Summary of Contents for Nuvair Quincy 390
- Page 1 User Manual Quincy 390 / Coltri MCH 36 Electric Nitrox System REV: 03.19 www.nuvair.com...
- Page 2 Every effort was made to ensure the accuracy of the information contained within. Nuvair, however, retains the right to modify its contents without notice. If you have problems or questions after reading the manual, stop and call Nuvair at +1 805 815 4044 for information.
-
Page 3: Table Of Contents
Material Safety Data Sheets ......................40 Owner’s Warranty Responsibilities ………………………………............43 Warranty …………………………………………………………………………………………………….. 42 Additional Record of Changes ……………………………………………………………………………. 43 Separate Manuals Included: Nuvair Pro O Oxygen Analyzer Operation Manual Coltri MCH-36 High Pressure Compressor Manual NUVAIR Q-390/MCH36 Nitrox system User Manual... -
Page 4: Introduction
Q-390/MCH 36Electric Nitrox System Introduction Nuvair has taken extreme care in providing you with the information you will need to operate this system. However, it is up to you to carefully read this manual and make the appropriate decisions about system safety. -
Page 5: Safety Warnings And Warning Graphics Defined
Do not use this system to produce nitrox mixtures containing more than 40% oxygen. Pumping nitrox mixtures with higher concentrations of oxygen may lead to fires or explosions, which can cause serious personal injury or death. NUVAIR Q-390/MCH36 Nitrox system User Manual Page... - Page 6 Cubic Feet per Minute High Pressure RPM . Rotations per Minute Low Pressure Parts Per Million Oxygen L/min Liters Per Minute Carbon Monoxide Oxygen Percentage of Gas Carbon Dioxide B.P. Back Pressure Nitrogen NUVAIR Q-390/MCH36 Nitrox system User Manual Page...
-
Page 7: Safety And Operation Precautions
Safety and Operation Precautions can result in injuries or equipment damage. However, Nuvair does not state as fact or does not mean to imply that the preceding list of Safety and Operation Precautions is all-inclusive, and further that the observance of this list will prevent all injuries or equipment damage. -
Page 8: Legal Precautions
% plus signature and date • User’s check of oxygen content O % plus signature and date • Fill pressure • MOD (maximum operating depth) in user’s handwriting • Nitrox certifying agency and card number NUVAIR Q-390/MCH36 Nitrox system User Manual Page... -
Page 9: Theory Of Operation
The HP compressor pumps the nitrox to a maximum pressure of 3600 psi (250 bar) to fill scuba tanks or storage cylinders. A unique feature of Nuvair nitrox systems is that the feed air pressure that correlates to a specific nitrox O % is repeatable. -
Page 10: Low Pressure Air Compressor Technical Data
• Compressor current: 440 V 50 or 60 Hz three phase – 27 Amps • Control voltage: 230 V General Technical Data: • Oil capacity: 9 Quarts – 16 Ounces (9 liters) • Maximum oil content in air: 3 mg/m NUVAIR Q-390/MCH36 Nitrox system User Manual Page... -
Page 11: High Pressure Compressor Technical Data
(see page 39 for filtration factor chart) • Condensate drains: automatic & manual interstage & final • Fill Pressure Stop: automatic & manual • Low oil level auto shutdown • Interstage pressure gauges NUVAIR Q-390/MCH36 Nitrox system User Manual Page... -
Page 12: System Components
♦ Soft start motor starter ♦ Hour meter ♦ External lubricant dip stick, fill, and drain ♦ Nuvair 455 food grade compressor lubricant (see MSDS starting on page 40) ♦ Large air aftercooler • Back-pressure regulator that controls LP compressor feed air supply ♦... -
Page 13: Nitrox System Specifications
LP Feed Air Quality Grade D Optimum Temperature 110 +/- 5 F (43 +/- 3 Nitrox Range 24 - 40% Charging Rate 26.4 SCFM (750 L/min) Horse Power – 20 horse power Electric (15 kW) NUVAIR Q-390/MCH36 Nitrox system User Manual Page... -
Page 14: Nitrox System Component Identification
LP Oil Filter HP Motor Control Fill Port Electric Box HP Oil Fill Port LP Oil Drain HP Compressor Intake Plumbed to Membrane HP Oil Gauge HP Auto Drains HP Oil HP Motor Drain NUVAIR Q-390/MCH36 Nitrox system User Manual Page... - Page 15 HP compressor Moisture Separator Condensate Container with LP Compressor Muffler & Drain Aftercooler LP Electric Motor Power cable for LP Motor total package Control Electric HP & LP Collective Condensate Drain NUVAIR Q-390/MCH36 Nitrox system User Manual Page...
- Page 16 LP or HP Gas Stop LP Compressor Dial-A- Pressure Fill Gauge Pro 4 Warn Low Pressure High Pressure Multi Gas Monitor Compressor Compressor On/Off On/Off Switch & Switch & Hour Hour Meter Meter NUVAIR Q-390/MCH36 Nitrox system User Manual Page...
-
Page 17: System Drawing/Schematic
Q-390/MCH 36Electric Nitrox System 11.0 System Drawing / Schematic NUVAIR Q-390/MCH36 Nitrox system User Manual Page... -
Page 18: System Flow Chart
+/- 1% O compression to +/- 2% O HP nitrox delivered to scuba cylinder - OR - HP compressor with moisture removal & filtration HP nitrox delivered to compresses nitrox storage NUVAIR Q-390/MCH36 Nitrox system User Manual Page... -
Page 19: Installing The Nitrox System
Q-390/MCH 36Electric Nitrox System 13.0 Installing the Q-390/MCH36 Nitrox System If any information in this manual conflicts with any of the other manuals call Nuvair before proceeding. The Nuvair System should never be operated in a facility where the room temperature exceeds F (40 C) while the system is in use. -
Page 20: Electrical Power Connection
Improper wiring may lead to fires, which can cause serious personal injury or death. The electrical power to the Nuvair Nitrox System must be off while wiring this system for service. Failure to ensure that the electrical power is off can lead to severe personal injury and death by electrocution. -
Page 21: Check Compressor Lubricant Levels
Check lubricant levels before starting the LP and HP compressors and add lubricant as LP oil fill & required. Use only the lubricants specified by dip stick Nuvair. Compressor lubricant level sight gauge Do not allow nitrox to be discharged into the air storage system. Nitrox introduced into the air storage system could cause a diver to suffer from oxygen poisoning at depth. -
Page 22: Pre-Operation Instructions
%. The fill oxygen analyzer supplies more accurate oxygen readings, within +/- 1% O . For cylinder nitrox fills, the user must always verify the final fill with a third independent oxygen analyzer. NUVAIR Q-390/MCH36 Nitrox system User Manual Page... - Page 23 The oxygen analyzers may require re-calibration after 10-20 minutes of operation due to humidity and temperature change effects on the sensor. To recalibrate, turn off the LP feed air and follow calibration instructions. NUVAIR Q-390/MCH36 Nitrox system User Manual Page...
-
Page 24: Producing Nitrox
Never allow any gas stream to be directed at any part of your body. Do not change the temperature setting on the thermostat control without contacting Nuvair. Changes in temperature settings may cause membrane damage. A damaged membrane will not produce the correct nitrox mixture which can lead to severe personal injury if the gas is used for diving purposes without proper analysis. - Page 25 40% oxygen. When filling oxygen clean cylinders, hyper-purification of the nitrox is required using an optional oxygen compatible air purification system available from Nuvair. This nitrox system does not produce nitrox mixtures acceptable for 100% oxygen service.
-
Page 26: Pumping Nitrox
When the HP compressor auto drain engages and dumps condensate, the fill oxygen analyzer reading will decrease momentarily due to the pressure drop in the system. It will return to its previous reading within seconds after the auto drain sequence stops. NUVAIR Q-390/MCH36 Nitrox system User Manual Page... - Page 27 4) After filling is complete, close the cylinder valve, vent the bleed valve, and remove the cylinder. 5) Test the nitrox O % in the cylinder using an independent oxygen analyzer such as the Nuvair O Quickstick . Calibrate the analyzer before use in accordance with manufacturer’s instructions.
-
Page 28: Pumping Air
4) The system will automatically drain all filters, compressor, and volume tank condensate. Dial-A-Pressure Switch & Gauge. Adjust Shut Off Pressure Here Low Pressure High Pressure Compressor Compressor On/Off On/Off Switch Ball Valve LP Tank NUVAIR Q-390/MCH36 Nitrox system User Manual Page... -
Page 29: Nitrox Operational Notes
6) When finished return LP regulator to previous setting, and allow the fill oxygen analyzer reading to stabilize. Make any minor adjustments necessary to achieve the desired O %, and then resume filling storage tanks. NUVAIR Q-390/MCH36 Nitrox system User Manual Page... -
Page 30: Maintenance
3) Check LP air filtration for condensate and proper operation of condensate drains. Use only the specified Nuvair lubricants in this system. The use of incompatible lubricants presents a risk of fire and/or explosion, and may result in system damage. -
Page 31: Routine Maintenance
17.2 Routine Maintenance 1) LP Compressor Lubricant: Change compressor lubricant every 100 hours or annually, whichever comes first. Only use lubricants rated for use with nitrox, such as Nuvair 455 . Never mix compressor lubricants. See Section 17.3 and LP compressor manual for details. -
Page 32: Compressor Lubricant
This can lead to severe personal injury or death. 17.3 Compressor Lubricants (see page 40 for Material Safety Data Sheets) • The LP compressor in your nitrox system comes standard with Nuvair 455 synthetic food grade compressor lubricant. Customers may specify different lubricants, check lubricant page at the back of manual for accepted lubricants. - Page 33 Lubricant sight gauge Lubricant drain plugs, right side of pumps • The LP compressor in your nitrox system comes standard with Nuvair 455 synthetic food grade compressor lubricant. • The HP compressor comes with the Nuvair 455 synthetic food grade lubricant.
-
Page 34: Lp Feed Air Filtration And Bowls
Filter with Filter with auto-drain auto-drain auto-drain auto-drain should not float & liquid float & liquid float & liquid contain level indicator & level indicator & level indicator moisture service indicator service indicator NUVAIR Q-390/MCH36 Nitrox system User Manual Page... -
Page 35: Changing Lp Filtration Elements
The interior of the Filter Bowls can be cleaned with a diluted solution of Simple Green flushed thoroughly with clean water. This will assist to prolong the life of the element, bowl, and auto drain. NUVAIR Q-390/MCH36 Nitrox system User Manual Page... -
Page 36: Hp Compressor Filtration
Be sure that all pressure has been relieved from the system prior to opening any filtration canister. Failure to vent pressure from the system prior to opening the canister can lead to serious personal injury or death. NUVAIR Q-390/MCH36 Nitrox system User Manual Page... -
Page 37: Spare Parts List
See LP and HP compressor manuals for compressor parts lists. Other nitrox system components and related items are listed below. Nitrox System Components Type Part Number LP Compressor Consumables LP compressor lubricant, food Nuvair 455, 1 Gal 9406 grade, nitrox compatible Hankison HF11-24 E11-24 Hankison HF7-24 E7-24... -
Page 38: Service Record Log
Q-390/MCH 36Electric Nitrox System 19.0 Service Record Log Date Technician Name Service Performed NUVAIR Q-390/MCH36 Nitrox system User Manual Page... -
Page 39: Appendix
68ºF (20ºC) 1 x Life 89ºF (32ºC) 77ºF (25ºC) 0.8 x Life 96ºF (36ºC) 84ºF (29ºC) 0.55 x Life 105ºF (41ºC) 93ºF (34ºC) 0.45 x Life 114ºF (46ºC) 102ºF (39ºC) 0.35 x Life NUVAIR Q-390/MCH36 Nitrox system User Manual Page... -
Page 40: Material Safety Data Sheets
• To prevent membrane damage, drain all low pressure filters and condensate tanks on a daily basis. • If you become aware of an operational fault, stop using the equipment immediately and contact Nuvair for assistance. Maintenance: • Change low pressure filter elements on a schedule determined by filter capacity and ambient temperature and humidity. - Page 41 NUVAIR has employed in the installation or use of any OEM component. This warranty is not transferable. NUVAIR will, at its discretion and according to the terms as set forth within, replace or repair any materials which fail under normal use and service and do not exhibit any signs of improper maintenance, misuse, accident, alteration, weather damage, tampering, or use for any other than the intended purpose.
-
Page 42: Warranty
Nuvair to contact the user regarding this product. The user must notify Nuvair of any change of address by the user or sale of the product. All changes or revisions to this manual must be recorded in this document to ensure that the manual is up to date. - Page 43 Q-390/MCH 36Electric Nitrox System...
- Page 44 Q-390/MCH 36Electric Nitrox System Nuvair Phone +1 805 815 4044 Fax +1 805 486 0900 1600 Beacon Place Oxnard, CA 93033 USA info@nuvair.com www.nuvair.com...
