Jerguson LUMASTAR EPL-100 Installation, Operating, & Maintenance Instructions

For atex units, led explosion protected illuminator

Advertisement

Quick Links

Specialists in Liquid Level Indication
STORAGE and HANDLING
The
Jerguson
LED
Illuminator meets or exceeds all applicable
specifications when shipped from the factory.
All units should be inspected upon receipt to ensure
that no damage has been incurred during transit. If
there has been damage, a claim should be filed with
the carrier immediately. Unit should be stored in an
area protected from the elements and corrosive
fumes, in a secure manner where they can neither
fall, nor be struck by other objects. Care should be
taken to protect the window and the end connections
from damage. Avoid placing any objects directly
on the light at any time.
COMPONENTS
There are three main components that make up the
LED illuminator: the light strip, the power supply,
and the cable connecting these two main pieces.
The cable may have more than one piece depending
on the required distance between the illuminator and
the power supply. The power supply is constructed
of aluminum, aluminum conduit sealing device and
a stainless steel I.S. connector. The light bar is
constructed of aluminum, stainless steel, glass and
silicone.
Questions
applications should be directed to The Clark-
Reliance Corporation.
INSTALLATION
CAUTION: All lights are tagged with the
service conditions for that particular unit. These
specifications are located on the Jerguson tag on
the power supply housing, and are contained in
the "Specifications" section of this manual. Do
not use or refer to specifications listed on red
label on the power supply housing. They are
specifications for generic use. Review the ratings
prior to installation and again prior to start-up,
to ensure proper operation in the installed
environment. Should there be any doubt as to
LUMASTAR™ EPL-100
INSTALLATION, OPERATING &
MAINTENANCE
INSTRUCTIONS FOR
ATEX
Explosion
Protected
regarding
acceptable
UNITS
the applicability of a unit for the installed
environment, consult the factory before placing
the unit into service.
Note:
All installation steps should be
performed by a qualified technician and should
be executed in accordance with all applicable
national and local codes.
The light and power supply should be checked to
ensure that they contain no foreign matter, and that
the end connections are clean, undamaged, and in
line with existing conduit.
Step by step instructions:
1) Refer to J500.33.A1 for bracket mounting
instructions.
CAUTION: Before working with power supply,
verify that the area is free of flammables and AC
power circuit is off.
2) Loosen cover locking screw and open the cover
of the power supply housing. Insert the AC
Line wires into the housing and connect to the
"AC IN" terminal block. A ground screw is
located inside the enclosure if required.
CAUTION: The DC output is pre-wired. If this
connection is removed during installation,
reconnect the "AC IN" and "DC OUT" to the
proper positions. Failure to do so will result in
permanent damage to the power supply.
3) If the cable will not reach the power supply,
contact your local representative for the
required extension cable.
4) Replace the cover on the power supply housing.
5) Switch "ON" the power supply making sure the
Illuminator is functioning properly, with all
LED's illuminated.
6) If the LED's do not illuminate, remove the
cover on the power supply once the power as
Section:
J500
Bulletin:
J500.33
Date:
01-10-12
Supersedes:
09-11-06
1 of 4
