Tapco Pro Cut-Off Gauge Operation Manual

Pro Cut-Off Gauge

STEP 2

To set up for first-time use, measure
back from the edge near each end of
the workpiece and make a mark. Flip
the Cut-Off Gauges down. The ends
of the Cut-Off Gauges indicate where
the Cut-Off will make the cut. Move
the workpiece until the marks align
with the ends of the gauges, then lock
the brake.
OPERATIONS MANUAL
Make Cuts Faster Without Measuring Each Cut
Attach Pro Cut-Off Gauge

STEP 1

Position the work piece in the Brake and close
the Brake to loosely hold the material. Attach
a Cut-Off Gauge near each end of the material.
Do this by placing the clip opening against the
back edge of the Locking Anvil and pulling it
sharply forward until it locks in place. Make
sure the clip is as far forward as it can go. Flip
the Cut-Off Gauges up and out of the way.
®
