Brave – Door Entry System
Brave Steel - C
Brave Steel - LC
User and Service Manual
Version 2.6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Steel-C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Brave Steel-C

Summary of Contents for Brave Steel-C

  • Page 1 Brave – Door Entry System Brave Steel - C Brave Steel - LC User and Service Manual Version 2.6...
  • Page 3 Congratulation on purchasing the „BRAVE Steel Door Entry system‟, which is a continuation of the successful „New Universal Door Entry System‟ NUDV. The Brave Steel Door Entry System is a universal project with the title “BRAVE” with different designs bringing a wider spectrum of functions and possibilities.

  • Page 4: Table Of Contents

    Table of Contents BASIC FEATURES ..................... 6 .................... 6 EATURES ..................7 ERMINOLOGY ..........8 RAVE TEEL VERSIONS AND DIFFERENCES ..................8 NIT FEATURES 1.4.1 Modules ..................... 8 1.4.2 Mechanical parts ..................9 1.4.3 Module compositions ................11 .............. 12 OTHERBOARD CONNECTION BSC(M)- 4 ...........
  • Page 5 ............. 57 ASIC SETTING AND DELETION ............... 57 ND OF PROGRAMMING 5.10 ............... 58 ARAMETER OVERVIEW TECHNICAL PARAMETERS................. 62 ..............62 LECTRICAL PARAMETERS ..............62 ECHANICAL DIMENSIONS TABLE FOR EASY PROGRAMMING ............63 BRAVE Steel – User and service manual...

  • Page 6: Basic Features

     Programmable with PC, via USB cable, and remote DTMF programming;  Integrated regulated heating of the PCB;  Switchable name tag lighting;  Unit earthed for better protection against static electricity (C) – only full version (Comfort) BRAVE Steel – User and service manual...

  • Page 7: Terminology

    PBX extension) The manufacturer continuously improves the product firmware. The technology used allows you to upload to Brave the latest version of the firmware any time using a standard computer with BraveSet and USB cable. The latest version of the firmware is available at http://www.alphatech.cz...

  • Page 8: Brave Steel Versions And Differences

    The features and parameters that are available to, and can be set, differ for each version of the Brave. It is therefore necessary to set the parameters for all versions including any add-on parameters for each version.

  • Page 9: Mechanical Parts

    Assembly box Mounting frame and cover frame for below plaster for below plaster for assembly above and below 1158/42 1145/52 1158/62 For illustration Only it is also possible to use the MK2 from NUDV BRAVE Steel – User and service manual...
  • Page 10 Roof Frame Housing for assembly on plaster for below plaster for below plaster 1158/SH2 1158/612 1158/802 Rain cover - compact for assembly on plaster 1158/312 (contains 1158/62) BRAVE Steel – User and service manual...

  • Page 11: Module Compositions

    1.4.3 Module compositions The modules are installed into the frames so that modules 1-4 are in one column (row) and the whole composition is then attached to this column. BRAVE Steel – User and service manual...

  • Page 12: Motherboard Connection

    (7 – second relay, 8 – exit button, 12 – DIP 3-5) Pic. 1 Brave Steel door entry system motherboard relay 2 only on version (C) exit button only on version (C) DIP switch 3,4 a 5 only on version (C) BRAVE Steel –...
  • Page 13 (Siemens). This regime fully replaces the use of internal box Best Box; and 5 = Name tag back lighting (switches on/off LED name tag back lighting next to the button). BRAVE Steel – User and service manual...
  • Page 14 1 – 8 on the PCI, additional buttons can also be added after that. To simplify a place can be determined as – how many flat cables are between the keyboard and the motherboard, which is where the keyboard is connected. BRAVE Steel – User and service manual...

  • Page 15: Connection Of Modules Bsc(M)-Mod4

    Next in line is passive module –connected with 5 conductors, the 2 yellow conductors are used for powering the name tag back lighting (12V). Pic. 2 Connection of BSC-mod4 and BSM-mod4 BRAVE Steel – User and service manual...
  • Page 16 Pic.3 also shows the position of the button module with keyboard connected. The number of buttons on the basic module is set with parameter 6# – see page 49. Pic. 3 Interconnecting of modules Brave Steel BRAVE Steel – User and service manual...

  • Page 17: Bskey Keyboard Connection

    You can set the DTMF dialling option with parameter 40 during a phone call. Because on the keyboard the button is used purely for disconnection and cancelling, you can set option * / # under button for parameter 40. BRAVE Steel – User and service manual...

  • Page 18: Installation

    2.1.1 Front cover disassembly The cover frame is affixed with 4 phillips screws. Removing the panel is done by extracting the fixing holders as per picture (on the side of the panel, in a forward direction) BRAVE Steel – User and service manual...

  • Page 19: Name Tag Back Lighting Assembly And Disassembly

    You can fill the tags in MS Excel – the file for which can be downloaded from www.alphatech.cz or from the installation CD. The tag dimensions are 55 x 14,5 mm. BRAVE Steel – User and service manual...

  • Page 20: Inserting The Module Into The Mounting Frame

    First screw on the bottom part of the frame. You can fit the frame into the fitting box of 1158/4x Urmet system, or 1145/5x system (original NUDV) 1158/4x 1145/5x Then screw on the top part of the frame. BRAVE Steel – User and service manual...

  • Page 21: Cover Frame Assembly

    2.1.5 Cover frame assembly The cover frame is affixed with 4 phillips screws. 2.1.6 Wall mounting BRAVE Steel – User and service manual...

  • Page 22: Connection

    Line connection - The Brave Steel broadcasts a sound (Reset) ♫ (chapter 3.1 page 27) if it has previously been disconnected from the line for any length of time. Brave Steel is an analogue door entry system designed for connection to an analogue phone line.
  • Page 23 (relay regime 1 and 2 m=1) or the gradual opening of a door (relay regime 2 - m=5 - only (C) version. 2. Two sources – the potential to use two power sources, one for the Brave Steel and a second for an electric lock.
  • Page 24 Pic. 4 Examples of relay connections BRAVE Steel – User and service manual...

  • Page 25: Code Relay (Cosw)

    When using this function is not possible connecting or disconnecting the voltage at the terminals to lock this lock activated. Activation is performed only when positive result compared serial information transmitted between Brave and the board code relay Brave is set in several codes to activate the relay code.

  • Page 26: Other Accessories

    2.3.2 Power supply 12V A 12V/A alternative power supply is recommended for the Brave Steel. This is not a part of delivery and must be ordered separately. Further details power supplies and electric locks can be found at www.alphatech.cz...

  • Page 27: Door Entry System Operation

    Empty memory (no number is programmed) 1300-2100 It is useful to know what tones the Brave Steel plays during installation as it will assist in the analysis of its state and operation. The sounds can be turned off in several levels (parameters 61,62,63 and 65).

  • Page 28: Caller At The Door

    Visitor finds the appropriate name (for example Mr Smith) and presses the button. The Brave will pick up a line, "plays" the pick up line tone (if it is not prohibited para.62) and dials the phone number saved under that button (parameter 1 or 2 depending on system regime).

  • Page 29: Relays Regimes

    Option to choose 1 or 2 digits of code 2 digit code is basic and it is possible to shorten it by using * in the first place of code during programming BRAVE Steel – User and service manual...

  • Page 30: Person In The Building

    Brave entry system (i.e. Mr Smith). 3.3.1 Outbound call An outbound call is a call from the Brave system (i.e. started by a visitor). Once the system has been dialled, a phone inside of the building rings and on pick up it is possible to talk to the visitor at the door.

  • Page 31: Incoming Call

    The visitor enters a number combination and after a length of time, set by the max time between key presses (parameter 53), the Brave picks up and dials the given number. If 1 then the keyboard choses a 2 digit combination 01-99 as per the memory address, where a telephone number is saved.

  • Page 32: Acoustic Path Setting

    We choose when the direction to the phone is interrupted. If parameter 73 greater than parameter 72, thus favored direction to the speaker. We choose this if the interrupted sound in the speaker of communicator. BRAVE Steel – User and service manual...

  • Page 33: Parameter Programming

    Brave is and ask be connected to the branch to . The brave will pick up (you will hear the which the Brave is connected) pick-up tone –...

  • Page 34: Programming With The Help Of Apc - Programme Brave Set

    If you want to keep a connection opened during the programming (prolong the 30 sec time) regime (i.e. before a customer decides what else he wants to be set) then you can press * or #, the Brave immediately answers with an error tone but will prolong the time before disconnecting.

  • Page 35: Description Of Programmable Parameters

    Flash numbers. Pause Note. The Day/Night regime switch over remains set in the Brave even after a line disconnection, in version (C) this regime switches over according to actual time (if this function is on – parameter 084) Examples of setting: first button is supposed to dial 358 during the day and 0603441296 during the night, then the programming is - 101358 and wait for ♫, then 2010 *0 603441296 and wit...

  • Page 36: Relays

    Day/Night (parameter 47) and then set the same code for switching over Day/Night (parameters 45 and 46). His way it is guaranteed that Brave will always be in Day regime and you can only programme telephone numbers for the day regime (parameter 1).
  • Page 37 (00-999999) – relay number [1-2] – order [1 - 5] for 1 impulse. 5 passwords (external codes) from Brave‟s buttons (external code of code lock) – order = * to set password (external code) for 2 impulses hh... – password (external code) for relay switching on from button or keyboard [2 to 6 places].
  • Page 38 "*a", where a is a single number and the star represents an empty space and must be in the first place. Switching a relay on with 2-impulses is used for sliding gates replacing a gate entry. BRAVE Steel – User and service manual...
  • Page 39 Programming: 352*8 ♫ , 432*8 ♫ , 362*9 ♫. If you are in conversation with the Brave, the command to open a gate would be button 9, the first impulse starts and the gate opens, the second impulse stops it, the time the gate is opened "opened space"...
  • Page 40 – turns on transmission serial code to activate the first switch. CAUTION - at activation this function never connect to the circuit electric lock without board COSW - code relay - threatens to destroy the relay in Brave communicator! The following codes may be the same or different for the resolution switching on multiple parallel connected relay code.
  • Page 41 Default activation code 2 pulses from phone abcd 0000 (0000-1111) abcd – Brave sends a serial code for the code relay (COSW) after evaluation code from telephone (DTMF) namely for 2 pulses Parametr Value Description Default activation code from other modes of switch...

  • Page 42: Basic Parameters

    (00- 99,*0-*9) g – Command order [1-2] (there are 2 to disconnect the Brave from both relays) bb – Command for disconnecting the Brave from the phone [2 spaces] It is advantageous to set the same command for relay switching on...
  • Page 43 2. Switch „DIP 1‟ to „ON‟; 3. Call the Brave; 4. Once the Brave picks up the system is in programming regime. In this regime it is possible to change the password 44xxxx; 5. Switch „DIP 1‟ to „OFF‟; and 6.
  • Page 44 – Line disconnection by repeated pressing of the same number: k=0 function is disabled; and k=1 repeatedly pressing the same button to disconnect the line. WARNING !! setting of this parameter materially affects number dialling! BRAVE Steel – User and service manual...

  • Page 45: Time Parameters

    Number of rings before the Brave picks up (1-9) q – The number of rings before an incoming call is picked up. The Brave picks up between rings 2 secs. after detecting the q-th ring. It is possible to set the number of rings between 1 and 9.
  • Page 46 Meaning Basic Time before commencing a choice z – Time [sec] after the Brave picks up, before it commences a choice [range 1-5]. This time is different for each switchboard phone system, but generally most operate within 2 seconds after a line is picked up.
  • Page 47 100 + 400 = time 375-475 425-525 length of pause [ms] 475-575 [range 1-0 which is 500-1400ms] 525-625 Time p is the simultaneously length of gap 575-675 between button taps for an impulse choice. 625-725 675-775 725-825 BRAVE Steel – User and service manual...
  • Page 48 Preemphase is the ratio of the upper and lower groups of DTMF frequencies. It is possible to choose ratio 2.2 dB - p=0 (Europe) or ratio 3.2dB - p=1 (Australia) Choice of DTMF volume levels (4 levels): Volume in DTMF [dB] s - choice BRAVE Steel – User and service manual...

  • Page 49: System Parameters

    Acoustic ticking signal during a call (0/1) Ticking during a call is switched off as standard. However, by switching it on you can differentiate on the switchboard a call from the Brave by a faint ticking. The values are: Ticking into a call is off...
  • Page 50 (confirmation) and a call is activated as if there were a number. Warning: During the first 10 seconds of a call the tone detector is inactive (there is a pause before the switchboard responds or number dialling by the switchboard). BRAVE Steel – User and service manual...
  • Page 51 By switching this function on t=1 the processor goes into sleep mode immediately after the line connection, and after 3 secs. The Brave initialises. The line connection after the power supply connection is then delayed - state switching on/restarting of the switchboard. If...

  • Page 52: Parameter Setting Hands Free

    Suppression of background noise (0/1) This function is set to off as standard n=0. If the Brave is installed in noisy location (train station, busy street, car park etc.) by switching on this circuit n=1 the noise level is set as a default threshold for switching on the microphone and is not one way opened.
  • Page 53 (0/1) Nearly every country in the world has different telephone norms and this parameter enables you to lower the voltage on the Brave‟s terminals to connect telephone line voltages in active state by 1V. Where it is required the respective norm I=0 lowers line voltage by 1V, as standard it is l=1.
  • Page 54 (0/1/2) The Brave has a circuit for installations remote from the switchboard (>100m) that can compensate for the loss caused by a conduit. This function is switched off as standard k=0, but it is possible to set on 2 levels, depending on the current...

  • Page 55: Time Programme - Automatic Switch Day/Night (C)

    (0/1/#) If the Brave has an RTC circuit - version (C) (M), it possible to switch on the automatic switch over time a=1. Condition is correct time setting. It is possible to make easy control a=#, the Brave answers either with confirmation tone (all is OK or with an error tone (it is necessary to set the time).
  • Page 56 00:00 is entered. Programming sequence: 0406451505 and ♫, 0515000000 and ♫, 0600001200 and ♫ BRAVE Steel – User and service manual...

  • Page 57: Basic Setting And Deletion

    WARNING !!! deletion is irreversible and it would be necessary to reprogramme them again! 5.9 End of programming Paramet Value Meaning Basic E N D of programming After choosing 9 programming tone the Brave disconnects. BRAVE Steel – User and service manual...

  • Page 58: Parameter Overview

    2 pulses from buttons abcd 0000 (0000-1111) activation code 2 pulses from phone abcd 0000 (0000-1111) activation code from other modes of switch abcd 0000 (0000-1111) Type of choice v – ton/impulse (0/1) BRAVE Steel – User and service manual...
  • Page 59 Choice DTMF from the keyboard during a call (0-3) Line disconnection by repeat press of the same button (0/1) Umber of rings before Brave picks up (1-9) Maximum length of call (0-9,*,#) Time between button presses (1-9) Time of disconnection for repeat choice...
  • Page 60 Time setting hh-hours, nn-minutes ddmmy Date setting dd-day,mm-month,yy-year, w- day of the week Waits 1 sec for zero sec Sunday – time setting hours hh and hhnnkkj 00000000 minutes nn starts day and hours kk and BRAVE Steel – User and service manual...
  • Page 61 Basic setting only for parameters 5x only 6.. Basic setting only for parameters 6x only 7.. Basic setting only for parameters 7x only 0.. Basic setting only for parameters 0x E N D BRAVE Steel – User and service manual...

  • Page 62: Technical Parameters

    Value Conditions Minimum line current 18mA Line picked up Minimum line voltage Line disconnected Voltage on the line when Brave < 8V I = 20mA picks up (VA characteristic) < 12V I = 60 mA Lead in in disconnected state <...

  • Page 63: Table For Easy Programming

    Number under button 11 Night/2gr. Number under button 12 Night/2gr. m=1 - 8 relay 1 works in mode Relay 2 works in mode m=1 - 8 Day+Night 3211 Passw. for relay 1 (1 imp.) BRAVE Steel – User and service manual...
  • Page 64 (1 imp.) Night 3223 Passw. for relay 2 (1 imp.) Night 3224 Passw. for relay 2 (1 imp.) Night 3225 Passw. for relay 2 (1 imp.) Night 322* Passw. for relay 2 (2 imp.) BRAVE Steel – User and service manual...

  • Page 65: Brave Steel – User And Service Manual

    0000-1111 code for activation other mode 0000-1111 0 / 1 Type of choice tone / imp. * / # Sign for prolonging of call Brave disconnection from phone Brave disconnection from phone Service password Command for switch over to DAY...
  • Page 66 0 / 1 Baby Call Mute at the lock activated 0 / 1 Type no of buttons on the panel dependant Delayed start (Siemens) Reception volume 01-16 (TRH) Transmitting volume (MIC) 01-16 BRAVE Steel – User and service manual...
  • Page 67 Date setting hhnnkkjj Sunday hhnnkkjj Monday hhnnkkjj Tuesday hhnnkkjj Wednesday hhnnkkjj Thursday hhnnkkjj Friday hhnnkkjj Saturday note. hours hh and minutes nn starts day and hours kk and minutes jj starts night BRAVE Steel – User and service manual...
  • Page 68 WARRANTY: Each and every product has been tested before it leaves the factory. The manufacturer guarantees that the product and its features will work in accordance with the descriptions in this manual as long as the customer uses the product in accordance with the manufacturer‟s instructions. Warranties will be extended when a warranty repair has been undertaken.
  • Page 69 © JR 2011-13 Version 2.6 X/13...
