Initial Setup & Assembly; Snowthrower Components - Simplicity 1694144 Operator's Manual

4
3
28
2
1
Ref Qty Description
1 1 SNOWTHROWER
2 2 GUIDE, Chute, Hold-Down
3 2 SCREW, Plastite
4 1 DISCHARGE CHUTE ASSY.
5 1 MOUNTING BRACKET
6 2 WASHER, Large
7 2 LOCKWASHER, 1/4"
8 2 NUT, 1/4-20
9 1 PIN
10 1 HAIR PIN CLIP
11 2 CAPSCREW, 1/4-20 x 7/8
12 1 SWITCH
13 1 WIRE HARNESS, Switch
14 1 WIRE HARNESS, Trailer Plug
Figure 10. Initial Setup
9
8
7
6
5
14
27
26
25
24
23
Ref Qty
15 1
16 1
17 2
18 2
19 1
20 1
21 1
22 1
23 1
24 1
25 1
26 1
27 1
28 1
15
Initial Setup
& Assembly
10
11
12
13
16
15
17
18
19
20
21
22
Description
SPRING, Extension
BRACKET, Spring
HAIR PIN CLIP
PIN, Clevis
NUT, 5/16-18
LOCKWASHER, 5/16
SUPPORT
CAPSCREW, 5/16-18 x 1
CAPSCREW, 3/8-16 x 1-1/4
ASSIST LEVER
SPACER
LOCKWASHER, 3/8
NUT, 3/8
RING GEAR, Reinforcement
