DESCRIPTION
This bulletin describes the installation and operating instructions for the FX04 and FX04-1, 3 lb.-ft./
4Nm servo motors. .
SAFETY INFORMATION
WARNING: When this equipment is mounted onto an appliance, all external timers/control-
lers must be listed or recognized components and approved by national certification agencies
for the purpose for which they are used and approved for use by a local authority who has
jurisdiction.
The Fireye FX04 and FX04-1 servo motors are precision actuators designed to accurately position
valves and dampers. The servomotor interprets Modbus commands from an external control and
uses a stepper motor to drive to the commanded position. A feedback potentiometer provides contin-
uous positional information that can be read and cross checked by the external control.
The FX04 series servo motor offers a maximum output torque of 3lb.ft/ 4Nm with a minimum travel
time of 30 seconds for 90 degrees of rotation. Maximum rotation angle of the drive shaft is 100
degrees.
The servo is designed to be applied for fuel valves and air damper control on industrial burners. It
can also be applied to drive any type of flow control valve or damper as long as the output torque is
suited to the application.
Before attempting to install, commission or operate this equipment all relevant sections of this docu-
ment must be read and fully understood, failure to follow them could damage the product or cause a
hazardous condition. If in doubt about any requirements consult the supplier.
Check the ratings in the following instructions to ensure the product is suitable for your application.
Installation, commissioning or adjustment of this product MUST be carried out by personnel quali-
fied by local, state, regional or national requirements.
After installation is complete, check the product operation is as described in these instructions.
The manufacturer of this equipment accepts no liability for any consequences resulting from inap-
propriate, negligent or incorrect installation, commissioning or adjustment of operating parameters
of the equipment.
Note: The manufacturer of this equipment has a policy of continual product improvement and
reserves the right to change the specification of the equipment and the contents of this manual with-
out notice.
These mounting and operating instructions are intended to give the knowledge which is necessary to
carry out the mounting and adjustment of FX04 servo motor safely and correctly.
FX04-1
Shown
®
®
Fireye
FX04 and FX04-1
Servo Motor Installation
NEX-3004
JUNE 27, 2011
NEXUS
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NEXUS FX04-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Fireye NEXUS FX04-1

  • Page 1 The Fireye FX04 and FX04-1 servo motors are precision actuators designed to accurately position valves and dampers. The servomotor interprets Modbus commands from an external control and uses a stepper motor to drive to the commanded position.
  • Page 2: Technical Data

     TECHNICAL DATA Actuating time for 90° angle of rotation: 30 s Nominal torque: 3 lb.-ft./ 4 Nm Holding torque: >3 lb.-ft./ 4 Nm Max. revolutions on the output drive shaft: 100° Nominal voltage 24 VDC~± 10% Nominal power consumption: 5 VA Angle of rotation limited by: Software...
  • Page 3 ® The installer should be satisfied that, as a result of the mounting, the commissioning or as a result of the test adjustments on the actuator, no potential hazards will be produced for devices/machines/ plant. Before mounting the servo motor, check the free movement of the valve/device. After completing the mounting and adjustment, check the correct functioning of the servo motor.
  • Page 4: Installation

     INSTALLATION Fasten the FX04 servo motor using bolts through a suitable mounting into the four 3/16 inch/5mm mounting holes so that the mounting surface rests flat. The output drive shaft should be connected using a suitable arm, link or flexible coupling. The mounting position of the FX04 servo motor is arbitrary.
  • Page 5 ® Cables, FX04-1 Cord sets having female connectors on both ends are available in 6 and 40 foot lengths. 59-565-6 or 59-565-40 Field wirable cables and connectors, FX04 Loosen the four cross-head housing cover screws and pull the cover hard to remove it. For the elec- trical installation of the FX04 servo motor, use the prescribed cable type (corresponding to the envi- ronmental conditions).
  • Page 6: Earth Ground

    Cables and connectors Field wireable connectors are available in kit form, 129-192. Fireye recommends cable part number 59-565 to be used for servo wiring. Fireye recommends cable part number 59-565 to be used for servo wiring. As shown above the cable strip length is specified at 30 mm (1.2 in) and each wire strip length is 7 mm (0.275 in).
  • Page 7 ® Manual Movement The servo can be moved manually by using the two red buttons (Figure 1 on page 3) whenever power is applied to the servo. One button moves the servo clockwise, the other is used to move the servo in the opposite direction.
  • Page 8  Read Table Table 2: Registers in Description Range Sequential Order 1 (first) Last commanded position 10 to 1100 0xFFFF if servo is in an error state Current servo position 10 to 1100 Current servo speed (bits 8 to 15) -30 to +30 Tweak Error (bits 0 to 7) -100 to +100...
  • Page 9 ® Blank Page...
  • Page 10 Fireye warranty, as stated in its General Terms and Conditions of Sale, pertains only to the Fireye products and not to any other equipment or to the combined system or its overall performance.
