Infotainment Carrier Board
SBEV-RCAR-KF-M04
Rev. 1. 1a
Preliminary Hardware Manual
-DRAFT VERSION -
.
0
Preliminary Hardware Manual
Advertisement
Table of Contents
Related Manuals for Shimafuji Electric KINGFISHER
Summary of Contents for Shimafuji Electric KINGFISHER
- Page 1 All information contained in these materials, including products and product specifications, represents information on the product at the time of publication and is subject to change by Shimafuji Electric Inc. without notice. Please review the latest information published by Shimafuji Electric Inc.
- Page 2 Preliminary Hardware Manual Notices on use and handling You should follow those remarks to use this product safely. If you are not following those remarks, you may cause electrical shock, injury, fire or trouble． Lightning Ｗhile lightning has occurred , never installing the product or connecting cables, it may cause an electrical shock by the thunderbolt.
- Page 3 Preliminary Hardware Manual Unplug the Power source Immediately unplug from the Power source when it smells or smokes. If continually keep supply power on while it smells or smokes, it may cause fire, an electrical shock or serious influence on this board and other equipments. Do not use or store in the following places.
- Page 4 Preliminary Hardware Manual Revision history Revision Release date Revised contents Remarks Alpha 2017/Apr./21 Draft version created 2017/Jul./7 Modify for SBEV-RCAR-KF-M04/S03 2017/Sep./4 Modify for SBEV-RCAR-KF-M04 1.11 2018/Jan./16 Delete 2. Specification SD card 1.8V Modify 4.13 HDMI 1980x1080 => 1920x1080i 1.1a 2018/Apr./24 Unconfirmed function comment added...
-
Page 5: Table Of Contents
Preliminary Hardware Manual Content OVERVIEW ············································································································1 SPRCIFICATIONS ···································································································1 BLOCK DIAGRAM ···································································································3 FUNCTIONS ···········································································································4 POWER SUPLLY ··································································································4 4.1. RESET ················································································································6 4.2. CLOCK ················································································································7 4.3. USB 3.0 ···············································································································8 4.4. USB 2.0 ···············································································································9 4.5. Mini PCI-Express ································································································· 10 4.6. M.2 INTERFACE ································································································· 11 4.7. - Page 6 Preliminary Hardware Manual 8.14. CN17 : CAN ········································································································ 46 8.15. CN18 : CAN ········································································································ 46 8.16. CN22 : MOST ····································································································· 46 8.17. CN23 : BOARD POWER ······················································································ 47 8.18. CN28 : MIC········································································································· 47 8.19. CN29 : VIDEO IN ································································································· 48 8.20.
-
Page 7: Overview
Preliminary Hardware Manual 1. OVERVIEW Infotainment Carrier Board called “KINGFISHER” . (Parts number: This document is the Manual for the SBEV-RCAR-KF-M04, hereinafter referred to as “this board”) This board is extending the function of R-Car Starter kit (hereinafter referred to as “CPU board”), Option, Renesas). - Page 8 Preliminary Hardware Manual Up 3Mbps SERIAL Connector: 535676-5 (CN4) TCAN332GDCNT(TI) CAN-FD Connector: S3B-PH-SM4-TB (LF)(SN) x2(CN17, CN18) 11023H52531 board (Option) MOST Connector: QSH-020-01-L-D-DP-A (CN22) MAX-M8Q-0 (ublox) Connector: PE44651C (CN16) 9 axis sensors LSM9DS0(STmicro) Si4689-A10-GM (Silicon Lab) RADIO LOOP Antenna: PTSA15235Z (CN43) RF Antenna: CONSMA001-G (CN42) TBD (Option) AUDIO AMP...
-
Page 9: Block Diagram
Preliminary Hardware Manual 3. BLOCK DIAGRAM The board block diagram. Figure 3: Block diagram... -
Page 10: Functions
Preliminary Hardware Manual 4. FUNCTIONS 4.1. POWER SUPLLY The main power supply domain must be connected to an external AC adapter. The voltage is +12V DC. ! Warning ! DO NOT USE R-Car Starter kit AC adapter to connect this board or this board AC adapter to connect R-Car Starter kit. - Page 11 Preliminary Hardware Manual - POWER OFF SW6 to OFF position Main power supply structure D3.3V PAmp_D12V AudioAMP +12Vin Connector FILTER ADAPTER VN7020AJTR ETHER AVB BR_D12V CONTROL FILTER Connector HUB5V HUB_D12V FILTER OKR-T/6-W12-C POWER D12V HUB3.3V FILTER MCP1725-ADJ HUB12 OKR-T/3-W12-C OKR-T/6-W12-C VCCDA FILTER VCCAD...
-
Page 12: Reset
Preliminary Hardware Manual 4.2. RESET The reset signal to each device. All reset signal is controlled by R-Car Starter Kit to this board. The reset structures R-CarH3/M3 CN22 MOST_RESET MOST Connector CN15 PCIe_RST PRESETOUTn_3 PCI Express Connector CN39 EtherAVB Connector I2C2_RST PCA9548ADB I2C4_RST... -
Page 13: Clock
Preliminary Hardware Manual 4.3. CLOCK The clock structures R-CarH3/M3 CN10 CSI0_CLKAp CSI0_CLKAn CSI0 Connector CN48 CSI1_CLKp CSI1_CLKn CSI1 Connector CN11 CSI2_CLKAp CSI2_CLKAn CSI2 Connector CN29 VI5_CLK Connector 24.000 MHz PCIE0_CN_CLK_P PCIE0_CN_CLK_M Connector EXT_LPO SN74LV1T0 4DBVR CN15 PCIE1_CN_CLK_P miniPCI Express PCIE1_CN_CLK_M Connector LVDS LVDS0_CLK_P... -
Page 14: Usb3.0
Preliminary Hardware Manual Figure 4-3 : clock structure 4.4. USB 3.0 The USB3.0 x1LANE (ch0) on the R-Car Starter Kit is connected to USB3.0 HUB (USB5534B-5000JZX) on this board, and connect to USB3.0 Type-A 2Port connector via USB3.0 HUB. The connector is connected the current protection power switch (max. 5v 3.7A) The USB 3.0 interface structure. -
Page 15: Usb 2.0
Preliminary Hardware Manual 4.5. USB 2.0 This board equipped with a USB2.0 (Type-AB) connector. The R-Car Starter Kit controlled USB2.0 interface (Ch. 0) HOST/FUNCTION. The USB 2.0 structure. R-CarH3/M3 OffVBUS I2C4_SDA Status1 ID_In TCA9539QPWR I2C4_SCL Status2 SHDN CN13 USB20_ID0 ID_Out VBUS MAX3355EEUD+ USB20_DM0... -
Page 16: Mini Pci-Express
Preliminary Hardware Manual 4.6. Mini PCI-Express This board equipped with a Mini PCI Express connector. The card size of Mini PCI Express is capable for Full size board (50.95x30). The Mini PCI-Express structure. R-CarH3/M3 CN15 PCIE1_TX_P PCIE1_TX_M PCIE1_RX_P PCIE1_RX_M PCIE1_CN_CLK_P PCIE1_CN_CLK_M CN52 SIM_VDD... -
Page 17: Interface
Preliminary Hardware Manual 4.7. M.2 INTERFACE This board equipped with a M.2 interface connector (KEY M). The card size of M.2 interface is capable for 2230～2280. The M.2 interface structure. R-CarH3/M3 PCIE0_TX_P PCIE0_TX_M PCIE0_RX_P PCIE0_RX_M PCIE0_CN_CLK_P PCIE0_CN_CLK_M Connector Figure 4-7: M2 I/F... -
Page 18: Wifi / Bluetooth
Preliminary Hardware Manual 4.8. WIFI / BLUETOOTH This board equipped with a module (WL1837MODGIMOCT) for IEEE802.11a/11b/11g/11n and BLUETOOTH Ver4.1. Wi-Fi use SD3 interface, and BLUETOOTH use HSCIF0 interface to R-Car Starter Kit. The Wifi and SD CARD cannot use simultaneously through SD3 interface and it controlled by U11P05 (SD_WF) to switch this function. -
Page 19: Sd Card
Preliminary Hardware Manual 4.9. SD CARD This board equipped with a normal size SD CARD slot. It assigned SD3 interface to R-Car Starter Kit. The Wi-Fi and SD CARD cannot use simultaneously through SD3 interface and it controlled by U11P05 (SD_WF) to switch this function. -
Page 20: Serial
Preliminary Hardware Manual 4.10. SERIAL This board equipped with a SERIAL connector (10pin) for debagging. The SERIAL connector is connected to SCIF1 on R-Car Starter Kit. The SERIAL structures. R-CarH3/M3 D3.3V 0～3.3V SCIF1_TXD SCIF1_RTS D3.3V SN74LVC125APWR SCIF1_RXD D3.3V SCIF1_CTS Debug Serial Connector Figure 4-10 : SERIAL I/F... -
Page 21: Camera Serial Interface (Csi)
Preliminary Hardware Manual 4.11. CAMERA SERIAL INTERFACE (CSI) This board equipped three CAMERA INTERFACEs (CSI). SERIAL Those are assigned CSI channel - CN10(CSI0) : option board, FPDLinkIII or GMSL - CN11(CSI2) : option board, FPDLinkIII or GMSL - CN48(CSI1) : CSI camera direct connection (30pin FPC) The SSI signal is switch between the camera serial interface (CSI0) SSI signal and radio devices SSI signal to use, and it controlled by U11 P15(HDMI_Radio) to switch this function. - Page 22 Preliminary Hardware Manual R-CarH3/M3 CN48 CSI1_CLKAp CSI1_CLKAn CSI1_DA1p CSI1_DA1n CSI1_DA0p CSI1_DA0n CSI1 Connector Figure 4-11b : camera SERIAL interface (CSI1) I/F R-CarH3 CN11 CSI2_CLKAp CSI2_CLKAn CSI2_DA3p CSI2_DA3n CSI2_DA2p CSI2_DA2n CSI2_DA1p CSI2_DA1n CSI2_DA0p CSI2_DA0n HDMI_CLK HDMI_SI HDMI_SO HDMI_CS_B GP1_08 GP1_16 D3.3V IrqExtB CSI2 Connector...
-
Page 23: Video In
Preliminary Hardware Manual 4.12. VIDEO IN This board equipped with an 8bit Parallel Video input connector (20pin). It supports ITU-R BT.601, BT.656, BT.709 formats. The Parallel Video IN structure. R-CarH3/M3 CN29 VI5_VSYNC VI5_HSYNC VI5_CLK VI5_DATA7 VI5_DATA6 VI5_DATA5 VI5_DATA4 VI5_DATA3 VI5_DATA2 VI5_DATA1 VI5_DATA0 Connector... -
Page 24: Hdmi
Preliminary Hardware Manual 4.13. HDMI This board equipped with a HDMI transmitter (ADV7513BSWZ) which support HDMI1.4a. The maximum resolution is 1920x1080i and it connected Digital output port (RGB888) on R-Car Starter Kit . The HDMI structures. R-CarH3/M3 CN49 DR[7..0] TX2+ TX2- DG[7..0] TX1+... -
Page 25: Flat Panel
Preliminary Hardware Manual 4.14. FLAT PANEL This board equipped connectors for VDS PANEL and FPD-LINK. Those are connected LVDS output on R-Car Starter Kit and select the output by setting. - CN7 : LVDS PANEL - CN40 : FPD-LINK It controlled by U97 P16 (LVDSvsFPDL) signal to switch picture output. - P16[H] : LVDS PANEL - P16[L] : FPD-LINK CN9 connector for LVDS PANEL DDC and CN8 for Power. -
Page 26: Audio
Preliminary Hardware Manual 4.15. AUDIO φ3.5mini jacks This board equipped with a 24-Bit 6ch IN / 8ch OUT AUDIO CODEC (PCM3168A) and there are three input and φ3.5mini jack x4、RCA jack x4 output. The TDM mode SSI between CODEC and R-Car Starter Kit connection. The SSI3,4 interface is sheared with AUDIOとAUDIO AMP, it cannot use simultaneously. -
Page 27: Audio Amp
Preliminary Hardware Manual 4.16. AUDIO AMP This board equipped with a (60pin) for audio amp option board. connector The SSI3,4 interface is sheared with AUDIOとAUDIO AMP, it cannot use simultaneously. It controlled by GP6_21 to switch connection. ・GP6_21[H]：AUDIO ・GP6_21[L]：AUDIO AMP The AUDIO AMP structure. -
Page 28: Can
Preliminary Hardware Manual 4.17. CAN This board equipped with a transceiver (TCAN332GDCNT) and two connector (3pin). There are the switch (SW2) to terminate register for each channel. - SW2[ON] : Enable terminate register - SW2[OFF] : Disable terminate register The CAN structure. R-CarH3/M3 CN17 CAN0_TX... -
Page 29: Most
Preliminary Hardware Manual 4.18. MOST This board could have equipped with a MOST function to install option board(TBD) to connect CN22 which allocate back of this board. MLB_SIG, MLB_DAT signal of MOST GPS (U44) RXD, TXD signal can switch the It switch this function by the register install status. -
Page 30: Gps
Preliminary Hardware Manual 4.19. GPS This board equipped with a MAX-M8Q-0) and external antenna connect to FAKRA connector (CN16). GPS device ( GPS(U44) RXD, TXD signal can switch the MLB_SIG, MLB_DAT signal of MOST signal It switches this function by the register install status. - (R660, R662 uninstall) +(R661, R663 install) : Enable GPS - (R660, R662 install) +(R661, R663 uninstall) -
Page 31: Radio
Preliminary Hardware Manual 4.20. RADIO This board equipped with a Digital Radio device (Si4689-A10-GM) and connect R-Car Starter Kit via SSI6 interface. The external antenna connects to SMA connector (CN42) and loop antenna connect to terminal block (CN43). The SSI signal is switch between the radio devices SSI signal and camera serial interface (CSI0) SSI signal to use, and it controlled by U11 P15(HDMI_Radio) to switch this function. -
Page 32: Axis Sensor
Preliminary Hardware Manual 4.21. 9 AXIS SENSOR This board equipped with a 9 axis sensor device (LSM9DS0) which is acceleration, gyroscope, electronic compass and the R-Car Starter Kit can read sensor value via I2C interface. The 9 axis sensor device structure. R-CarH3/M3 ACC_INT_G ACC_INT... -
Page 33: Ether
Preliminary Hardware Manual 4.22. ETHER There are 2 connectors (60pin) on this board to install Ether board (Option). This ETHER board install to CN38(CONTROL),CN39(DATA) at the BOTTOM sideof this board. The other connector structures. NOTE: Unconfirmed ETHER function. CN39 AVB_RXD[3..0] AVB_RXDV AVB_TXD[3..0] AVB_TXEN... -
Page 34: I2C
Preliminary Hardware Manual 4.23. I2C The table of I2C device list on this board Device Remarks I2C2 PCA9548ADB I2C MUX I2C2 TCA9539QPWRQ1 GPIO I2C2 TCA9539QPWRQ1 GPIO I2C2 CN38 QSH-030-01-L-D-A ETHER AVB I2C2 USB5534B-5000JZX USB 3.0 I2C2 CN37 FX23-60P AUDIO AMP I2C2 Si4689-A10-GM RADIO... - Page 35 Preliminary Hardware Manual The I2C(ch2) structure. R-CarH3/M3 CN38 I2C2_SDA BCM_I2C_SDA I2C2_SCL BCM_I2C_SCL I2C2_RST Ether AVB Connector SM_DAT SM_CLK USB5534B-5000JZX CN37 PAmp_SDA PAmp_SCL Power AMP Connector PCA9548ADB MOSI SCLK Si4689-A10-GM TCA9539QPWR HDMIoSDA HDMIoSCL TCA9539QPWR ADV7513BSWZ CN15 PCIe_SDA PCIe_SCL MiniPCI-Express Connector Disp_SDA Disp_SCL LVDS CONTROL Connector...
- Page 36 Preliminary Hardware Manual The I2C(ch4) structure. R-CarH3/M3 CN10 I2C4_SDA I2C4_SCL I2C4_RST HDMI_SDA HDMI_SCL A_SDA A_SCL CSI0 Connector CN11 EVd_SDA EVd_SCL B_SDA B_SCL CSI2 Connector PCA9548ADB CN22 MOST_SDA MOST_SCL MOST Connector TCA9539QPWR CN48 U107 RaspB_SDA RaspB_SCL CSI1 TCA9539QPWR Connector CN29 Cmos_SDA Cmos_SCL Connector Figure 4-23b : I2C I/F...
-
Page 37: Switch List
Preliminary Hardware Manual 5. SWITCH LIST The table of switch list on this board REF.No Function Remarks CAN Terminate Register enable／disable Default value: OFF ON→enable OFF→disable AUDIO input 1 GAIN setting Default value: OFF ON→+20db OFF→0db AUDIO input 2 GAIN setting Default value: OFF ON→+20db OFF→0db AUDIO input 3 GAIN setting... -
Page 38: Led List
Preliminary Hardware Manual 7. LED LIST The table of LED list on this board REF.No Color Details Remarks Illuminate when USB3.0 (CN2 port2 low) Green POWER ON Illuminate when USB3.0 (CN2 port1 up) Green POWER ON Illuminate when board POWER ON SSD_LED(CN5 M.2 connector ) LED1 Orange... -
Page 39: Conector List
Preliminary Hardware Manual 8. CONECTOR LIST The table of connector list on this board CN.No Function Connector Remarks Connect R-Car Starter kit 402-51501-51 USB 3.0 GSB311231HR Debug Serial 535676-5 10130616-067R2LF Only SBEV-RCAR-KF-M04 LVDS OUT DF14A-20P-1.25H(25) PANELPower S7B-PH-SM4-TB(LF)(SN) PANEL control 0530480710 CN10 FX23-60P Only SBEV-RCAR-KF-M04... -
Page 40: Cn1 : R-Car Starter Kit Connector
Preliminary Hardware Manual 8.1. CN1 : R-Car Starter kit CONNECTOR Pin No. Signal Remarks Pin No. Signal Remarks A001 A056 USB30_VBUS A002 CSI2_DA0p A057 A003 CSI2_DA0n A058 BCM_RS232_TXD A004 A059 BCM_RS232_RXD A005 A060 A006 A061 USB31_ID A007 CSI2_CLKAn A062 USB30_ID A008 CSI2_CLKAp A063... - Page 41 Preliminary Hardware Manual A051 A106 A052 BCM_SO A107 A053 A108 A054 A109 A055 USB31_VBUS A110 Table 8-1a : CN1 pin assignment (402-51501-51 : Ept) Pin No. Signal Remarks Pin No. Signal Remarks B001 B056 MLB_SIG *share B002 AVB_PHY_INT B057 MLB_DAT *share B003 AVB_RXD0...
- Page 42 Preliminary Hardware Manual B046 B101 B047 SD3_PWR_EN B102 B048 uVI_FRSYNCB B103 B049 B104 B050 PRESETOUTn_3 B105 B051 B106 B052 SD3_CLK B107 B053 B108 B054 HDMIoINT B109 B055 B110 Table 8-1b : CN1 pin assignment (402-51501-51: Ept) Pin No. Signal Remarks Pin No.
- Page 43 Preliminary Hardware Manual C041 C096 C042 C097 C043 C098 C044 C099 C045 C100 C046 C101 C047 C102 VI5_HSYNC C048 CLK24.576 C103 C049 C104 C050 SD3_DAT3 C105 C051 C106 C052 VLDO_SD3 C107 C053 VLDO_SD3 C108 C054 VLDO_SD3 C109 C055 VLDO_SD3 C110 Table 8-1c : CN1 pin assignment (402-51501-51 : Ept) Pin No.
- Page 44 Preliminary Hardware Manual D036 D091 D037 D092 D038 D093 D039 D094 D040 D095 D041 D096 D042 D097 DHSYNC D043 D098 DVSYNC D044 D099 DU_DISP D045 D100 D046 D101 DotCLK D047 D102 MLB_CLK D048 D103 D049 D104 D12V D050 VI5_VSYNC D105 D12V D051 D106...
-
Page 45: Cn2 : Usb 3.0
Preliminary Hardware Manual 8.2. CN2 : USB 3.0 Pin No. Signal Remarks Pin No. Signal Remarks PWR2 PWR1 USBDN_DM2 USBDN_DM1 USBDN_DP2 USBDN_DP1 USB_SSRXM_DN2 USB_SSRXM_DN1 USB_SSRXP_DN2 USB_SSRXP_DN1 USB_SSTXM_DN2 USB_SSTXM_DN1 USB_SSTXP_DN2 USB_SSTXP_DN1 Table 8-2 : CN2 pin assignment (GSB311231HR : Amphenol) 8.3. CN4 : SERIAL Pin No. -
Page 46: Cn5 : M2
Preliminary Hardware Manual 8.4. CN5 : M2 Pin No. Signal Remarks Pin No. Signal Remarks M2BE D3.3V D3.3V KEY.B SSD_LED D3.3V D3.3V D3.3V D3.3V SSDIND1 BDevSlp PCIE0_TX_M PCIE0_TX_P PCIE0_RX_M PCIE0_RX_P BPERST BClkReq PCIE0_CLK_N BPEWake PCIE0_CLK_P SUSCLK PCIe_SATA D3.3V D3.3V D3.3V USB30_used Table 8-4 : CN5 pin (10130616-067R2LF:FCI 製) -
Page 47: Cn7 : Lvds Out
Preliminary Hardware Manual 8.5. CN7 : LVDS OUT Pin No. Signal Remarks D3.3V D3.3V EL_D0n EL_D0p EL_D1n EL_D1p EL_D2n EL_D2p EL_CLKn EL_CLKp EL_D3n EL_D3p DISP_CONTRAST PWM4 Table 8-5 : CN7 pin assignment (DF14A-20P-1.25H(25) : Hirose) 8.6. CN8 : PANEL POWER Pin No. -
Page 48: Cn9 : Panel Control
Preliminary Hardware Manual 8.7. CN9 : PANEL CONTROL Pin No. Signal Remarks Disp_Irq Disp_SDA Disp_SCL Table 8-7 : CN9 pin assignment (0530480710 : Molex) 8.8. CN10 : CSI Pin No. Signal Remarks Pin No. Signal Remarks CSI0_DA3n CSI0_DA3p uVI_FRSYNCA CSI0_DA2n CSI0_DA2p TP10 CSI0_CLKAn... -
Page 49: Cn11 : Csi
Preliminary Hardware Manual 8.9. CN11 : CSI Pin No. Signal Remarks Pin No. Signal Remarks CSI2_DA3n CSI2_DA3p uVI_FRSYNCB CSI2_DA2n CSI2_DA2p TP11 TP12 CSI2_CLKAn CSI2_CLKAp CSI2_DA1n EVd_SCL CSI2_DA1p EVd_SDA CSI2_DA0n CSI2_DA0p BCM_SO HDMI_CS_B B_LED BCM_CLK BCM_SI B_SDA B_SCL IrqExtB nVRST Table 8-9 : CN11 pin assignment (FX23-60P-0.5SV15 : Hirose) -
Page 50: Cn12 : Line
Preliminary Hardware Manual 8.10. CN12 : LINE Pin No. Signal Remarks Table 8-10 : CN12 pin assignment (PJRAS4X2U01X : Switchcraft) 8.11. CN13 : USB 2.0 Pin No. Signal Remarks VBUS USB20_DM0 USB20_DP0 Table 8-11 : CN13 pin assignment (ZX62D-AB-5P8(30) : Hirose) -
Page 51: Cn15 : Mini Pci-Express
Preliminary Hardware Manual 8.12. CN15 : Mini PCI-Express Pin No. Signal Remarks Pin No. Signal Remarks MPCIeWake MPCI3.3V MiniPCIe1.5V MiniPCIeClkRQ umPWR umDATA PCIE1_CN_CLK_M umCLK PCIE1_CN_CLK_P umRST umVPP MiniPCIeW_DSBL PRESETOUTn_3 PCIE1_RX_M MPCI3.3V PCIE1_RX_P MiniPCIe1.5V PCIe_SCL PCIE1_TX_M PCIe_SDA PCIE1_TX_P MPCI3.3V MPCI3.3V MiniPCIe1.5V MPCI3.3V Table 8-12 : CN15 pin assignment (2041119-1 : AMP) 8.13. -
Page 52: Cn17 : Can
Preliminary Hardware Manual 8.14. CN17 : CAN Pin No. Signal Remarks CAN0H CAN0L Table 8-14 : CN17 pin assignment (S3B-PH-SM4-TB(LF)(SN) : JST) 8.15. CN18 : CAN Pin No. Signal Remarks CAN1H CAN1L Table 8-15 : CN18 pin assignment (S3B-PH-SM4-TB(LF)(SN) : JST) 8.16. -
Page 53: Cn23 : Board Power
Preliminary Hardware Manual 8.17. CN23 : BOARD POWER Pin No. Signal Remarks Table 8-17 : CN23 pin assignment (2DC-G213-D42:SIGRATRON) 8.18. CN28 : MIC Pin No. Signal Remarks Right_In Left_In Right_In Left_In Right_In Left_In Table 8-18 : CN28 pin assignment (STX-4335-5BGP-S1 : Kycon) -
Page 54: Cn29 : Video In
Preliminary Hardware Manual 8.19. CN29 : VIDEO IN Pin No. Signal Remarks D3.3V Cmos_SCL Cmos_SDA VI5_VSYNC VI5_HSYNC VI5_CLK Cmos_Clk24 VI5_DATA7 VI5_DATA6 VI5_DATA5 VI5_DATA4 VI5_DATA3 VI5_DATA2 VI5_DATA1 VI5_DATA0 Cmos_RST Cmos_PWDN Table 8-19 : CN29 pin assignment (5535512-2 : TE) 8.20. CN32 : HEADPHONE Pin No. -
Page 55: Cn33 : Headphone
Preliminary Hardware Manual 8.21. CN33 : HEADPHONE Pin No. Signal Remarks HPR3 HPL3 HPR4 HPL4 Table 8-21 : CN33pin assignment (STX-4235-3/3-N : Kycon) 8.22. CN37 : AUDIO AMP Pin No. Signal Remarks Pin No. Signal Remarks PAmp_RST PAmp_D12V PAmp_D12V PAmp_D12V PAmp_D12V PAmp_D12V PAmp_D12V... -
Page 56: Cn38 : Ether Control
Preliminary Hardware Manual 8.23. CN38 : ETHER CONTROL Pin No. Signal Remarks Pin No. Signal Remarks BCM_SS BCM_SO BCM_SI BCM_SCK BCM_RSTn BR_D12V BR_D12V KSZ_RSTn BR_D12V BR_D12V BCM_RS232_RXD BR_D12V BR_D12V BCM_RS232_TXD BCM_I2C_SDA BCM_I2C_SCL Table 8-23 : CN38 pin assignment (QSH-030-01-L-D-A : Samtec) -
Page 57: Cn39 : Ether Avb
Preliminary Hardware Manual 8.24. CN39 : ETHER AVB Pin No. Signal Remarks Pin No. Signal Remarks AVB_RXDV AVB_RXD3 AVB_RXD2 AVB_RXD1 AVB_RXD0 AVB_GTXCLK AVB_TXEN AVB_TXD3 AVB_TXD2 AVB_TXD1 AVB_TXD0 AVB_RXCLK PRESETOUTn_3 AVB_MDIO AVB_MDC D3.3V AVB_PHY_INT D3.3V DP1.2V EhVDDIO DP1.2V EhVDDIO Table 8-24 : CN39 pin assignment (QSH-030-01-L-D-A : Samtec) 8.25. -
Page 58: Cn42 : Radio
Preliminary Hardware Manual 8.26. CN42 : RADIO Pin No. Signal Remarks RF_IN Table 8-26 :CN42 pin assignment (CONSMA001-G:LINX) 8.27. CN43 : RADIO Pin No. Signal Remarks LOOPP LOOPN Table 8-27 : CN43 pin assignment (PTSA15235Z : Phoenix Contact) 8.28. CN45 : WIFI/BLUETOOTH Pin No. -
Page 59: Cn46 : Wifi
Preliminary Hardware Manual 8.29. CN46 : WIFI Pin No. Signal Remarks RF_ANT2 Table 8-29 : CN46 pin assignment (B040420A:YRT) 8.30. CN47 : SD CARD Pin No. Signal Remarks L_D3 L_CMD L_CLK L_D0 L_D1 L_D2 SD3_CD SD3_WP Table 8-30 : CN47 pin assignment (693063020911 : Wurth) -
Page 60: Cn48 : Csi
Preliminary Hardware Manual 8.31. CN48 : CSI Pin No. Signal Remarks Pin No. Signal Remarks CSI1_D0n CSI1_D0p CSI1_D1n CSI1_D1p CSI1_CLKn CSI1_CLKp RaspB_IO0 RaspB_IO1 RaspB_SCL RaspB_SDA D3.3V Table 8-31 : CN48 pin assignment (1-1734248-5 : TE) 8.32. CN49 : HDMI Pin No. Signal Remarks TX2+... -
Page 61: Cn52 : Sim
Preliminary Hardware Manual 8.33. CN52 : SIM Pin No. Signal Remarks umPWR umRST umCLK umVPP umDATA Table 8-33 : CN52 pin assignment (78800-0001 : Molex) -
Page 62: Board External View
Preliminary Hardware Manual 9. BOARD EXTERNAL VIEW Board external view Figure 9a : PCB TOP side... - Page 63 Preliminary Hardware Manual Figure 9b : PCB BOTTOM side...
