Summary of Contents for Hyvision MV179
- Page 2 FCC NOTE :This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
-
Page 3: Table Of Contents
Table of Contents Please read the cautions carefully before using this product Product features Installation of the product Names and operation of control buttons Selection and operation of the OSD menu Menu Timing guide Product specifications Before asking for repair service, please check below... -
Page 4: Please Read The Cautions Carefully Before Using This Product
Please read the cautions carefully before using this product Do not scratch the screen of the The interior part of the monitor is Take care of the LCD monitor so LCD monitor with sharp composed of electric elements. If that it is not damaged by the materials such as nails and the monitor is broken, do not try to external impact. -
Page 5: Product Features
Product features Introduction Thank you for buying our TFT LCD monitor. Our monitor is a high-resolution monitor that has features of electromagnetic wave blocking, reduction in electricity consumption, and efficient use of space. In view of the fact that this user's manual is prepared for helping you to adequately use the product, it is recommendable to read the user's manual before using the product. -
Page 8: Selection And Operation Of The Osd Menu
Selection and operation of the OSD menu You can select the OSD menu in the OSD window using all the control buttons at the bottom of the screen. To change the current settings or adjust them for the desired settings, follow the following steps. MENU SELECT (Select the... -
Page 9: Menu
Menu 1. Color menu 2. Image menu If you press the menu button, the following screen appears. Main menu screen Menu selection screen Submenu screen ï\é¶Window Current screen status Horizontal position Contrast Adjusts the horizontal position Adjusts contrast. (0 ~ 100) of the current screen. - Page 10 Menu 3. Function menu 4. OSD menu Auto-Adjust Language Configures Auto-Position, Auto- Configures the language used in the OSD menu. The languages are as follows: Phase, Auto-Clock and Auto- English, German, French, Italian, Spanish, Color at the same time. Chinese Simplified, Chinese Traditional and Japanese.
- Page 11 Menu 5. Miscellaneous Description of operation messages Cable not connected Cable not connected It appears when there is no input signal from the computer. If the message disappears, the monitor status is changed to energy-saving mode. Signal out of range Signal out of range It appears when the input signal is out of range.
-
Page 12: Timing Guide
Timing guide Timing guide This product is a multi-frequency monitor. It functions in horizontal frequencies from 30 kHz to 80 kHz and vertical frequencies from 56 Hz to 75 Hz. Due to its design based on microprocessor, it offers the functions of automatic synchronization and automatic size. -
Page 13: Product Specifications
Product specifications Product specifications 17" 14'' diagonal viewable screen TFT (Thin Type Film Transistor). Active Matrix Panel 0.264 mm (H) x 0.264 (V). R. G. B. vertical stripe. pixel pitch Surface Color 16,194.277 colors. Display anti-glare coating. Condition Angle of view 150°/130°... -
Page 14: Before Asking For Repair Service, Please Check Below
Before asking for repair service, please check below Before asking for repair service, please check below You can contact our technical services or selling agency if you want to ask for repair service. Check the following before you ask for repair service. Screen shows no image.
