Page 1: Table Of Contents
Table of Contents Please read the cautions carefully before using this product Product features Installation of the product Names and operation of control buttons Selection and operation of the OSD menu Menu Timing guide Product specifications Troubleshooting... -
Page 2: Please Read The Cautions Carefully Before Using This Product
Please read the cautions carefully before using this product Product features Introduction Thank you for buying our TFT LCD monitor. Our monitor is a high-resolution monitor that has features of electromagnetic wave blocking, reduction in electricity consumption, and efficient use of space. In view of the fact that this user's manual is prepared for helping you to adequately use the product, it is recommendable to read the user's manual Do not scratch the screen of the... -
Page 3: Installation Of The Product
Installation of the product Installation of the product USB installation (option) Checking the product Please check if the product contains the following items. If there are some 1. Connect the monitor to the PC with signal cable and turn on the PC. items missing, please contact the technical services. -
Page 4: Names And Operation Of Control Buttons
Names and operation of control buttons Selection and operation of the OSD menu Names and operation of control buttons This monitor has several control buttons. They can be used according to the user preference. Function of the buttons Power button ( If you press the power button, the indicator lamp is turned on, and the operation of the monitor is initiated. - Page 5 Menu Function Menu Function Picture Picture OSD H Posi Brightness OSD V Posi Contrast OSD Timer 10 SEC H Position Transparency 25 % V Position Phase Clock Auto Adjust OSD horizontal position Adjusts the horizontal position of the OSD menu screen. 0 ~ 100 Brightness_ Adjusts brightness.
-
Page 6: Timing Guide
Timing guide Menu Function Timing guide This product is a multi-frequency monitor. Auto Adjust It functions in horizontal frequencies from 30 kHz to 80 kHz and vertical Auto Adjust frequencies from 56 Hz to 75 Hz. Due to its design based on microprocessor, it offers the functions of automatic synchronization and automatic size. - Page 7 Product specifications Troubleshooting Product specifications No power. 19'' diagonal viewable screen TFT (Thin Film - Flip the power switch ON. The Power LED turns on. Type Transistor). Active Matrix Panel 0.294 mm (H) - Make sure AC power cord is securely connected to the power jack and to x 0.294 (V).
- Page 8 Troubleshooting...
- Page 9 FCC NOTE :This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
