INSTRUCTIONS FOR USING THE MOTION PRO #08-0134
The Motion Pro torque adaptor wrench is designed to be used with a torque wrench to accurately
tighten the cylinder base nuts on two-stroke engines that you cannot reach with a socket wrench.
How to use the Torque Adaptor Wrench:
When you mount the adaptor onto a torque wrench, it effectively lengthens the torque wrench. Therefore,
the torque value set on the torque wrench will not be the actual torque that you apply to the fastener.
Before using the torque adaptor, you must recalculate the torque specification listed in the engine's
service manual. To recalculate your torque wrench when using the Motion Pro adaptor, use the extension
formula included with these instructions.
_____________________________________________________________________________________
After recalculating the torque specification, write it down here for future reference.
MODEL
_____________________________________________________________________________________________________
To make conversions from one form to another, use the following torque conversion table:
MULTIPLY
foot-pounds (ft-lb.)
foot-pounds
foot-pounds
inch-pounds (in.-lb.)
inch-pounds
inch-pounds
kilogram-meters (kg-m)
kilogram-meters
kilogram-meters
Newton-meters (N-m)
Newton-meters
Newton-meters
MOTION PRO, INC.
PH. (650) 594-9600
TORQUE ADAPTOR WRENCH
TORQUE ADAPTOR CORRECTION CHART
0.01152
0.08333
- OVER -
867 AMERICAN STREET
Ft.-lb.
BY
1.356
0.1383
12.0
0.1130
7.233
86.79
9.806
0.7375
8.851
0.1020
SAN CARLOS, CA. 94070
FAX (650) 594-9610
N-m
TO OBTAIN
Newton-meters
kilogram-meters
inch-pounds
kilogram-meters
Newton-meters
foot-pounds
foot-pounds
inch-pounds
Newton-meters
foot-pounds
inch-pounds
kilogram-meters
