74120
Please keep this instruction sheet for future reference,
as it contains important information.
Adult assembly is required.
Requires four "C" (LR14) alkaline batteries for the mobile
and two "AA" (LR6) alkaline batteries for the remote control
(batteries not included).
Tool required for battery installation:
Phillips screwdriver (not included).
www.fisher-price.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Fisher-Price 74120
Summary of Contents for Fisher-Price 74120
- Page 1 74120 Please keep this instruction sheet for future reference, as it contains important information. Adult assembly is required. Requires four “C” (LR14) alkaline batteries for the mobile and two “AA” (LR6) alkaline batteries for the remote control (batteries not included).
-
Page 2: Consumer Information
Consumer Information WARNING Possible entanglement injury. • Keep out of baby’s reach. • Remove mobile from crib or playpen when baby begins to push up on hands and knees. • This product will not attach to all crib designs. Do not add additional strings or straps to attach to crib or playpen. - Page 3 Parts Upper Arm Spiral Remote Control Star Retainer Lower Arm Clamp 3 Soft Toys #6 x ½" Screw - 1 Shown Actual Size CAUTION This toy contains small parts in its unassembled state. Adult assembly is required.
-
Page 4: Battery Installation
Battery Installation Battery Compartment Door Mobile • Locate the battery compartment door on the mobile’s lower arm. • Loosen the screws in the battery compartment door with a Phillips screwdriver. Remove the battery compartment door. • Insert four “C” (LR14) alkaline batteries. •... - Page 5 Battery Installation Battery Compartment Door Remote Control • Locate the battery compartment door on the back of the remote control. • Loosen the screw in the battery compartment door with a Phillips screwdriver. Remove the battery compartment door. • Insert two “AA” (LR6) alkaline batteries, as indicated inside the battery compartment.
-
Page 6: Battery Safety Information
• If removable, rechargeable batteries are used, they are only to be charged under adult supervision. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A. ©2007 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc. - Page 7 Assembly Upper Arm Lower Arm • Fit the upper arm into in the lower arm. Star Retainer Battery Compartment • Insert the star retainer into the hole in the lower arm on the side opposite the battery compartment. • Insert the #6 x ½" screw into the lower arm as shown. Tighten the screw with a Phillips screwdriver.
- Page 8 Assembly Wide Clamp Upper Arm Narrow- Clamp Spiral • Note that the spiral has a wide clamp on one end and a narrow clamp on the other end. • “Snap” the spiral wide clamp onto the post above the star on the upper arm. •...
- Page 9 Power/Volume Switch • The switch has three positions: off ; on with low volume volume and on with high • Slide the power/volume switch to the off position when not in use. Light Select Button • Press the button to choose from four different light modes: 1 Twinkling lights around baby's room 2 Glowing star light gently fading in and out 3 Twinkling and glowing lights...
- Page 10 IMPORTANT! • In the unlikely event that use of the remote interferes with normal use of other remote controlled equipment, such as televisions and stereos, or use of other electric or battery powered appliances interfere with operation of the mobile, do not use both appliances at the same time.
- Page 11 Care • Wipe the toy with a clean cloth dampened with a mild soap and water solution. • Do not immerse the toy. Protect the environment by not disposing of this product with household waste (2002/96/EC). Check your local authority for recycling advice and facilities (Europe only).
-
Page 12: Fcc Statement (United States Only)
FCC Statement (United States Only) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
