- Page 1 OBU User Manual In case of additional questions contact Satellic Customer Support on 00800/72 83 55 42 (From Belgium and neighboring countries) +32 2 416 0 416 (From any location) Calls from mobile networks may be surcharged according to the terms and conditions of your mobile service operator.
-
Page 2: Table Of Contents
Basic Safety Instructions ................17 OBU – FAQ ....................18 Satellic NV • Airport Plaza • Leonardo Da Vincilaan 19 A Bus 4• B-1831 Diegem • support@satellic.be • www.satellic.be Customer Support: T 00800-72 83 55 42 or • F +32 2 416 02 99... -
Page 3: List Of Figures
On Board Unit Light Emitting Diode Satellic NV • Airport Plaza • Leonardo Da Vincilaan 19 A Bus 4• B-1831 Diegem • support@satellic.be • www.satellic.be Customer Support: T 00800-72 83 55 42 or • F +32 2 416 02 99... -
Page 4: Introduction
On Board Unit (OBU) in Belgium. This regulation applies on motorways and on a number of regional and municipal roads. To detect whether a toll road is used, an On Board Unit (OBU) is installed in the vehicle. The OBU is mandatory in order to comply with the toll regulations of the Belgian regional authorities. -
Page 5: Controls
The OBU has six buttons: “button ok” (4), “button up, down, left, right” (3) and “button back” (5). The red LED (1) and the green LED (2) are optical indicators for the status of the OBU. The “display” (6) is the main optical indicator for the OBUs status. - Page 6 The display informs the road user about the journey on Belgian roads. Satellic NV • Airport Plaza • Leonardo Da Vincilaan 19 A Bus 4• B-1831 Diegem • support@satellic.be • www.satellic.be Customer Support: T 00800-72 83 55 42 or • F +32 2 416 02 99...
-
Page 7: Operation
Starting… After successful start-up: default screen 3.1.2 OBU LED A red LED is shown during the booting process. The green LED will switch on if the OBU is ready for toll collection within approximately 10 minutes. 3.1.3 OBU SOUNDS No sound during the start-up process. -
Page 8: While Travelling With The Obu
Figure 2: Default Screen Toll > 0 Satellic NV • Airport Plaza • Leonardo Da Vincilaan 19 A Bus 4• B-1831 Diegem • support@satellic.be • www.satellic.be Customer Support: T 00800-72 83 55 42 or • F +32 2 416 02 99... -
Page 9: Figure 3: Default Screen Toll = 0
Figure 4: Default Screen Toll-free Satellic NV • Airport Plaza • Leonardo Da Vincilaan 19 A Bus 4• B-1831 Diegem • support@satellic.be • www.satellic.be Customer Support: T 00800-72 83 55 42 or • F +32 2 416 02 99... -
Page 10: Figure 5: Screen "Obu Locked
Line 2: lock reason Figure 5: Screen "OBU Locked" Satellic NV • Airport Plaza • Leonardo Da Vincilaan 19 A Bus 4• B-1831 Diegem • support@satellic.be • www.satellic.be Customer Support: T 00800-72 83 55 42 or • F +32 2 416 02 99... -
Page 11: Figure 6: Screen "Top-Up
Satellic NV • Airport Plaza • Leonardo Da Vincilaan 19 A Bus 4• B-1831 Diegem • support@satellic.be • www.satellic.be Customer Support: T 00800-72 83 55 42 or • F +32 2 416 02 99... -
Page 12: Figure 8: Screen "Wake-Up Movement
✓ Supporting Screen – “Error Screen” Errors are shown by the OBU as a response to internal errors. Error screens can only be overlaid by menu screens to let the user check OBU data in the menu. All error screens show the following information: •... -
Page 13: Figure 9: Screen "Errors
Figure 9: Screen "Errors" ✓ Supporting Screen – “Warning Screens” Warning screens are shown by the OBU as a response to certain types of behaviour of the OBU, which can be corrected by the user. All warning screens show the following information: •... - Page 14 III. Menu Screen The OBU provides a menu with user information. In order to enter the menu screen the user has to hold the navigation button. The information in the menu screen is not selectable or changeable, except for the language. The Menu Screen is always accessible even if overlaying screens are displayed.
-
Page 15: Obu Led
The menu screen has no influence on the LEDs so the LED colour could be green as well as red. Satellic NV • Airport Plaza • Leonardo Da Vincilaan 19 A Bus 4• B-1831 Diegem • support@satellic.be • www.satellic.be Customer Support: T 00800-72 83 55 42 or • F +32 2 416 02 99... -
Page 16: Obu Sounds
No sound during the menu screen. Satellic NV • Airport Plaza • Leonardo Da Vincilaan 19 A Bus 4• B-1831 Diegem • support@satellic.be • www.satellic.be Customer Support: T 00800-72 83 55 42 or • F +32 2 416 02 99... -
Page 17: Basic Safety Instructions
(= 00800-SATELLIC) from within Belgium and its neighbouring countries. From the rest of Europe, dial +3224160416. Satellic NV • Airport Plaza • Leonardo Da Vincilaan 19 A Bus 4• B-1831 Diegem • support@satellic.be • www.satellic.be Customer Support: T 00800-72 83 55 42 or • F +32 2 416 02 99... -
Page 18: Obu - Faq
Satellic NV • Airport Plaza • Leonardo Da Vincilaan 19 A Bus 4• B-1831 Diegem • support@satellic.be • www.satellic.be Customer Support: T 00800-72 83 55 42 or • F +32 2 416 02 99...
