Summary of Contents for Funsnap iDol
- Page 1 Drone User Manual...
-
Page 2: Table Of Contents
Catalogue Introduction………………………………………………………………………… 5 Package……………………………………………………………………………… 5 Main Components………………………………………………………………… 6 Flight Preparation………………………………………………………………… 6 1) Charging Battery……………………………………………………………………………6 2) Battery Installation and Removal …………………………………………………8 Download APP……………………………………………………………………… 9 Preflight Check………………………………………………………………………9 Flight Environment Requirements……………………………………………10 Basic Use…………………………………………………………………………… 11 LED Status Indicator ………………………………………………………………………11 Power On/Power Off ………………………………………………………………………12 Connecting to Drone ………………………………………………………………………12 Horizon Calibration ………………………………………………………………………... - Page 3 Local Gallery……………………………………………………………………………………25 Controller ………………………………………………………………………… 26 Controller Overview…………………………………………………………………………26 Preparation before Operation…………………………………………………27 Battery and Power…………………………………………………………………27 Power On ……………………………………………………………………………27 Binding……………………………………………………………………………… 28 Horizontal Calibration……………………………………………………………28 Compass Calibration ……………………………………………………………29 How to use the basic functions……………………………………………… 30 Left Stick…………………………………………………………………………………………30 Right Stick ………………………………………………………………………………………30 Takeoff and Landing ………………………………………………………………………30 Replace Propeller …………………………………………………………………32 Battery Disposal …………………………………………………………………...
- Page 4 Power Charger Specification……………………………………………………………37 Controller Specification …………………………………………………………………37 Warranty ……………………………………………………………………………37 RoHS………………………………………………………………………………… 38...
-
Page 5: Introduction
Introduction The iDol drone is portable and easy to use, the body is collapsible and compact and is a fully functional aircraft. As well as a remote control, the user can control flight and video/picture through an app or supported controller. -
Page 6: Main Components
It is recommended that you first check the package contents and read the Disclaimer, safety information, battery safety instructions and quick start guide in order to get a basic understanding of the product. For more detailed information, read the user manual. Main Components Propeller Drone Status Indicator/Power... -
Page 7: Flight Preparation
Flight Preparation 1) Charging Battery Align the battery with the charger slot, then insert the battery into the charger, making sure the battery connects correctly. Connect the power adapter and start charging. Solid red light: No battery inserted or the battery is not connected correctly. -
Page 8: Battery Installation And Removal
requirements in the Battery Safety Instructions. When the charger detect the battery temperature is outside of the normal operating range (5°C to 40°C), it will stop charging until the temperature returns to normal. 2) Battery Installation and Removal Installing the Battery Ensure that battery is being inserted into the aircraft in the right direction. -
Page 9: Download App
Download APP Search for Funsnap in the app store or scan the QR code to download the FUNSNAP app from the APP Store. Android FUNSNAP requires iOS 9.0 and above or Android 5.0 or higher. This manual is subject to change without notice. Please visit www.fun-snap.com... -
Page 10: Flight Environment Requirements
Flight Environment Requirements Outdoors 1、Do not fly in bad weather such as rain, snow or strong winds.Keep the Drone in line of sight at all times. Keep away from obstacles such as high-voltage lines, trees, dense crowds and water. 2、Fly in a clear open area, do not fly near buildings and maintain a good distance from tall buildings to avoid GPS issues. -
Page 11: Basic Use
Basic Use LED Status Indicator The tail of the drone has a status indicator that gives various information about the state of the drone. The indicator above the camera is a photo/video indicator that shows the camera’ s mode. Please refer to the table below for information on the status indicators: Color &... -
Page 12: Power On/Power Off
Power On/Power Off Press and hold the power key for 3 seconds. When the iDol powers on the power indicator light will turn green. The status indicator below the power switch will also turn green. Press and hold the power key for 3 seconds. Once the status and power indicators go out let go of the power key. -
Page 13: Horizon Calibration
Horizon Calibration Unfold the drone, place it on a horizontal surface and turn it on. Connect to the APP and navigate to the APP ’ s settings page, select “ Sensor Calibration”, then “Level Calibration” and touch “start”. The status indicator will flash quickly for 5 seconds, after which the APP will display “successful calibration”. - Page 14 1、Rotate the drone horizontally 4 times. When the status indicator flashes twice go to the next step. 2、Rotate the aircraft as if doing a roll 4 times. When the status indicator flashes again the calibration is complete. Precautions: Before flying a new drone, or if the flight is more than 100km away from the last flight location, please calibrate the compass before takeoff.
-
Page 15: One Button Takeoff/Landing
If the calibration failed, restart the drone and repeat the above steps. One Button Takeoff/Landing Once the aircraft is turned on, place it horizontally on the ground and connect it to the APP. Touch the icon, the APP will display “Confirm Takeoff?”... - Page 16 The control on the right side of the screen controls forward, back, left and right. Forward, Back, Left, Right: When AFM is active tilting the device forward and back will control the forward and back motions of the drone. Tilting the device left or right will move the drone left and right.
-
Page 17: App
APP Overview The FUNSNAP App is a companion app developed specifically for iDol. Users can use the FUNSNAP App instead of the remote control to control the flight and shooting pictures/video. It can also share the photos and videos directly to social networks. - Page 18 APP Control Interface The FUNSNAP APP s control interface integrates status information and function controls required for flight and taking pictures/video. 1. Return To Main Screen 11. Album 2. Camera Up 12. Current Height, Distance And Speed 3. Camera Down 13.
- Page 19 1、Return to Main Screen Return to the main screen. 2、Camera Up Move up the camera lens. 3、Camera Down Move down the camera lens. 4、 Auto Return Home Taking-off while GPS signal is good, tap Taking-off while GPS signal is good, tap drone will automatically drone will automatically return to the takeoff point.
- Page 20 Turn on smart follow and select the object need to be followed, the drone will track on heading, drone stay hover, and rotate head to let camera focus on object. * Operating distance: within 1.5 meters, between the camera and object. ②...
- Page 21 7、 Settings to enter into flight setting page Settings ① Fast/Slow Gear Fast and slow speed control Swith bar. ② Ultrasonic Wave This is default to be turn on. But when it flies above like water surface, thick carpet, foam and snowfield, we suggest you turn the positioning off. ③...
- Page 22 ⑥ Electronic Fence Electronic Fence ensure the drone flying in the safe area. 8、Real-Time Function When smart Gravity Mode is turned on, this area will display the corresponding icon according to the special function clicking icon will end the special function，and icon disappear. 9、Take photo to take a picture.
- Page 23 Display current capacity of the battery. Note: If the battery level drops below 7% while in flight, the drone will enforce landing automatically. 16、 SD Card Display current free space of the SD card. 17、 GPS Signal Strength Display the current GPS signal strength. 18、...
-
Page 24: Media Library
Media Library Real time Gallery Touch the icon located at the Lower right corner of the main interface to enter the Real time Gallery. When the mobile device and aircraft are linked, you can view or download HD video or pictures. 24th... -
Page 25: Local Gallery
Local Gallery When the mobile device and aircraft are not linked you can view local videos or photos that have been downloaded previously. The content will be arranged in chronological order, from the newest to oldest. Select the video/photo you wish to download, then touch download to transfer it to your mobile device. -
Page 26: Controller
Controller Controller Overview The iDol controller is part of a new generation of transmission systems, which are easy to operate and control. 1、Left Stick 5、Status Indicator 8、Phone Holder 2、Takeoff Key 6、Auto Return Home 9、Fast/Slow Gear 3、Power Switch 7、Take photo/video 10、Camera Angle 4、Right Stick... -
Page 27: Preparation Before Operation
Preparation before Operation Battery and Power This remote controller is powered by 3 AAA Batteries. Place your new battery in the battery tray, make sure it faces the proper direction and ensuring it is properly secure to prevent movement. When the battery power gets low, the status LED will be flashing and there will has an audible low battery signal warning to alert you for the battery replacement. -
Page 28: Binding
Bind with drone Power on the remote controller firstly, and secondly power on the aircraft. Then quickly move the left stick up and down. When the left stick return to its default position, the status LED of the aircraft will change color to indicate that binding is successful while the app will display “Controller Connected”. -
Page 29: Compass Calibration
Compass Calibration Unfold the aircraft and place it on a horizontal surface away from any metal objects, then move the left and right sticks to the lower right at the same time for about 1 seconds to start the compass calibration. When the white LED single flash, please hold the aircraft horizontally and rotate it for 4 times. -
Page 30: How To Use The Basic Functions
How to use the basic functions Left/Right Stick Default setting: Left Mode. Left Mode Left Stick Right Stick Forward Forward Down Down Backward Backward Turn Left Turn Right Left Left Right Right Mode Left Stick Right Stick Forward Forward Down Down Backward Backward... - Page 31 Manual Takeoff: Move the left stick to the bottom left and the right stick to the bottom right at the same time to activate the manual takeoff during which the propellers already prepare well for a flight, then move the left stick upward for a takeoff. Manual Landing: Move the left stick downwards to control the descending until the aircraft reach the ground.
-
Page 32: Replace Propeller
Replace Propeller If one of the iDol ’ s propellers is damaged, the user can replace it in accordance with this instruction manual. 1、The iDol has 4 propellers, 2 rotate clockwise and 2 anticlockwise. The propellers that are diagonal to each other spin in the same direction. -
Page 33: Battery Disposal
Do not overtighten or loosen the screws. Each propeller requires 2 screws to be secure. Battery Disposal The battery may age over time and may not be used for other products. Do not continue to use the batter in the following cases, be sure to handle, recycle and dispose of the battery in accordance with local laws. -
Page 34: Storage & Transportation
Storage & Transportation Store the iDol in a suitable environment and do not place any heavy objects on the drone. Battery Storage Store the battery separately in a suitable environment to prevent the battery from over discharging. Battery storage temperature range: Short-term storage (less than one month): -10°C-40°C... -
Page 35: Appendix
4 、 After the firmware has successful been updated, the drone will automatically power off and restart. Note: Before updating the firmware make sure the iDol’ s battery is over 50% power. Once the update is complete check the firmware version via the FUNSAP app to confirm that the update has been successful. -
Page 36: Camera Specification
Camera Specifications Image Sensor: 1/3 inch CMOS; Lens: FOV 77.5°; 28mm (35mm format equivalent) ISO Range: 100-3200 Camera Pitch Range: -90° to 30° Max. Photo Resolution: 1920x1080 Video Resolution: 1080P, 1920×1080 @ 30 fps Storage Format: JPEG, MP4 Storage Capacity: 16 GB (including system files) Image Transmission Distance: 50 m Battery Specifications Max. -
Page 37: Power Charger Specification
Input : 12V ~2A MAX Output : 8.7V ~1.6A MAX Controller Specifications Operating Frequency: 2.4GHz Max. Transmission distance: 100m Operating Temperature Range: 5-40°C Operating Current/Voltage: 0.04A@4.5V Warranty Please visit FUNSNAP official website for the latest service information. Warranty Policy: http://www.funsnap.com/index.php/repair3/ 37th... -
Page 38: Rohs
RoHS 38th...
