RTscan RT920 User Manual

Hide thumbs Also See for RT920:

Advertisement

Quick Links

Download this manual See also: User Manual
RTSCAN TECHNOLOGY LIMITED
RT920 User Guide
1. Front view
LED Indicator
Touch screen
Key pad
Switch on: Hold power button until device switches on.
Switch off: Hold power button keep until the device shows the menu (as shown in
figure), select "Power off".
Switch off display: Press the power button once or set the auto sleep option at
"Setting -> Display -> Sleep"
Wake up: When the display is off, press power button once to turn on the display.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the RT920 and is the answer not in the manual?

Questions and answers

Related Manuals for RTscan RT920

Summary of Contents for RTscan RT920

  • Page 1 RTSCAN TECHNOLOGY LIMITED RT920 User Guide 1. Front view LED Indicator Touch screen Key pad Switch on: Hold power button until device switches on. Switch off: Hold power button keep until the device shows the menu (as shown in figure), select "Power off".
  • Page 2 RTSCAN TECHNOLOGY LIMITED 2. Side view 3.5 mm earphone port Mini USB port Power button Scan button Scan button User-defined button Volume control Reset button Barcode Scanner POGO pin...
  • Page 3 RTSCAN TECHNOLOGY LIMITED 3. Back view Camera Battery cover lock Loudspeaker TF Card slot SIM slot RFID card induction area U-style strap: remove by pulling the strap downward...
  • Page 4 RTSCAN TECHNOLOGY LIMITED...

  • Page 5: Removing Battery

    RTSCAN TECHNOLOGY LIMITED Removing battery Switch to ‘unlock’ position and use the strap buckle to raise the battery cover, as shown below. Battery installation Insert the battery into the battery compartment in the direction as shown in image right. Battery should sit tightly in the compartment when correctly installed.

  • Page 6: Battery Charging

    RTSCAN TECHNOLOGY LIMITED Battery charging Charge by DC power adapter To plug in the power adapter connector into the DC power port on the terminal device. Red color LED indicates battery is charging, green color LED indicates battery is fully charged. DC power adapter...

  • Page 7: Battery Operation

    Battery operation This device battery is polymer type battery, which should only be charged by using original RTscan power supply. Do not short the battery Do not store battery in hot, humid, or corrosive environment. Do not break or crack open the battery.
  • Page 8 RTSCAN TECHNOLOGY LIMITED INSTALLING THE SIM/TF CARD 1. Swing open the main battery cover clip by 90 degree; you can then remove the battery cover 2. Insert the SIM card or micro SD/TF card into their corresponding slots in the battery compartment Notice: You should gently push the SIM/TF card to the correct position without using excessive force.
  • Page 9 RTSCAN TECHNOLOGY LIMITED Check this to enable Check this to enable device as a USB USB debugging storage to PC Note: When you enable device as USB storage to PC, the flash memory of the device are map as a PC drive. At this point of time, you cannot install APK to the device.
  • Page 10 RTSCAN TECHNOLOGY LIMITED For any question, please contact: support@rtscan.net...
  • Page 11 RTSCAN TECHNOLOGY LIMITED FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
