RTSCAN TECHNOLOGY LIMITED
RT920 User Guide
1. Front view
LED Indicator
Touch screen
Key pad
Switch on: Hold power button until device switches on.
Switch off: Hold power button keep until the device shows the menu (as shown in
figure), select "Power off".
Switch off display : Press the power button once or set the auto sleep option at
"Setting -> Display -> Sleep"
Wake up: When the display is off, press power button once to turn on the display.
1
Advertisement
Summary of Contents for RTscan RT920
- Page 1 RTSCAN TECHNOLOGY LIMITED RT920 User Guide 1. Front view LED Indicator Touch screen Key pad Switch on: Hold power button until device switches on. Switch off: Hold power button keep until the device shows the menu (as shown in figure), select "Power off".
- Page 2 RTSCAN TECHNOLOGY LIMITED 2. Side view 3.5 mm earphone port Mini USB port Power button Scan button Scan button User-defined button Volume control Reset button Barcode Scanner POGO pin...
- Page 3 RTSCAN TECHNOLOGY LIMITED 3. Back view Camera Battery cover lock Loudspeaker TF Card slot SIM slot RFID card induction area U-style strap: remove by pulling the strap downward...
- Page 4 RTSCAN TECHNOLOGY LIMITED...
-
Page 5: Removing Battery
RTSCAN TECHNOLOGY LIMITED Removing battery Switch to ‘unlock’ position and use the strap buckle to raise the battery cover, as shown below. Battery installation Insert the battery into the battery compartment in the direction as shown in image right. Battery should sit tightly in the compartment when correctly installed. -
Page 6: Battery Charging
RTSCAN TECHNOLOGY LIMITED Battery charging Charge by DC power adapter To plug in the power adapter connector into the DC power port on the terminal device. Red color LED indicates battery is charging, green color LED indicates battery is fully charged. -
Page 7: Charging By Car Charger
DC port Battery operation This device battery is polymer type battery, which should only be charged by using original RTscan power supply. Do not short the battery Do not store battery in hot, humid, or corrosive environment. Do not break or crack open the battery. - Page 8 RTSCAN TECHNOLOGY LIMITED If battery is misshapen, or is found leaking, replace the battery immediately. Note : The battery should be charged for at least 8 hours before the first use. INSTALLING THE SIM/TF CARD 1. Swing open the main battery cover clip by 90 degrees, you can then remove the battery cover 2.
- Page 9 RTSCAN TECHNOLOGY LIMITED Select this option to enable / disable device as USB storage to the After the device connected to your PC,you could drag the top part of the screen down,to show the USB options. Select this option to...
- Page 10 RTSCAN TECHNOLOGY LIMITED Setting 1. Barcode scanning setting...
- Page 11 RTSCAN TECHNOLOGY LIMITED 2. NFC 3. WIFI(WLAN) / Bluetooth...
- Page 12 RTSCAN TECHNOLOGY LIMITED 4. Language Supports most of language worldwide, just as a Android mobile phone do.
- Page 13 RTSCAN TECHNOLOGY LIMITED More images view of the terminal :...
- Page 14 RTSCAN TECHNOLOGY LIMITED...
- Page 15 RTSCAN TECHNOLOGY LIMITED...
- Page 16 RTSCAN TECHNOLOGY LIMITED...
- Page 17 RTSCAN TECHNOLOGY LIMITED For any question, please contact: support@rtscan.net...
