I-2533
CAN to Fiber Multi-Mode Bridge
Quick Start Guide
1. Introduction
This quick start helps users to apply the I-2533 in users' applications
quickly. If users need the details of I-2533, please refer to the I-2533 user
manual. Users can free download it from the web site as follows or get it
from product CD (path: CAN/Converter/I-2533).
I-2533 Website
http://www.icpdas-usa.com/i_2533.html
I-2533 CAN to Fiber Multi-Mode Bridge
- QuickStart (Nov/2016)
ICP DAS USA, Inc. |
www.icpdas-usa.com
| 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717
1
Advertisement
Table of Contents
Related Manuals for ICPDAS I-2533
Summary of Contents for ICPDAS I-2533
- Page 1 This quick start helps users to apply the I-2533 in users’ applications quickly. If users need the details of I-2533, please refer to the I-2533 user manual. Users can free download it from the web site as follows or get it from product CD (path: CAN/Converter/I-2533).
-
Page 2: Hardware Installation
Before using I-2533, some things must be done. 1. Prepare one pair of I-2533. 2. Set the CAN baud rate of each I-2533 by using rotary switch. You can refer to the following table for details. (If you set the rotary switch to “A”, please use utility tool to do the configuration before.) - Page 3 3. Check the application structure, and determine if the terminator resistor is needed or not. You can find it at the position as follows. I-2533 CAN to Fiber Multi-Mode Bridge - QuickStart (Nov/2016) ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717...
- Page 4 4. Connect the fiber port of these I-2533, CAN port, power line and frame ground. The pin assignment and wire connection are as follows. When finished, run your application with the I-2533. I-2533 CAN to Fiber Multi-Mode Bridge - QuickStart (Nov/2016) ICP DAS USA, Inc.
- Page 5 COM port with the COM port of the I-2533. Users can find the communication cable in the product box. When connecting to the COM port of I-2533, the TxD pin of the cable is connected to the TXD pin of the COM port, RXD pin of the cable is connected to the RXD pin of the COM port, and GND pin of the cable is connected to the GND pin of the COM port.
- Page 6 ID 0x0 in the CAN 2.0A specification, fill the value “0” in both of “from” and “to” field and click “Add” button. I-2533 CAN to Fiber Multi-Mode Bridge - QuickStart (Nov/2016) ICP DAS USA, Inc. | www.icpdas-usa.com...
- Page 7 Step6. After finishing the configuration, set the rotary switch value to “0” ~ “A” and reboot the I-2533. The CAN message filter will be applied automatically in the value “0” ~ “A” of the rotary switch. The CAN baud rate set by utility is only appled when the rotary switch is set to “A”.
- Page 8 4. Dimension I-2533 CAN to Fiber Multi-Mode Bridge - QuickStart (Nov/2016) ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717...
