Jumbo Touch Panel Remote Operation Manual page 5

TV
VCR
DVD
SAT
AUDIO
AUX1
CBL
CD
1" to 2"
LEARNING FEATURE:
If the pre-programmed codes do not work for your device, use the LEARN feature to program
the functions using the original remote control.
DVR
We recommend using "AUX1" and "AUX2" for this feature as these two device buttons are
reserved to accommodate this feature without changing the existing device buttons that have
been set up. This remote control can be used to learn up to 57 functional keys.
AUX2
(NOTE: Some specific remote control signals may not work with this feature, such as those
that do not use an infrared signal.)
AUX1
1. Press the device button for which you would like to program functions.
2. Press and hold the LEARN button until the LED flashes repeatedly.
LEARN
3. Place the original remote control head-to-head to the Jumbo remote control on a flat surface.
The detector/signal emitter of the original remote control should be aiming at the detector/
signal emitter of the jumbo remote control. The distance between them should be about
1 to 2 inches.
Fig.2
4. Press the button (e.g."Stop"or " ") on the Jumbo remote control to which you would like to
assign a function. The LED will turn solid red.
5. Press and hold the button for the function that you would like the jumbo remote to learn from
the original remote until LED flashes for more than five times. This indicates the learning
process has been completed and you can release the button.
(NOTE: If the LED turns solid red after flashing 5 times, it indicates the learning process failed.
Repeat step 4).
6. If you want to continue programming other keys, repeat step 4.
7. Press LEARN to exit the learning mode. The LED will turn off.
LEARN
NOTE:
a. If you do not press any button within 30 seconds, the remote control will exit the
learning mode and go back to regular operation.
b. If you want to program different buttons for different devices, repeat step 1.
c. Within the same device, learned function is automatically replaced when a new
function is programmed on the same button.
d. Do not move the remote controls during learning process.
e. Avoid direct sunlight or strong fluorescent light. This could interfere with the learning
process.
f. Make sure fresh batteries are used in both remote controls.
5
