5.3 Printout

Printout may be initiated by pushing key "B" on the front panel. Correct communication settings must be made
under the "COM SETUP" before connection to printer.
Refer to section 3.5.1
The printed information depends on what selections have been made for display indication.
Refer to the explanations below:
> Flow >
Zero
A
If "Zero I Print" indication is toggled in the lower display, key B will initiate printout of the selected indication
on the upper row with time and date.
In the example above, "07.02.21 11:18 Flow
Subsequently, the following will be printed if corresponding indications is selected in the upper row:
"07.02.21 11:19 Sub-1 Total
"07.02.21 11:20 Sub-2 Total
"07.02.21 11:21 Master Total
Remote printout via terminals 41,42 will print Subtotal2 only, with automatic zeroset for each printout.
NOTE! Printout will only be executed once. No new printout can be executed until the totaliser value has been
incremented with 1 digit (Not indicating zero).
If any other indication than "Zero I Print" is indicated in the lower display row, that indicated information will
be printed. Refer to example below:
> Flow >
Sub1Tot 35.2 t
18-08-16
325tþ
Print
B
35.2 t"
18.3 t"
227.7 t"
The indication to the left will print:
325tþ
"07.02.21 11:19 Sub-1 Total
SYSTEM A2-H15 INSTRUCTION
D
C
325th" will be printed.
S44-H15E
35.2 t"
