Product Description

1.a

System Overview

The proLYTE analyzer is designed to make service and repair quick and easy. Modular construction is used
throughout the design. The basic operating system consists of a motor which drives the peristaltic pump.
The peristaltic pump draws the desired fluid through the system. A second motor drives the sample probe
through the solutions valve to aspirate the appropriate fluid for pumping: sample; standards; or air. The
sample detector in the fluid path communicates the position of the fluid in the line.
Please note that mechanical and electrical assemblies can be replaced. Follow the instructions in the
TROUBLESHOOTING SECTION to determine if assembly replacement is necessary. Refer to the
Replacement List in this section which lists replaceable assemblies, components, and appropriate part
numbers.
