Page 2
Sections Page Saxon Mini Dob features Setting up your Saxon Mini Dob Operating your Saxon Mini Dob Caring for and cleaning your telescope Saxon Mini Dob Acces sory Pack Saxon Mini Dob Specifications WARNING! • Do not use the telescope to look at the sun without an appropriate solar filter. Looking at or near the sun can result in irreversible eye damage.
Page 3
Saxon Mini Dob features Eyepiece Focuser Focusing wheel Primary Mirror – inside Secondary Tube end (Diagonal) Mirror – Optical tube inside Lock nut Base SAXON MINI DOB INSTRUCTION MANUAL | 1...
Page 4
Tube End. 3. Tighten the Lock Nut to ensure the telescope stays in position. It may be necessary to readjust the Lock Nut when accessories are added to, or removed from the optical tube. 2 | SAXON MINI DOB INSTRUCTION MANUAL...
= 30x Focal length of the eyepiece 10mm The Saxon Mini Dob comes with two eyepieces of 20mm and 4mm, giving you a usable magnification range of 15x and 75x. Calculating the Field of View The size of the view seen through your telescope is called the true (or actual) field of view (FOV).
Page 6
If moisture condenses on the inside of the optics, remove the accessories from the telescope. Place the telescope in a dust-free environment and point it downwards. This will remove the moisture from the telescope tube. 4 | SAXON MINI DOB INSTRUCTION MANUAL...
Page 7
Saxon Mini Dob Acces sory Pack The Saxon Mini Dob Accessory Pack expands the capabilities of your Min Dob to enhance the views of your desired land and/or sky objects. The carry bag provided in the accessory pack makes it easy to carry the...
