Koganei ION WIPER DTY-WCM-S Owner's Manual

Air curtain down blow type
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
X903454 Ver.2.0
（エアカーテンダウンブロー形）
ION WIPER
(Air Curtain Down Blow Type)
DTY-WCM-S DTY-WC-S
DTY-WCM-L DTY-WC-L
取扱説明書
Ver.2.0
Owner's Manual Ver. 2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ION WIPER DTY-WCM-S and is the answer not in the manual?

Questions and answers

Related Manuals for Koganei ION WIPER DTY-WCM-S

Summary of Contents for Koganei ION WIPER DTY-WCM-S

  • Page 1 X903454 Ver.2.0 （エアカーテンダウンブロー形） ION WIPER (Air Curtain Down Blow Type) DTY-WCM-S DTY-WC-S DTY-WCM-L DTY-WC-L 取扱説明書 Ver.2.0 Owner’s Manual Ver. 2.0...

  • Page 2: Table Of Contents

    目 次 Contents はじめに ……………………………………………………………………………………………………………… 2 1. イオンワイパー設置上の注意点 ……………………………………………………………………… 2 2. 概 要 ………………………………………………………………………………………………………… 2 3. 機器の構成および機能 …………………………………………………………………………………… 2 3-1. 各部名称および機能 ………………………………………………………………………………… 3 4. 設置および配線・配管 4-1. 一般的なイオンワイパー設置上の注意 …………………………………………………………… 4 4-2. 排気ダクト …………………………………………………………………………………………… 4 4-3. 電源 …………………………………………………………………………………………………… 4 4-4. アース（接地） ……………………………………………………………………………………… 4 4-5.

  • Page 3: Introduction

    Introduction Thank you for purchasing the ION WIPER. The ION WIPER uses alternating voltage of 2000V, though it is not specified as high voltage devices in Electric Equipment Standards. Read carefully this manual and another supplied owner's manual for Ionizer Air Blow【DTRY- ELL01】before using, and handle carefully and properly.

  • Page 4: Major Parts Name And Function

    3-1. Major parts Name and Function Ionizer, compact blow type （DTRY-ELL01） (Front of the body) Throttle valve (flow rate adjustment) Regulator for Ionizer for air curtain Setting pressure range: Power switch 0.05 to 0.5MPa ｛0.5 to 5.0kgf/cm ｝ Photoelectric switch (workpiece detecting sensor) pressure gauge Shower nozzle (outlet for ionized air)

  • Page 5: Installation, Wiring And Tubing

    4. Installation, Wiring and Tubing 4-1. Precautions on Installation of the ION WIPER ・ Use the ION WIPER indoors. For installation of the unit, care should be taken to the contamination by oil or water, high temperature and high humidity. ・Especially, avoid a place subject to dew condensation.

  • Page 6: Operations

    5. Operations q Install the ION WIPER on the stable and flat location, then connect the power supply, grounding, air tubing and exhaust duct. w Open the main valve of air unit (purchased and installed by the customer) and adjust the regulator of the Ionizer.
  • Page 7 t The ION WIPER operates for the time set in e and then stops, and the process for removing static charges and dust is completed. When the time for blowing is set to ［HOLD］ , ionized air blow is continued while the workpiece is placed (while the sensor detects the work).
  • Page 8 o Removing the side cover The side cover can be removed during operation in accordance with the size of the workpiece (charged object) or for operating efficiency. As a pipe for air curtain is installed on the upper part of the side, no contamination of working environment occurs. With side cover installed With side cover removed !0 Removing the tray...

  • Page 9: Maintenance And Precautions

    6. Maintenance and Precautions ・If water, oil, paint, etc. are adhered on the unit, remove them with waste, cloth or the like. ・Static charge removal level will be reduced, if dirt is adhered on the tip of discharging needle of the installed Ionizer.

  • Page 10: Specifications

    7. Specifications Model DTY-WC-S DTY-WCM-S DTY-WC-L DTY-WCM-L Blower fan Built-in Built-in Input voltage 100VAC ±10% (50/60Hz) Consumption current Approx.650 Approx.700 Approx.600 Approx.650 Installed Ionizer DTRY-ELL01（1pc.） DTRY-ELL01 （2pcs.） Ion balance Note ±15 Media Static charge removing performance Note 1sec （ 1000V→100V, 0.5MPa, 50mm） Operating pressure range MPa ｛kgf/cm ｝...
  • Page 11 DTY-WC-L DTY-WCM-L (Type A3) Power switch Throttle valve for air curtain Regulator (for Ionizer) Setting pressure range: 0.05 to 0.5MPa Pressure gauge Air curtain pipe Ionizer 366.2 Throttle valve IN port: φ8 quick fitting for Ionizer 0.2 to 0.7MP ａ Photoelectric switch Transparent cover (anti-static processed)
  • Page 12 Memo - 21 -...
  • Page 13 7 0 1 2 0 - 5 5 - 9 0 4 0 クレシード専用フリーダイヤル JUST CONSULT US KOGANEI CORPORATION OVERSEAS DEPARTMENT 3-11-28, Midoricho, Koganei City, Tokyo 184-8533, Japan TEL : 042-383-7271 FAX : 042-383-7276 イオンワイパー （エアカーテンダウンブロー形） ION WIPER (Air Curtain Down Blow Type)
  • Page 14 イオンワイパーに関するお問い合わせ先は… □ク レシー ド事業部 184-8533 東京都小金井市緑町3-11-28 ゴーゴー ク レ シ ー ド 7 0 1 2 0 - 5 5 - 9 0 4 0 クレシード専用フリーダイヤル URL http://www.koganei.co.jp 2004年9月10日 初版 5 2005年3月 2版 3 CHAT ©KOGANEI CORP. PRINTED IN JAPAN...
