- Page 1 No.BK-SP005 Static Electricity Removing Unit IONIZER Technical Information Guidebook...
-
Page 2: Table Of Contents
Reference Contents Application Examples Blow Type Application Examples ･････････････････････････････････････････ Fan Type Application Examples ･･････････････････････････････････････････ Technical Information Blow Type: Flow Rate Characteristics ････････････････････････････････････ Static Charge Removing Characteristics When Mini Line Filter (DTRY- LF040) is Mounted ････････････････････････････････････････････････････････ Blow Type: Flow Rate Changes in Relation to Number of Throttle Valve Needle Rotations ･･････････････････････････････････････････････････････････... -
Page 3: Application Examples
Use the blow type ionizer to prevent parts from becoming stuck due to static electricity. Also, simultaneous use with a fan type is effective for the static electricity removal. - Page 4 ● Removal of static charges on devices carried ● Removal of static charges in printing by pallets process Use blow type Ionizers with straight bar nozzles to remove Use 2-head type Ionizers with bender nozzles. Prevents static charges on a wide carrying pallet. faulty printing caused by static charges in ink jet printing process.
- Page 5 Select the proper nozzle for your application ● Shower nozzle ● Flat nozzle ・ Blows ionized air at 60° or 90° angles. ・ Blows ionized air at 90° angle, suitable for removal of static charges over relatively wide area. 90° 60°...
-
Page 6: Fan Type Application Examples
Fan Type Application Examples ● Removal of static charges of parts on ● Removal of static charges on printed circuit working bench boards Removes static charges from parts, during assembly. Enables static charge removal for relatively wide objects. ● Removal of static charges on packaging films ●... -
Page 7: Technical Information
Technical Information Blow Type: Flow Rate Characteristics Mini Line Filter DTRY-LF040 DTRY-ELB01 Flow Rate Characteristics DTRY-ELL01 Flow Rate Characteristics Without filter Without filter When DTRY-LF040 When DTRY-LF040 is mounted is mounted 1R/min＝0.0353 ft. /min. Supply air pressure (MPa) Supply air pressure (MPa) 1 MPa＝145 psi. -
Page 8: Static Charge Removing Range By Nozzle Type
Notes: 1. The method of measurement used a 20 pF, □150 mm [5.91 in.] charged plate monitor, and the measurement was performed using Koganei measurement conditions. 2. The static charge removing time is the time required to decay from ±1000V down to ±100V. -
Page 9: Selecting Pneumatic Equipment For Blow Type
Selecting Pneumatic Equipment for Blow Type ※ Select ionizer air cleanliness suited to your applications. ※ The combinations shown below are typical examples. For details, see p. 41 of the Accessories General Catalog. Please feel free to consult us. High Clean level ①... -
Page 10: Discharging Needle Maintenance Period (Rough Guidelines)
The photographs below show the accumulation of dust on the tip of the discharging needle used in the steady flow fan type. Depending on the application conditions, perform the cleaning after 300 to 500 hours of use. When cleaning the discharging needle, cleaning the louver and the inside of the ionizer body at the same time is recommended. 100 h... -
Page 11: Cleaning Procedure For Discharging Needle
・ The discharging needle is a consumable part that must be replaced if used over long periods. For replacement, use a dedicated tool (DTRY-ELB21). ・ After cleaning, flush the needle. Activating the ionizer with residual alcohol on the needle could result in unstable performance. The ionizer requires periodic maintenance and checks. -
Page 12: Steady Flow Fan Type: Wind Speed Data
Steady Flow Fan Type: Wind Speed Data (Reference value) ●DTRY-ELF02 ●DTRY-ELF02 When straight louver is used When wide-angle louver is used （m/s） （m/s） 100 mm 100 mm 100 mm 100 mm 100 mm 100 mm 100 mm 100 mm 100 mm 100 mm ●DTRY-ELF03 ●DTRY-ELF03 When straight louver is used... -
Page 13: Other Materials
Other Materials Static Electricity Countermeasure Accessories ※ Koganei does not offer the static electricity countermeasure goods shown on this page. ● Wrist Strap Because the operator’s body maintains a constant, low-level electrification potential, use a wrist strap to ground the body. -
Page 14: Static Electricity Q&A
Static Electricity Q&A What is static electricity? Dynamic electricity Static electricity (regular electricity) (electricity stored on materials) Static electricity is generated by clothing or seat friction. Discharges when metal is touched. Electric current When friction between materials causes the plus-minus balance to collapse and to tilt electrically toward one polarity, this condition is called static electricity. - Page 15 What types of electrification are there? Electrification is due to contact: Electrification is induced when two objects come into contact. ● Triboelectric electrification Static electricity induced when the surfaces of two objects in contact rub against each other. ● Peeling electrification ...
- Page 16 What is the difference between a conductor and an insulator? Electrification acts differently between a conductor and an insulator. Conductor: Materials that conduct electricity easily → Iron, copper, aluminum, carbon, etc. Conductor image Since electrons move freely through the c o n d u c t o r, g r o u n d i n g t h e c h a r g e d conductor results in 0V.
- Page 17 What kind of phenomenon is electrostatic induction? Bringing a charged body close to a conductor (metal, etc.) causes a build-up in the opposite charge in regions near the charged body, and a build-up of the same charge in regions farther away. This is called electrostatic induction.
- Page 18 Is there an example of work-related trouble with electrostatic induction? Even if a workpiece has no charge, bringing a charged body close to a conductor can cause polarization within the conductor due to electrostatic induction, resulting in a discharge. Semiconductor (example of device) Charged body Approaches Discharge...
- Page 19 What is electrostatic damage? With increasingly compact parts and greater semiconductor densities, electrostatic damage to circuits and devices due to electrostatic discharge (ESD) has become a major problem. In general, MOS-configuration ICs and field-effect transistors (FETs), high-frequency devices, and other similar types of equipment are extremely sensitive to static electricity, and easily susceptible to be damaged.
- Page 20 , t h e c h a r g e d s t a t e method of static charge elimination is not continues unchanged. appropriate. Blown off by Ionizer force of wind Charged Charged Dust...
- Page 21 Static electricity removal using ionizers Ionizers are devices that direct positive and negative ion air against the target object to neutralize the electrification state of the target object. Neutralized with negative ions Ionizer Positively Positively charged charged material material...
- Page 22 Corona discharge occurs when high voltage is locally generated between two conductors, causing a breakdown in air insulation and generating blue-violet light. In a corona discharge ionizer, high voltage is applied to the discharging needle to generate the corona discharge.
- Page 23 What is the difference between the AC and DC methods? The corona discharge type ionizer can be broadly divided into AC and DC methods, depending on the method of applying voltage. AC method : Generates positive and negative ions in alternating...
- Page 24 This causes ions within the tube to be extinguished, making carrying ions through the tube impossible. The Koganei ionizer, on the other hand, uses a high frequency of...
- Page 25 Please explain about static charge removing time and ion balance. Static charge removing time (elimination speed) and ion balance are two measures for evaluating ionizer performance. Static charge removing time The time required for objects charged to ±1000V to decay down to ±100V.
- Page 26 Low-frequency ionizer High-frequency ionizer Long cycle for Short cycle for generation of positive generation of positive and negative ions and negative ions Situation on workpiece surface when ionizer is used Large voltage Small voltage fluctuation fluctuation Apparent ion balance...
- Page 27 The situation when the plastic panel is lifted away from the metal plate is shown in Figure 2. When the plastic panel is separated from the metal plate, its potential rises sharply. If an ionizer was being used to perform efficient static charge removal, where the static charge is being eliminated is the key point.
- Page 28 When eliminating charges of a large charged object When the targeted workpiece is large in size, and the ionizer must be set at a cer tain distance away, the fan type s h o w s b e t t e r c h a r g e e l i m i n a t i o n effectiveness than the blow type.
- Page 29 9-10.) Discharging Needle Contamination The tip of the discharging needle used in the ionizer can become dirty after repeated use. If this discharging needle contamination becomes severe enough, the amount of ions generated will deteriorate, resulting in reduced static charge elimination capability. It can also lead to poor ion balance.
- Page 30 Please explain the measurement principles for the electrostatic potential sensor EP Sensor. The electrostatic potential sensor EP Sensor uses the electrostatic induction phenomenon that arises between the charged body and detection electrodes. The electric field from the charged body generates an induction charge in the detection electrode surface. This induction charge is then calculated and displayed as the potential of the charged body.
-
Page 31: Frequently Asked Questions
It does not serve to extend the operating life of the ionizer itself. Can the ionizer be used in explosive atmospheres? Corona discharges are induced when ions are generated, and since it could ignite in a flammable gas atmosphere, the ionizer cannot be used in such locations. - Page 32 DTRY-ELB nozzle for connecting to the main body. Please purchase the nozzle specially made for each model. What is the nozzle made of? The connection part (cone-shaped part) to the ionizer main body is made of aluminum alloy, while the tips are made of stainless steel.
- Page 33 There is no reset function for abnormal output in the EP EP sensor? sensor. A sensor abnormality is treated as a malfunction, and should be either repaired (consult with Koganei) or replaced with a new sensor. In what sort of situations do sensor abnormalities occur? When the sensor (detector) stops transmitting, this is output as a sensor abnormality.
- Page 34 Can calibration be performed? Since the CC monitor is not a measuring instrument, calibration cannot be performed. However, Koganei is ready to perform inspections and adjustments at customer request. Customers desiring this service are requested to consult with Koganei.
-
Page 35: Troubleshooting
No air is being delivered. ① Ionizer throttle valve ・Check whether the air is throttled too much. too tightly squeezed, or ・Check whether air is being supplied to the ionizer. a piping error. ・Check the pneumatic circuit. Fan type LED fails to light even after ①... - Page 36 Sensor input the IP address allocated in DeviceInstaller for sensor is not connected!” implementing the support software settings. is displayed. ＊ If the product fails to operate correctly even after the above measures are adopted, there may be a problem with the product itself. Consult with Koganei.
-
Page 37: Glossary
NC (Normally Closed) contact. ⇔ See a-contact. Carrying ions through a A method where ions generated by the ionizer are carried through a tube to remove charges from an tube electrified area. In ionizers with a low frequency of 50/60 Hz, carring ions through a tube is impossible because the ions are extinguished inside the tube. - Page 38 (DC method) current high voltage (DC) are called direct current type ionizers. Discharging needle A needle-shaped electrode attached to the interior of a corona discharge method ionizer. A corona discharge is generated from its tip, to generate ions. Dust generation Generation of dust or particles.
- Page 39 (parts per billion). Pulse AC method ionizer A method for applying high voltage to the discharging needle in the corona discharge method ionizer. A feature is its ability to use sensing to control the amount of positive and negative ions. Positive ions and negative ions can be discharged from a single discharging needle.
- Page 40 Electrostatic energy discharged from a charged object through a conductive object in close proximity. Discharging brushes utilize this principle. Soft X-ray method A type of light irradiation ionizer. The ionizer uses soft X-rays, a type of electromagnetic wave with an ionizer extremely short wavelength.
- Page 41 MEMO...
- Page 42 Limited Warranty • KOGANEI CORP. shall in no way be liable or responsible for KOGANEI CORP. warrants its products to be free from defects injuries or damage to persons or property arising out of the in material and workmanship subject to the following provisions.
