Messrs:
FCC ID: F2QRFCOMKBTX / KEYBOARD:
SCORPIUS RF/SCORPIUS MVII/SCORPIUS KIV
FCC ID: F2QRFCOMPOTX / MOUSE:
LYNX RF /LYNX KIV/LYNX LV/LYNX KV
RECEIVER: RECEIVER RF/RECEIVER KI
Approval Signatures:
PM:
Electronic Engineer:
Mechanical Engineer:
Produce by:
9F, # 75, Se . 1, Hsin Tai Wu Rd. Hsichih, Taipei Hsien,Taiwan, R.O.C.(Far East World Center-Bldg. A)
C
Tel: (886-2) 2698-2566 Fax: (886-2)2698-3133
Email Address: qtronix@qtronix.com.tw World Wide Web: http://www.qtronix.com.tw
User's Guide
QTRONIX CORPORATION
Advertisement
Summary of Contents for QTRONIX SCORPIUS RF
- Page 1 Approval Signatures: Electronic Engineer: Mechanical Engineer: Produce by: QTRONIX CORPORATION 9F, # 75, Se . 1, Hsin Tai Wu Rd. Hsichih, Taipei Hsien,Taiwan, R.O.C.(Far East World Center-Bldg. A) Tel: (886-2) 2698-2566 Fax: (886-2)2698-3133 Email Address: qtronix@qtronix.com.tw World Wide Web: http://www.qtronix.com.tw...
- Page 2 Scorpius KIV (P) & Lynx KIV (p) SPECIFICATIONS WARNING Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection. This equipment generates, uses and can radiated radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 3 Scorpius KIV (P) & Lynx KIV (p) SPECIFICATIONS ⅠSetup Guide Reset ID before using Step 1: Connect the receiver to your computer Step 2: Push the “CONNECT” button on the receiver. Step 3: Push the button on the back of the mouse (in upper left corner). Please note that this step must be completed after Step 2 within 8 seconds.
-
Page 4: System Requirements
Scorpius KIV (P) & Lynx KIV (p) SPECIFICATIONS Ⅱ GENERAL Description keyboard has an enhanced NedMedia design and can work with any IBM PC PS/2 compatible computer. Utilizing the latest in rubber mechanical key switch technology, Keyboard offers durability and style that will enhance any system for years to come. - Page 5 Scorpius KIV (P) & Lynx KIV (p) SPECIFICATIONS Ⅲ Electrical specification Environmental of Temperatures 0℃ to 50℃. Operating temperature -10℃ to 60℃. Non-operation temperature Humidity Test Condition temperature 25C~55C Operating humidity 10% to 85% Non-operation Humidity 10% to 85% 60℃, 24Hours Heat storage -10℃, 24Hours Cool storage...
- Page 6 Scorpius KIV (P) & Lynx KIV (p) SPECIFICATIONS 2.EN 61000-3-2: 1995+A1: 1998+A2: 1998 3.EN 61000-3-3:1995 4.EN 55024; 1998 BSMI CNS13438. Contact discharge: +2 / +4 KV Air Discharge: +2/ +4 / +6 / +8 KV Environmental of electrical Shock test The mouse shall withstand a shock equal to 20G forces, half sine wave for 11 msec duration in all three (3) orthogonal axes.
- Page 7 Scorpius KIV (P) & Lynx KIV (p) SPECIFICATIONS Ⅳ Mechanical specification Material Cover HIPS Key top HIPS Body Weight & Dimension Keyboard Mouse Receiver Weight 800g 100.5grams 88.5grams Length 475.5mm 130.1mm 102.8mm Width 172mm 73.1mm 82.2mm High 32mm 39.5 mm 30.3mm Body colors Keyboard...
- Page 8 Scorpius KIV (P) & Lynx KIV (p) SPECIFICATIONS Ⅴ RF SPEC Keyboard Mouse Receive FREAUENCY 27.092MHZ 27.042MHZ 26.64MHZ/26.59MHZ MODULATION DATA RATE 4.8K 4.8K 4.8K POWER LEVEL 0 dB 0 dB SENSITIVITY -90 dBm TRANSISSION 1.5M 1.5M 1.5M DISTANCE...
