MicroControl uMIC.200 Quick Start

Hide thumbs
1
2
3
4

Advertisement

Table of Contents

Control systems
µMIC.200
QuICkStart
Start-up in 6 steps.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the uMIC.200 and is the answer not in the manual?

Questions and answers

Summary of Contents for MicroControl uMIC.200

  • Page 1 Control systems µMIC.200 QuICkStart Start-up in 6 steps.
  • Page 2 Power supply Connect DC voltage 9V..36V to the accordingly marked terminals of the µMIC.200. the LED “PWr” shows a permanent green light. a green flashing light of “LED1” indicates access to the internal flash memory. Network interface Plug network wire into LaN1 or LaN2 connector and connect it to your computer.
  • Page 3 Set up development environment For remote development, use the preconfigured Eclipse which only requires a Java runtime environment and a network connection to the µMIC.200. Install the µMIC.200 remote tool Chain which corresponds your operating system from the attached CD. Navigate to the installation directory and execute „eclipse“.
  • Page 4 More helpful tips and tricks on the usage of the automation Controller you will find in the µMIC.200 manual. tel.: +49 ( 0 ) 2241/25 65 9 - 0 Junkersring 23 info@microcontrol.net Fax: +49 ( 0 ) 2241/25 65 9 - 11 53844 troisdorf www.microcontrol.net...
