UG-7-A6O-24V and UG-7-A6O-120V Installation and maintenance manual
________________________________________________________________________________________
Specifications:
Operating temperature:
Storage temperature:
Humidity:
Air Velocity:
Footprint dimensions:
Weight:
Electrical
Power supply voltage :
Reset time (by power down):
Power up time:
Sensitivity:
Current requirements
Max. standby current (no
external equipment attached):
Max. alarm current:
Link current:
Total max auxiliary current
output on terminals 2 and 5:
Contact ratings
Alarm initiation contacts (SPST)
Supervisory contacts (SPST)
Alarm auxiliary contacts (DPDT)
PRIOR TO INSTALLING YOUR DUCT DETECTOR
Read this installation manual which provides information on detector placement, wiring, test and maintenance.
This manual is also available online at www.calectro.com.
Follow the installation instruction in the installation manual, and all applicable local codes including NFPA 72,
NFPA 90A, and NEMA Guide for Proper Use of Smoke Detectors in Duct Applications,
TABLE OF CONTENTS
[1]
Limitations of Duct Smoke Detectors
[2]
Overview
[3]
General Description
[4]
Duct Smoke Detector Kit Contents
[5]
Installation
[6]
Field Wiring Installation Guidelines
[7]
Measurement Tests
[8]
Detector condition Indication
[9]
Confirmation of Operation
[10]
Detector replacement and cleaning
UG-7-A6O Installation manual
HFE716 Version: 14
Box 4113 • 426 04 Västra Frölunda • SWEDEN
info@calectro.com • www.calectro.com
32°F (0°C) to 100°F (38°C),
-22°F (-30°C) to 158°F (70°C)
0% to 95% Relative humidity
100 ft/min (0.51 m/sec.) - 4000 ft/min (20.32 m/sec).
L: 10.98 in (279 mm) / W: 6.49 in (165 mm) / D: 3.26 in (83 mm)
UG-7-A6O-24V: 0,84kg / UG-7-A6O-120V: 1kg
UG-7-A6O-24V
UG-7-A6O-24V
24Vdc (-5 / +20%)
24Vac (±10%) 50-60Hz
Nominal sensitivity 0.96-1.2 %/ft
42mA
82mA
83mA
145mA
Without linked detectors: 30mA, with linked detectors: 25mA
1 sec. max.
1 minute
5mA
1.0A @ 24VDC (resistive)
1.0A @ 120VAC (resistive)
1.0A @ 24VDC (resistive)
1.0A @ 120VAC (resistive)
10A @ 30VDC (resistive)
10A @ 250VAC (resistive)
½ HP @ 240VAC
¼ HP @ 120VAC
UG-7-A6O-120V
110-120Vac 50-60Hz
31mA (at 120Vac)
42mA (at 120Vac)
page 1
Date: 2014-03-24
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for CALECTRO UG-7-A6O-120V
Summary of Contents for CALECTRO UG-7-A6O-120V
- Page 1 UG-7-A6O-24V and UG-7-A6O-120V Installation and maintenance manual Box 4113 • 426 04 Västra Frölunda • SWEDEN info@calectro.com • www.calectro.com ________________________________________________________________________________________ Specifications: Operating temperature: 32°F (0°C) to 100°F (38°C), Storage temperature: -22°F (-30°C) to 158°F (70°C) Humidity: 0% to 95% Relative humidity Air Velocity: 100 ft/min (0.51 m/sec.) - 4000 ft/min (20.32 m/sec).
- Page 2 A SUBSTITUTE FOR OPEN AREA DETECTOR PROTECTION as a means of providing life safety. Nor are they a substitute for early warning in a building’s regular fire detection system. Calectro AB supports this position and strongly recommends that the user read NFPA Standards 90A, 72, and 101. UG-7-A6O is listed per UL 268A.
- Page 3 The UG-7-A6O has two versions that operates with 24 VDC/VAC or 120 VAC. The UG-7-A6O-24V for the 24 VDC/VAC and the Model UG-7-A6O-120V for the 120 VAC versions. Alarm and supervisory relay contacts are accessible to interface with control panel, HVAC control, and multiple auxiliary functions including turning off the fan.
- Page 4 Figure 2 Mounting position Ventilation duct Air flow direction We recommend that the UG-7-A6O is mounted on a distance of approximately 3 times the duct diameter before an obstruction such as dampers, filters or bends, and approximately 5 times the diameter after these obstructions as shown in Figure 3.
- Page 5 Figure 6 Figure 7 Figure 8 [5.4] INSTALLATION OF SAMPLING TUBE LONGER THAN 2 FT. Strong vibrations can arise inside a duct due to the air currents. When the diameter of the duct is larger than 2 ft. the sampling tube should penetrate the whole duct. Drill a 2 inch hole in the opposite side of the duct. Mount the rubber gasket HFU204* in the hole.
- Page 6 Figure 14a Figure 14b Test/Reset button Factory prepared entry for conduit connector. * Extra conduit entries. Figure 15 Detector LED Test/Reset button Power board LED 1: Green Power supply 2: Yellow 3: Yellow 4: Red Table 6.1 GND / Detector Link out- Common ground for detector link out, +18V AUX and Test/Reset Detector link out + 18Vdc at Detector link out: 18Vdc out for AUX relay triggering of linked UG-7-...
- Page 7 Connect power source to appropriate terminals of each detector. Power supply must not be connected to GND (terminal 1). NOTE 2: 120VAC Power Inputs accept 110-120VAC 50-60Hz (UG-7-A6O-120V). Connect power source to appropriate terminals of each detector. See specifications for additional power supply information.
- Page 8 NOTE 4: Supervisory contacts indicates: removed, contaminated or power failure. Contacts shown in standby position. Open contacts indicate a trouble condition. See specifications for contact ratings. NOTE 5: Alarm Initiation contacts shown in standby position. Closed contacts indicate an alarm condition. See specifications for contact rating.
- Page 9 Figure 16B [7.3] METHOD 3 : AIR VELOCITY GREATER THAN 500 FPM: First, verify the air speed is greater than 500 feet per minute by using the measurement method described in method 1 above. With the air handler turned on, use a manometer to measure the differential pressure across the inlet port and outlet ports of the sampling tube, this measurement shall be verified to be between 0.0028 to 1.49 inches of water.
- Page 10 Apply power to terminals 17 and 18: 24 VAC/DC for UG-7-A6O-24V version. 120 VAC for UG-7-A6O-120V version. [9.2] PERFORM DETECTOR CHECK Verify that the UG-7-A6O is installed according to this manual and that it is in Standby Status according to Table 8.1.
- Page 11 4. Remove the four screws and the cover as described in Section 6.1 Figure 14b. 5. *) Remove the detector head by turning it counter clockwise and lift the detector head. 6. Use the UB-6 smoke detector base. This can be ordered from Calectro AB. Please see contact information in this Installation manual.
- Page 12 [10.2] DETECTOR CLEANING If the detector needs to be cleaned do the following: 1. Disconnect the power. 2. Remove the four screws and the cover as described in Section 6.1 Figure 14b. 3. *) Remove the detector head by turning it counter clockwise and lift the detector head. 4.
