PLEASE READ THESE INSTRUCTIONS CAREFULLY AND KEEP FOR FUTURE REFERENCE! IF
YOU DO NOT UNDERSTAND THE INSTRUCTIONS, OR DO NOT FEEL THAT YOU CAN
FOLLOW THEM SAFELY, CONTACT A QUALIFIED CONTRACTOR. THE WARRANTY WILL BE
HONOURED IF ACCOMPANIED BY AN ORIGINAL SALES RECEIPT, AND ONLY IF THE
INSTRUCTIONS HAVE BEEN FOLLOWED EXACTLY.
http://www.everik.com/en-CA/Parts-Request.html
• These mounts are designed to mount a panel onto a vertical wall. Hardware for mounting to a
wood stud is included. For mounting to any other surface, it is recommended you contact a
qualified contractor.
• The wall or mounting surface must be capable of supporting the combined weight of the mount
and the flat panel, otherwise the structure must be reinforced.
• Safety gear and proper tools must be used. A minimum of two people are required for this
installation. Failure to use safety gear and/or attempting this installation alone can result in
property damage, serious injury, or death.
• Follow all instructions and recommendations regarding adequate ventilation and suitable locations
for mounting your flat panel. Consult the owner's manual of your flat panel for more information.
• This product will hold flat panels up to 70" and weighing up to 88 lbs.
• VESA 600mm x 400mm
Tools Required
• Phillips head screwdriver
• M6 socket and wrench
• Electric drill and 10mm masonry bit for concrete wall installation
• Pencil
•
Hammer
•
Stud finder
1
INSTRUCTIONS
To acquire missing parts please visit
or call 1-866-604-6966.
EM-T2000
EM-T1000..LU.092013.IM
Advertisement
Related Manuals for Everik EM-T2000
Summary of Contents for Everik EM-T2000
- Page 1 EM-T2000 INSTRUCTIONS PLEASE READ THESE INSTRUCTIONS CAREFULLY AND KEEP FOR FUTURE REFERENCE! IF YOU DO NOT UNDERSTAND THE INSTRUCTIONS, OR DO NOT FEEL THAT YOU CAN FOLLOW THEM SAFELY, CONTACT A QUALIFIED CONTRACTOR. THE WARRANTY WILL BE HONOURED IF ACCOMPANIED BY AN ORIGINAL SALES RECEIPT, AND ONLY IF THE To acquire missing parts please visit INSTRUCTIONS HAVE BEEN FOLLOWED EXACTLY.
-
Page 2: Parts List
PARTS LIST Wall Mount (1) Safety Bar (1) Left Adapter Bracket (2) Decorative Covers (2) Bubble Level (1) Right Adapter Bracket (2) ST2.9 x 6.5 (4) Package M M5x14 M6x14 M8x20 M6x30 M8x30 Washer Small spacer Large spacer Package W ST6.3x55 Concrete anchor D6 washer... - Page 3 1. Installing the Decorative Covers Attach the decorative covers to the wall plate using screws (G) x4. Note: The gap on the decorative covers should be facing downwards. 2a. Mounting the wall plate into wooden studs * Make sure that the mounting screws are anchored into the center of the studs. The use of a stud finder is highly recommended.
- Page 4 2b. Mounting the wall plate into concrete * When installing wall mounts on cinder block, verify the actual concrete thickness is at least 1-3/8” (35mm) for using the concrete anchors. Do not drill into mortar joints! Be sure to mount in a solid part of the block, generally 1”...
- Page 5 3. Installing the Adaptor Arms Top of TV 3a. For flat back panels Note: Choose the appropriate screws, washers and spacers according to the type of panel. Using two people, lay your flat panel down on a clean, soft surface and install the Adaptor Arms Tighten all screws, but do not over tighten.
- Page 6 3b. For recessed back panels or to access A/V inputs. Note: Choose the appropriate screws, washers and spacers according to the type of panel. Tighten all screws, but do not over tighten. 4. Hanging your panel onto the Wall Plate *Using two people, lift panel slowly and hook the Adaptor Arms (C &...
- Page 7 4. Hanging your panel onto the Wall Plate Insert the safety bar *Use a padlock to prevent theft. (The padlock is not included) 5. Final Adjustments Push or pull from the top or bottom of the screen to obtain the desired angle. EM-T1000..LU.092013.IM...
- Page 8 QUALIFIÉ. LA GARANTIE NE SERA HONORÉE QU'EN LA PRÉSENCE DU COUPON DE CAISSE ORIGINAL ET UNIQUEMENT SI LES INSTRUCTIONS ONT ÉTÉ SUIVIES À LA LETTRE. Pour obtenir des pièces manquantes, visitez www.everik.com/parts.html ou téléphonez au 1 866 604-6966. • L'IM-ALB3 est conçu pour fixer un moniteur sur un mur vertical. Le matériel servant au montage sur mon- tant de bois est inclus.
-
Page 9: Liste Des Pièces
LISTE DES PIÈCES Plaque murale (1) Barre de sécurité (1) Bras adaptateur gauche (2) Plaque décorative (2) Bras adaptateur droit (2) Niveau à bulle (1) ST2.9 x 6.5 (4) Package M M5x14 M6x14 M8x20 M6x30 M8x30 Rondelle Cale (petit) Cale (grand) Package W ST6.3x55 Cheville pour béton... - Page 10 1. Installation des plaques décoratives Fixez les caches décoratifs à la plaque murale avec les vis (G) x4. Remarque : l'ouverture sur les caches décoratifs doit être orientée vers le bas. 2a. Montage de la plaque murale sur montants en bois Percez des rous Trouvez et marquez l'emplacement exact...
- Page 11 2b. Montage de la plaque murale sur mur de béton Marquez l'emplacement exact des trous de montage Percez des rous Vissez le sup-port mural au mur AVERTISSEMENT * Si vous installez le support mural sur un bloc de béton, assurez-vous de disposer d'une épaisseur de béton d'au moins 1 3/8"...
- Page 12 3. Installation des bras adaptateurs Haut du téléviseur 3a. Pour les écrans à dos Remarque : Choisissez les vis, rondelles et cales appropriés en fonction du type d'écran plat. Avec l'aide d'une autre personne, placez votre écran plat sur une surface propre et plane, et installez la bras adaptateurs.
- Page 13 3b. Pour les écrans à dos concave ou pour accéder aux connexions A/V Remarque : Choisissez les vis, rondelles et cales appropriés en fonction du type d'écran plat. Assurez-vous de bien serrer les vis, mais ne les serrez pas trop fort. 4.
- Page 14 4. Installation de l'écran plat sur le support mural Le pli est orienté vers l'intérieur Insérez la tige de sécurité (B) Utilisez un cadenas pour empêcher le vol (cadenas non fourni). 5: Derniers ajustements Tirez ou poussez en haut ou en bas de l'écran pour obtenir l'angle désiré. EM-T1000..LU.092013.IM...
