FUTABA FDL01TU Instruction Manual

FUTABA FDL01TU Instruction Manual

Wireless modem with serial interface
Hide thumbs
Table of Contents

Advertisement

Quick Links

WIRELESS DATA COMMUNICATION MODEM
FDL01TU
Wireless Modem with Serial Interface
Instruction Manual
Futaba Corporation
Industrial Radio Control
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FDL01TU and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FUTABA FDL01TU

Summary of Contents for FUTABA FDL01TU

  • Page 1 WIRELESS DATA COMMUNICATION MODEM FDL01TU Wireless Modem with Serial Interface Instruction Manual Futaba Corporation Industrial Radio Control...
  • Page 2 Any unauthorized changes or modifications to this device not expressly approved by Futaba Corporation could void the user’s authority to operate the device and possibly result in damage to the equipment and/or cause serious or fatal injuries to the operator or nearby personnel.
  • Page 3 The following warnings are included in the lists that follow but warrant repetition here: In installations where the FDL01TU system is used to control motion or operation of potentially dangerous equipment, it is imperative for safety that all operators and installers be thoroughly trained in the normal function of that equipment before attempting to control it remotely with the FDL01TU system.
  • Page 4 Improper installation and/or operation of the FDL01TU system can cause serious or fatal injuries to the operator or nearby persons and cause damage to the FDL01TU system, and any equipment it is used to control. Please read and understand this manual completely and the manual of all equipment being controlled before attempting to operate or install this system.
  • Page 5 The FDL01TU modem contains no user serviceable parts. If the unit requires service, contact your sales representative or local branch of Futaba Corporation per instructions the section titled How To Obtain Help.
  • Page 6 Be sure the FDL01TU modem power, the power to the equipment that is being connecting to it, and the DC power source are all turned off before wiring and connecting the power cable.
  • Page 7 A loose antenna or cable may severely reduce the operating range of the system. When installing the FDL01TU modem in a mobile unit such as an Automated Guided Vehicle (AGV), Futaba recommends to use the diversity reception feature as a remedy for multipath fading problems.
  • Page 8 Environmental Safety Hazards and Notes II.IV If the FDL01TU modem has been stored at a temperature beyond the specified operating temperature range for the system, it may not function properly. Allow it to return to normal temperatures before use. Refer to A A –...
  • Page 9 Operational Safety Hazards and Notes Before each use of the FDL01TU modem, ensure that the area where the equipment will be operated is clear of people or obstacles that may affect its safe operation. Before each use of the FDL01TU modem, verify that both the equipment being controlled and the modem are in proper operating condition.
  • Page 10 System Identification For future reference, please take a moment to fill in the information below. This information will help us respond as quickly as possible should your FDL01TU modem ever need repair or replacement. Model Name and Number: FDL01TU Serial Number:...
  • Page 11 This limited warranty does not cover any defect or damage to any of the goods caused by or attributable to force, accident, misuse, abuse, faulty installation, improper maintenance, improper electrical current, failure to install or operate in accordance with Futaba’s written instructions, repair or alteration by unauthorized persons, or leaking batteries. THE...
  • Page 12 Furnishing of these products does not convey a license, implied or otherwise, under any patent, copyright, or trademark right in which Futaba has an interest, nor does it convey rights to trade secrets or any other proprietary information of Futaba.

  • Page 13: Table Of Contents

    TABLE OF CONTENTS 1 1 1 1 INTRODUCTION....................1 Special Features......................2 How To Obtain Help......................3 Physical Description .......................4 2 2 2 2 SYSTEM INSTALLATION ................5 Wireless Modem Installation...................6 Communication Cable Connection.................7 Antenna Connection .......................7 Other Installation Precautions ..................9 3 3 3 3 SYSTEM OPERATION ................... 11 Data Transparent Mode....................12 Packet Transmission Mode ..................13 Headerless stream Mode .....................16...

  • Page 15: 1 1 1 Introduction

    SECTION INTRODUCTION...

  • Page 16: Special Features

    Special Features The following list highlights some of the special features of the FDL01TU. For more complete system specifications please refer to p.66 S PECIFICATIONS Approved under FCC Part 15.247 rules -- no special user license required • Operating range greater than 1000 feet, line-of-sight -- configurable as a repeater for •...

  • Page 17: How To Obtain Help

    How To Obtain Help Please contact your local sales representative or local branch of Futaba Corporation at the address shown below for help with the following: Application information regarding the FDL01TU or other Futaba products • Technical assistance or training •...

  • Page 18: Physical Description

    Used to connect to antennas for transmit and receive functions. LEDs Four bi-color LEDs indicate the states of the FDL01TU modem. Mounting Hole Used to install a modem from the front surface. It is easy to install a modem, however, only two holes are available, it should be fixed by guide structure on the other side of the unit to prevent vibration problem.

  • Page 19: 2 2 2 System Installation

    SECTION SYSTEM INSTALLATION...

  • Page 20: Wireless Modem Installation

    W ARNING (especially metal particles) to enter inside, which may damage the unit. Since the FDL01TU modem is a precision electronic device, install it W ARNING at a place free of excessive shock and vibration to prevent the unit from damage.

  • Page 21: Communication Cable Connection

    For the connection of the modem, see p.22 P SSIGNMENT The signal level of the FDL01TU is CMOS. If the interface of the equipment to be connected is RS232C or RS485, the level conversion circuit is required. For the example of the level conversion circuit, see p.64 C...
  • Page 22 Figure 2–5: Connecting the Antenna 2.3.2 Diversity Antenna Setup In certain situations, reception can be improved by using the integrated antenna diversity feature. This is accomplished by using two separate antennas and enabling the diversity function in REG19 (see p.27 M EMORY EGISTER ESCRIPTION...

  • Page 23: Other Installation Precautions

    Excessive vibration could permanently damage the modem and/or cause it to malfunction. If the FDL01TU modem has been stored at a temperature beyond the W ARNING specified operating temperature range for the system, it may not function properly.
  • Page 24 Such objects can severely reduce the operating W ARNING range of the system. When installing the FDL01TU modem in a mobile unit such as an Automated Guided Vehicle (AGV), Futaba recommends using the diversity receive function as a remedy for to multipath fading problems.

  • Page 25: 3 3 3 System Operation

    SECTION SYSTEM OPERATION...

  • Page 26: Data Transparent Mode

    With the exception of FDL01TU modem commands, all data input from the sending terminal are transmitted to the receiving terminal. Using this mode, the user can simply replace a serial cable with a pair of FDL01TU modems and communicate without any special software or hardware requirements.

  • Page 27: Packet Transmission Mode

    1:n and n:m topology applications. In packet transmission mode, the FDL01TU modem normally waits in a ready-to- receive state. When a transmission command is issued to the sender modem from its terminal equipment, the modem searches for a clear frequency channel and, when found, transmits the message to the intended destination receiver modem.
  • Page 28 Six transmit commands can be used in packet transmission mode . Both text and binary data can be sent directly from modem-to-modem or sent through a third FDL01TU modem configured as a repeater. The receiver modem automatically determines the transmitted data format and communication path from the information in the received packet header.
  • Page 29 The following list shows each command’s syntax as issued at the sender terminal equipment and the response displayed at the receiver terminal equipment when the packet is received. 1. Direct Text Data Transmission transmit: TXT [destination address]{source address}[message] receive: RXT [source address][message] CR/LF 2.

  • Page 30: Headerless Stream Mode

    Headerless stream Mode 3.3.1 Operation in the headerless stream mode The headerless stream mode is a specific transmission mode to set transmission data without the packet header, employing the protocol of the packet transmission mode. Parameters such as receiver or repeater addresses are set either by the memory register or by the command.

  • Page 31: Power Down Mode

    Set REG18:bit 5 whether the repeater is used or not. The address of the repeater is set using REG08 and REG09 or PAS command. Power Down Mode The FDL01TU has three power down modes. Select the mode according to the power supply operating conditions such as battery powered application. (1) Active Mode This mode is not the power down mode but always capable of transmitting and receiving data.

  • Page 32: Frequency Grouping

    Frequency Grouping 3.5.1 Frequency Allocation The FDL01TU can operate on 76 available frequencies between 2403 MHz and 2480 MHz with 1 MHz separation between each frequency. See the table below for the exact frequency assignments. Freq.No. Freq.(MHz) Freq.No. Freq.(MHz) ０...
  • Page 33 3.5.2 Frequency Group Operation The FDL01TU can operate on a fixed frequency or on any frequency in a set of frequency group. Multiple FDL01TU systems can be use different frequency groups and operate in the same area without mutual interference between the systems. When the RF environment is relatively clean, wireless channel links can be made on a fixed, clear frequency (no interference) by using Grouping Method A.

  • Page 35: 4 4 4 Function Control Methods

    SECTION FUNCTION CONTROL METHODS...

  • Page 36: Interface

    Interface 4.1.1 Pin Assignment The figure below shows the pin location of the serial communication connector, following the DCE (Data Communication Equipment) specification. # 14 Figure 4–1: Serial Communication Connector Location Name Abbreviation Function Carrier Detect Out DCDO output carrier detect output Receive Data output received data output Transmit Data...

  • Page 37: Serial Interface Setting

    RS485 driver IC chip. As for the RS232C interface, no connection is required because it is pulled up inside. Since the interface level of the FDL01TU modem is CMOS, the level conversion circuit must be provided outside for connecting it with the RS232C or RS485 interface. For an example of the level conversion circuit, see p.64 C...

  • Page 38: Terminal Software Setup For Memory Register Control

    Terminal Software Setup for Memory Register Control Communication or terminal software is necessary to set the memory registers. Nearly any PC communication software can be used. Launch the communication software and set the terminal’s communication parameters as shown below. Refer to your specific communication software instructions how to set these parameters.
  • Page 39 If the memory contents are lost or corrupted, they can be restored to CAUTION original default settings by reinitializing them. (See the section below titled p.25 M EMORY EGISTER NITIALIZATION Input character arrays of commands quickly and sequentially. Too slow input (taking more than 5 seconds in the initial setting) results in command error.

  • Page 40: Command Control

    Command Control Some FDL01TU parameters can be changed by issuing commands from the terminal equipment. Various applications can be supported with the flexibility that command control offers. Command Entry When a command is issued to the modem from the terminal equipment, a command •...

  • Page 41: 5 5 5 Memory Register Description

    SECTION MEMORY REGISTER DESCRIPTION...

  • Page 42: Memory Register Description

    Memory Register Description The FDL01TU modem contains 28 memory registers which are used to control and store communication parameters and operation mode settings. After rewriting new register settings, the power must be cycled, a hardware reset asserted, or a software RST command is issued to validate the new settings.
  • Page 43 Valid values are 000 to A23(1023). • REG03: Reserved [default value: F0H] The FDL01TU does not use this register. Keep the default value as it is. • REG04: ID Code 1 [default value: 00H] Used with ID code 2 (REG05), set the ID code. Valid values are 000 to 255.
  • Page 44 REG06: Frequency Group [default value:C00] Refer to p.18 F in Section 3, for a detailed description of the REQUENCY ROUPING • frequency operation modes. Frequencies Method Group Numbers per Group 0 to 75 0 to 37 0 to 24 0 to 18 0 to 11 0 to 0 to...
  • Page 45 REG11: Retransmission Count [default value: 32H] Sets the maximum number of packet retransmission attempts. Valid values are 000 • to 255. When retransmission exceeds the retransmission count (retransmission count plus • one), the modem outputs an error response to the terminal equipment. REG12: Roaming Threshold [default value: 50H] At the time to set the frequency roaming (REG19:bit 2 is 1), set the receiving...
  • Page 46 Packet transmission mode Headerless stream mode Table 5–7: Protocol Bits 5: Reserved The FDL01TU does not use this register. Keep the default value as it is. • Bit 4 Transmission format transmit in the text form (default value) transmit in the binary form Table 7–4 Transmission format...
  • Page 47 (REG00), the data is discarded (data cannot be received). REG19: Communication Setting 2 [default value: 00H] Bit 7: Reserved The FDL01TU does not use this register. Keep the default value as it is. • Bit 6: Diversity Reception Disable diversity reception (default value) Enable diversity reception Table 5–6: Diversity Reception Settings...
  • Page 48 Table 5–11: Beacon Transmission Enable or disenable beacon transmission in packet transmission mode. • Set roaming function with combining bit 2. • Bit 0: Reserved The FDL01TU does not use this register. Keep the default value as it is. •...
  • Page 49 REG20: Serial Interface Setting 1 [default value: 05H] Bit 7: Data Length 8 bit data bytes (default value) 7 bit data bytes Table 5–13: Data Length Settings Bit 6: Parity Bit No parity bit (default value) Parity bit Table 5–14: Parity Settings Bit 5: Even/Odd Parity Even parity (default value) Odd parity...
  • Page 50 REG21: Serial Interface Setting 2 [default value: 09H] Bits 7 – 4: Reserved The FDL01TU does not use this register. Keep the default value as it is. • Bit 4: Command Header Use REG 10 character Use Break signal Table 5–16: Command Header...
  • Page 51 Issue the REN command to enable reception. • Bit 6: Reserved The FDL01TU does not use this register. Keep the default value as it is. • Bits 5 – 4: DCD (Data Carrier Detect) Bit 5 Bit 4 Setting Ignore DCD input; DCD output always ON (default value) Ignore DCD input;...
  • Page 52 1. Bit 3: reserved The FDL01TU does not use this register. Keep the default value as it is. • Bit 2: RS485 collision avoidance regular interval output...
  • Page 53 To use this function, set REG23:bit 1 of all RS485 multi-dropped modems to 1. And • set all the RS485 Packet Interval (REG07) to different values more than 1.5 bytes each. Further set this bit of the modem, the RS485 Packet Interval is set to the longest, to 1.
  • Page 54 REG24: Special Mode Settings [default value: C0H] Bit 7 : reserved The FDL01TU does not use this register. Keep the default value as it is. • Bit 6: Transmission trigger (Headerless stream mode) Need trigger even if data number exceeds 255 bytes(default value) Transmit without trigger when the data number exceeds 255 bytes Table 5–26: Transmission trigger setting...
  • Page 55 Sets the vacant duration time interval to recognize as the end of the message data • input in the headerless stream mode. REG27: Reserved [default value: 00H] The FDL01TU does not use this register. Keep the default value as it is. •...

  • Page 57: 6 6 6 Command Set Description

    SECTION COMMAND SET DESCRIPTION...

  • Page 58: Command Set Description

    Command Set Description This section provides a description of each command available in the FDL command set. The table below lists each command and it applicability in each operation mode. Command Function Reference All Memory Resisters Clear Transmit and Receive Buffers Connect Wireless Link Reference and Set the Destination Address Read Signal Strength...
  • Page 59 Reference All Memory Registers Syntax ARG{Local Station Address} Local Station Address : local station address for 485 mode (000 to 999). Response All settings are indicated (REG00 to REG27) N0: command error (Except 485 mode) Function Recalls the contents of all 28 memory registers. Example : Recall the contents of all the memory registers >...
  • Page 60 Connect Wireless Link Syntax CON(destination address) destination address : 000 to 999 Response : connection established : command received, link established : command error : connection failed – no response from destination modem : connection failed – local modem already connected to a remote modem.
  • Page 61 Response : current value (reference) : command accepted (setting) : command error Function References or sets the destination address of the modem connection established with in the data transparent mode and headerless stream mode The current DAS value can be referenced by entering the command with no parameter.
  • Page 62 Disconnect Wireless Link Syntax Response : connection established : command received, link disconnected : command error : link disconnect failed : link is disconnected Function In data transparent mode, this command requests wireless disconnection from the remote modem. Example >@CON002 : request wireless connection to station 002 ↵...
  • Page 63 Example > : reference the current grouping method and frequency CR/LF number : output current value (grouping method F: group number 00) <F00 CR/LF : set grouping method to E (6 groups) and group number to >@FRQ:E03 CR/LF <P0 : command accepted CR/LF Frequencies Method Group Numbers...
  • Page 64 If the group address (REG01) is designated while RS485 multi-drop connection is being made in the RS485 mode, the local station address of all modems will be initialized to 000. Exercise care when issuing this command. For a list of the factory default values, see the section titled p.27 M EMORY EGISTER ESCRIPTION...
  • Page 65 This command enables serial data output after it has been disabled with the ODA command. When the modem’s power is turned on (or a reset), the modem is in the state to enable the received data output. Example > : disable serial output of received wireless data CR/LF <P0 : command accepted...
  • Page 66 Disable Wireless Reception Syntax RDA{Local Station Address} Local Station Address : local station address for 485 mode (000 to A22). Response : command accepted : command error (Except 485 mode) Function Disables wireless reception in the packet transmission mode. The status when the modem is powered ON or reset follows bit 7 of REG22. Example : disable wireless reception >...
  • Page 67 While rewriting the memory register, do not turn off the power until response is output. Otherwise, the memory registers content may be collapsed. When the response of the memory register write error is output, set the values after initializing the memory register. Reception Enable Syntax REN{Local Station Address}...
  • Page 68 To use it more securely, it is recommended to readout the local serial ID code with TID command and pad it (either all or a part of it) in the transmitting packet. When no packet is received, “All Zero” is displayed as the result of this command execution.
  • Page 69 This function is used to save the current consumption when no transmit/receive are required. Example : turn off RF circuit block > CR/LF <P0 : command accepted CR/LF : turn on RF circuit block > CR/LF <P0 : command accepted CR/LF RF Circuit Block Power Up Syntax...
  • Page 70 Example > : reset the modem CR/LF <P0 : command accepted CR/LF Note When a serial communication parameter in memory register is changed with REG command, the response of “P0” returns according to the changed setting parameter, which may cause communication error. In such a case, set the communication parameter of the terminal equipment in correspondence with the new setting immediately after the issuance of RST command.
  • Page 71 X X X X X X X X Name Status Connection Connected Disconnected Reception Disabled Enabled Output message Disabled Enabled Receive buffer Data exist Data empty Transmit buffer Data exist Data empty Reserved Reserved Reserved Figure 6–2: Modem Status Bit Description Example >...
  • Page 72 <P1 : data being transmitted CR/LF <N1 : transmission failed, no response from destination station CR/LF Notes Set the message length to 255 byte or less. The message length exceeding 255 byte will be command error. Message must be terminated with 2 byte (CR/LF) character, others will be command error.
  • Page 73 Display Local Station Serial ID Syntax TID{Local Station Address} Local Station Address : local station address for 485 mode (000 to 999). Response XXXXXXXXXXXX : displays the local serial ID code (12 digits) : command error (Except 485 mode) Function Readout the local serial ID code of the modem and display it.
  • Page 74 For broadcasting messages to multiple modems, set the destination address to 255. In this case, the modem retransmits the message the number of times of the Retransmission count plus 1, and then it will return “P0”. In case the global addressing command is issued to plural modems connected by RS485 multi-dropping interface, the transmission stops when any modem outputs “P0”, “N2”...
  • Page 75 <P0 : data transmission succeeded CR/LF >@TXT003MAIL : transmits MAIL from station 001 to station 003 CR/LF <P1 : data being transmitted CR/LF <N1 : transmission failed. no response from destination station CR/LF Notes Set the message length to 255 byte or less. The message length exceeding 255 byte will be command error.

  • Page 77: 7 7 7 Appendix

    SECTION APPENDIX Futaba Corporation Rev. 020323-01...

  • Page 78: Conversion Circuit

    Conversion Circuit Examples of the level conversion circuit are shown as a reference, which is just for the confirmation of system operation. This example does not guarantee the operation under users’ actual operation environment. 7.1.1 RS-232C Level Converter Wire the control line when necessary. Tie down unused input pin(s) to GND and leave the 485ENB pin open.

  • Page 79: Specification Of The Connectors

    (2) Antenna connector RF connector: HIROSE U.FL-R-SMT The antenna connector is guaranteed for 30 times of plugging in/out. When plugging out the antenna connector, use the specially prepared tool of E.FL-LP-N, provided by HIROSE (HIROSE Product No. CL331-0441-9). Futaba Corporation Rev. 020323-01...

  • Page 80: Specification

    Specification 7.3.1 Radio Characteristics Engineering standard FCC Part 15.247 (no user license required) RF power output 6mW/MHz max. Modulation Direct sequence spread spectrum Communication scheme Single communication Frequency band 2403.328 to 2480.128 MHz Frequency channel 76 channels （26 channels available for simultaneous communication in one area） Channel management Fixed mode or group mode Fixed mode: communication by fixing 1 arbitrary frequency from 76 freq.
  • Page 81 † Operating distances depend on the conditions such as obstructions and electrical interference. Under ideal, line-of- sight conditions, reliable operating distances greater than specified may be achieved. Optional, directional antennas can significantly increase the operating range. * Specifications and appearance are subject to change without prior notice. Futaba Corporation Rev. 020323-01...

  • Page 82: Dimensions

    Dimensions 7.4.1 FDL01TU 7.4.2 Communication Cable...
  • Page 83 Chiba, 299-4395 JAPAN Tel: +81 (475) 32-6173, Fax: +81(475) 6179 Internet: www.futaba.co.jp In the United States Futaba Corporation of America Industrial Radio Control Department 1605 Penny Lane Schaumburg, IL 60173 Tel: (847) 884-1444, Fax: (847) 884-1635 Internet: www.futaba.com In the Europe Pending.
