CoverCraft WeatherShield HD Use And Care Instructions

1 - Using a large commercial washer without agitator, wash the cover using 1/4
cup of Simple Green All-Purpose Cleaner. Put the cover in the washer and
pour the cleaner in the tub after it's filled with warm water or, for some wall
mounted commercial units pour it directly in the machine, then put in the cover
and start the machine. Use a "gentle" cycle if available.
2 - Rinse the cover twice (2X) to remove all the cleaner.
3 - Dry using low heat.
A cover may also be cleaned by turning it inside-out on the vehicle.
1 - Mix one ounce Simple Green All-Purpose Cleaner per quart of warm water.
2 - Spray or sponge onto cover.
3 - Rinse with plain water (until no suds) and allow to air dry (or use a dryer).
Simple Green is available in most world markets.
If you have any questions, contact them at
or visit their web-site...www.simplegreen.com

OPTIONAL LOCKING DEVICE

Your new cover is equipped with plastic (non-scratch) grommets, reinforced into the
bottom edge on both sides of the cover. A plastic-coated, steel cable with padlock
and keys is available to lock through the grommets and secure the cover to the
vehicle. Consult your dealer for availability.
An added theft deterrent is the application of large letters on the sides of the cover.
Print your name or license number on the cover to make it uninviting to a prospective
thief. (Note - see warning for use of ink and markers)

LIMITED FIVE (5) YEAR WARRANTY

WeatherShield® HD fabric covers are warranted for five (5) years from date of purchase to the
original purchaser. Save your receipt! Warranty coverage protects against defects in material
and workmanship, as well as the fabric becoming unserviceable during normal use. After
factory inspection, we will repair or replace the cover or specific panels judged to be unusable.
Warranty does not cover fading, which occurs naturally on all products used outdoors. Highly
water resistant, this fabric is not waterproof - it is breathable to allow moisture, condensation
and heat to escape from under the fabric.
To process your warranty claim, contact:
COVERWORLD
Unit 2, 37 Premier Circuit, Warana, QLD, 4575
P (61) 7 5493 1400
orders@coverworld.com.au
NOTE - Car covers are not designed for use when towing. Serious damage
can occur to the cover and the paint surface of the vehicle may also be
damaged. If you use a cover for towing you do so at your own risk.
1-800-228-0709 (USA)
Form # 1320455 HG (2/10)
Your new WeatherShield® HD cover is manufactured with a durable solution-dyed
woven polyester outer shell, finished with a patented immersion process that uses
heat and pressure to permanently encase the fibers to shed moisture, dust, dirt, bird
droppings, tree sap and grime.
outstanding protection against most natural elements and can be used for storing
vehicles outside, and indoors as well.
If your vehicle has an outside radio antenna which will not retract flush with
the vehicle body, you will have to provide an opening in the cover. We have
included a non-corrosive plastic grommet set for the antenna opening.
1) The most accurate way to make an antenna opening is to remove the antenna
and install the cover on the vehicle, making sure it is properly aligned and
positioned. Using a sharp pencil, punch a hole through the fabric at the antenna
location. Be careful to avoid hitting the vehicle finish with the pencil. If the antenna
is not easily removed, see procedure #2.
2) Place the cover on the vehicle except for the fender or body panel where the
antenna is located. For example, if the antenna is located on the front passenger
side fender, roll or fold the cover away from the antenna and cover all the remaining
area of the vehicle. (Do not attempt to place the cover over the top
Center the cover, align both seams with the roof edges and be sure the cover is
pulled down evenly over the front and rear bumpers. Carefully unfold the portion
of the cover that is next to the antenna and position it next to the base of the antenna.
Recheck the overall positioning of the cover to make sure it has not moved on the
vehicle. Make sure the cover lies flat over the hood and roof areas of the vehicle.
Mark the cover with the location of the antenna base and make a hole with a sharp
pencil.
Use sharp scissors to make the hole opening 3/4 inch in diameter and install the
grommet as shown in the diagram to the right. The outside grommet ring fit is very
tight. Place the cover on a CLEAN hard surface, position the the inside grommet
through the opening you made
and then secure the outside grom-
met snap-ring in place using a
rubber mallet. Do NOT use ex-
cessive force or the ring can be
damaged. Do NOT install the
grommet with the cover on the
vehicle.
Use and Care
Instructions
This high-performance fabric helps provide
of t
he antenna.)
