Omnimount HM1 Installation Instructions Manual

OM #
OM1004469
PN # HM-1 = L27-OM1004469-PRO-060710vB
HM1
37"
USE WITH PRODUCTS LARGER THAN THE MAXIMUM WEIGHT AND SIZE MAY RESULT IN INSTABILITY CAUSING POSSIBLE INJURY.
EL USO CON EL PRODUCTOS MÁS GRANDE QUE EL PESO MÁXIMO Y TAMAÑO PUEDE CAUSAR INESTABILIDAD Y POSIBLEMENTE HERIDAS. NE PAS
UTILISER DES PRODUITS QUI SONT PLUS GRANDS DE LA CAPACITÉ DE CHARGE OU DES DIMENSIONS MAXIMALES

CONTENTS

Screws / Hardware for Flat Panel (Monitor
Kit M-V-vC)
Part # Qty Description
M-A 4 Philips Screws M4 x 12mm
M-B 4 Philips Screws M4 x 30mm
M-C 4 Philips Screws M5 x 12mm
M-D 4 Philips Screws M5 x 30mm
M-E 4 Philips Screws M6 x 12mm
M-F 4 Philips Screws M6 x 30mm
M-G 4
Round Spacers: M4 - M6
M-A M-B
M-C M-D
M-E M-F
M-G
80 lbs
36.3 kg
OM1004469vB
Part # Qty
P-A 1 Allen Wrench 3mm
P-B 4 Screws M5 X 25mm
P-C 4 Screws M5 X 45mm
P-D 4 Screws M5 X 57mm
P-E 2 Security Screws M5 x 8mm
P-F 9 Screws M5 x 8.5mm
P-G 2 Washers
P-H 2 Screws M5 x 26.5mm
P-I 1 Security Allen Wrench 4mm
P-J 4 Washers
P-A
P-B P-C
P-E
P-G
Description
P-I
8
P-E
P-D
P-F
P-J
P-H
VERSION
7
5
4
3
4
2
1
Contents
Part # Qty CONTENTS
1 1 Threaded Reciever
2 1 Stator Assembly
3 1 Rotor Assembly
4 2 Bushing
5 1 Retaining Assembly
6 1 Rotation Stop
7 1 Monitor Plate
8 1 Cover Assembly
B
P-H
P-G
P-F
6
P-F
P-B –
P-D
