- Page 1 GE616 Proximity Reader Last Update August 24, 2005...
-
Page 2: Table Of Contents
GE616 Proximity Reader Last Update August 24, 2005 Table of Contents 1. Important safety instructions 2. Introduction 3. Identifying supplied parts 4. Specification 5. Installation 6. Wire Connection to Controller 7. Wire Color Table of the Reader 8. Operation 9. The Maximum Length of the Wiegand Cable 10. -
Page 3: Important Safety Instructions
GE616 Proximity Reader Last Update August 24, 2005 1. Important safety instructions To prevent injuries to persons and damages to property, please read all the instructions and follow them whenever you deal with this product. After reading, please put this instruction manual where it can be easily seen for the system operator. - Page 4 GE616 Proximity Reader Last Update August 24, 2005 ON MAINTENANCE Do NOT use any kind of liquid for cleaning. - There may be a risk of electric shock, fire or heavy damage of the unit. Use an air spray, if needed.
-
Page 5: Introduction
GE616 Proximity Reader Last Update August 24, 2005 2. Introduction The GE616 is an elegant looking and an attractive 4" read range proximity reader which can be mounted to metal door frame (mullion) or any flat wall surface. The GE616 is epoxy potted that ensure you successful operation even in harsh environments. -
Page 6: Specification
GE616 Proximity Reader Last Update August 24, 2005 4. Specification Read Range/Time Up to 4"(10cm) / 30ms Input Voltage/Current DC 5V ~ 17V, Max. 100mA Output Format 26 bit Wiegand External Buzzer Low Active, DC 0 ~ 12V, Control Input Max. -
Page 7: Wire Connection To Controller
GE616 Proximity Reader Last Update August 24, 2005 6. Wire Connection to Controller... -
Page 8: Wire Color Table Of The Reader
GE616 Proximity Reader Last Update August 24, 2005 7. Wire Color Table of the Reader POWER Power(DC +5V~+17V) DC(+) Red wire Power(DC Ground) DC(-)(GND) Black wire INPUT Buzzer control input BUZZER Blue wire LED control input Yellow wire OUTPUT(Wiegand Format) -
Page 9: The Maximum Length Of The Wiegand Cable
GE616 Proximity Reader Last Update August 24, 2005 8-4. Buzzer Control When the reader reads proximity card, only one beep sound generates in normal operating mode but you can generate more beep sounds to distinguish whether the access is granted or denied. -
Page 10: Fcc Registration Information
GE616 Proximity Reader Last Update August 24, 2005 10. FCC Registration Information FCC REQUIREMENTS PART 15 Caution: Any changes or modifications in construction of this device which are not expressly approved by the responsible for compliance could void the user's authority to operate the equipment. -
Page 11: Warranty And Service
11. Warranty and Service TWO YEARS LIMITED WARRANTY AND LIMITATION OF LIABILITY GE Security warrants that this product will be free of defects in material and workmanship for a period of two years from date of purchase under normal consumer use. Losses caused by modification, improper installation or use, abuse, and acts of God are not covered. - Page 12 GE616 Proximity Reader Last Update August 24, 2005 The specification contained in this manual are subject to change without notice at any time. GE Security Asia Ltd. Suites 503-506, 5/F Tower 1, The Gateway, 25 Canton Rd, TST. Kowloon, Hong Kong...
