- Page 1 Studio 300/400 Monolight with Built-in R2 2.4GHz Radio Remote System FPLFS300B/ FPLFS400B...
- Page 2 Thank You for Choosing Flashpoint! The new Flashpoint Studio300 R2 and Studio400 R2 are 300 and 400 watt second monolights, designed to be compact AC studio members of the R2 Family of wireless radio controlled flashes. The small units deliver GN 190 (ft) / 58 (m) - Studio300, and GN 213 (ft) / 65 (m) - Studio400, respec- tively, with standard Bowens reflectors and modifiers.
-
Page 3: For Your Safety
For Your Safety To prevent damage to the product or injury to you or to others, read the following safety precautions in their entirety before using this device. Keep these safety instructions where users can read them for ready reference. Do not disassemble or modify There are high-voltage components inside the unit. -
Page 4: Names Of Parts
NAMES OF PARTS er Cord Socket 11. Optical Slave Light Sensor 1. AC Pow 2. Sync Cord Jack 12. Modeling Lamp Indicator 3. Power Switch 13. Power Ready Indicator 4. Open Flash Test Button 14. Select Dial + SET Button 5. - Page 5 LCD Panel 1. R2 2.4G Wireless Transmission 9. Modeling Lamp is OFF 2. Wireless Channel Selection 10. Modeling Lamp is in the PROP mode 3. Wireless Channel Switch Code 11. Modeling Lamp shows the power in 4. Slave Model Indicator 5.
-
Page 6: Power Connection
Operations 1. Remove the lamp cover. Install the modeling lamp and attach a standard reflector. To detach the standard reflector, press the release button on the flash head and turn the standard reflector counterclockwise. 2. Attach the flash unit onto an appropriate light stand. -
Page 7: Power Output Control
Power Output Control The Select dial (14) varies the power output, setting the light requirements as needed. The power is adjustable in thirds of a stop from 1/16 to 1/1, in increments of tenths of a stop, clearly shown on the LCD display (10). “--” on the display indicates that the flash triggering function is turned off. - Page 8 The camera shutter-release button transmits your com- mands to trigger the flash. • For full instructions on the use of R1 series remote control, see the The Flashpoint R1 Transmitter and Receiver Set (FPRRSL) user manual.
-
Page 9: Flashtube Replacement
Replace the ground wire on the flash tube as on the original tube. TECHNICAL DATA Flashpoint Model Studio 300 Monolight Studio 400 Monolight Max Power (Ws) 300Ws 400Ws Guide Number( ISO 100) -
Page 10: Maintenance
Maintenance of the flash must be performed by our authorized maintenance department which can provide original accessories. The flashtube and the modeling lamp are user-replaceable. Replacement tubes and lamps can be obtained from the Adorama/Flashpoint. This product, except consumables e.g. flash tube and modeling lamp, is supported with a one-year warranty. - Page 11 Flashpoint’s option, to repair or replace the hardware, provided that the hardware is returned to the point of purchase or such other place as Flashpoint may direct with a copy of the sales receipt or dated itemized receipt. Flashpoint may, at...
