- Page 1 SCM Microsystems (India) OEM MANUAL PACT (Contact/Contact-less) Physical access control terminal OEM Manual – PACT-STC II Page 1 of 10...
-
Page 2: Table Of Contents
SCM Microsystems (India) Contents Product Specification ........................ 3 Overview........................... 3 Product Features ........................3 Hardware Specification ......................4 Power Supply..........................4 Clock Frequency........................4 Contact interface details ......................4 Contactless Reader ........................4 User Interface ........................... 4 2.5.1 Keypad ..........................4 2.5.2... -
Page 3: Product Specification
Product Specification 1.1 Overview The term PACT is the acronym for Physical Access Control Terminal. The PAT1241 has three user interfaces, the Contact, the contactless Smart Card and the Pin-pad and is intended for indoor use. Apart from this there is the Access granted/denied indication LED and Buzzer. The PAT1241 is based on the PACT STCII-B ASIC and is designed for indoor operation. -
Page 4: Hardware Specification
SCM Microsystems (India) Hardware Specification 2.1 Power Supply +12V DC is taken from the input to the control panel and regulated to +5V DC and +3.3V DC on the PAT13X1 PCBs. Connect the Shield pin of the reader to the base-plate and the shield of the cable to the base-plate. -
Page 5: Buzzer
SCM Microsystems (India) 2.5.3 Buzzer • User feedback (beep) with different sounds. 2.5.4 Installation Fix the base-plate on the wall and then mount the reader with a switch for tamper evidence in between . Wires required for connection to the alarm needs to be connected to the switch, prior to mounting the reader. - Page 6 SCM Microsystems (India) OEM Manual – PACT-STC II Page 6 of 10...
-
Page 7: Cable Specifications
SCM Microsystems (India) 2.5.5 Cable Specifications Cable to be used between the Reader and the Control Panel should be 22 (7/30) AWG OEM Manual – PACT-STC II Page 7 of 10... -
Page 8: Software Specifications
SCM Microsystems (India) Software Specifications 3.1 Contact Card Parameters Some important smart card parameters, supported smart card types, maximum operable smart card frequencies, operating voltages etc., are detailed in the tables below. ICC Parameters Value/Description Class A Smart Cards Supported... -
Page 9: Regulatory Compliance
SCM Microsystems (India) Regulatory Compliance This section describes the product's compliance with U.S. and international safety and electromagnetic compatibility (EMC) regulations. 4.1 Safety Regulations Below Table mention the safety regulations the product complies with when correctly installed in a compatible host system. - Page 10 SCM Microsystems (India) The following information is provided to address worldwide product ecology concerns and regulations. 5.3.1 Disposal Considerations This product contains the following materials that may be regulated upon disposal: lead solder on the printed wiring board assembly. 5.3.2 Recycling Considerations SCM encourages its customers to recycle its products and their components (e.g., batteries, circuit...
