Warning WARNING : FAILURE TO COMPLY WITH THE FOLLOWING WARNINGS MAY SIGNIFICANTLY SHORTEN THE PRODUCT’S LIFE TIME, AND LEAD TO FAILURES AS WELL AS HAZARDOUS CONDITIONS*� COMMON SENSE MUST ALWAYS PREVAIL WHEN USING ANY ELECTRONIC CONTROL� *ONLY QUALIFIED PERSONNEL ARE TO SERVICE THIS UNIT� THERE ARE NO USER SERVICEABLE PARTS INSIDE�...
Larger, faster, and cooler touch screen display Driven by a powerful 400 MHz processor, the k1000 keypad features an eye-catching 4�3 inch 256K color LCD capacitive touchscreen display resting within a thin and beautiful enclosure that houses its cutting-edge electronics�...
Keypad functions in.k1000 keypad layout direct to function selection wheel (settings and all-on or all-off key additional options) (one touch activation) mode selection wheel (settings and on-screen accessories) system messages and reminders interactive display icons (main spa functions) Power Touch the screen to turn on the keypad� 3 minutes after the last pump is turned off, the screen will shut off if there is no touch activity�...
Keypad functions Start or stop accessories To start or stop an accessory, touch the associated icon� Icons will become animated when their accessory is turned on, and animation will stop when turned off� Icons on the screen will reflect the speed or state of the devices running on your spa�...
Keypad functions Water temperature The temperature shown at the bottom of the screen shows the current water temperature� Use the Up and Down icon to set the desired temperature� The set point will appear in blue� After 3 seconds without any change to the set temperature value, the current water temperature will reappear�...
Keypad functions Contrast page Use this page to change the display contrast� Settings In the Settings page you can access the following: • WaterCare • Maintenance • Date & Time • Keypad • Electrical Config • Wi-Fi • About To select an item, slide the right wheel until the desired icon is highlighted in the middle or press on the menu name�...
Keypad functions Water care The Water Care page will help you set up your ideal filtration and heating settings� Choose between Away from Home, Beginner, Energy Savings, Super Energy and Weekender, depending on your need� Touch the Water care name to choose your setting� A green checkmark will appear on the selected icon to confirm your choice �...
Keypad functions Modifying schedules To modify a Water Care category, touch the pen icon at the right end of the desired watercare to open the selected Water Care menu� Touch the Economy tab to change the economy setting and filter cycle tab for the filtration settings (or schedules)� You can add economy or filtration schedules by touching the «...
Keypad functions Date and time Simply touch the item you want to change� Set date Here you can adjust the year, month and day� Simply swipe up and down the column you want to change, and select the desired value� When done, touch the calendar icon at the right of the screen�...
Keypad settings Here you can adjust the Temperature Units, Day/Night contrast, and Display orientation and language� Simply touch the item you want to change� Temperature units Choose the appropriate units to display temperatures� Display page Use this page to change the display orientation�...
(i�e� a SwimSpa installation), the master unit’s chosen configuration must support a slave unit� If, after re-booting, the chosen configuration does not support SwimSpa installations, the in�k1000 will return (after about 45 seconds) to this configuration menu and prompt the user to select a configuration number again�...
Wi-Fi network a green check mark will appear in the Wi-Fi menu, and the network name will appear in the Settings menu� About This section shows information about the in�k1000 software number, and the revision numbers of the different components of your system�...
Keypad functions Wipe screen This message appears when too much water is detected on the touch screen� Simply wipe away excess water� in.stream 2 functions This menu is available only if the in�stream 2 audio station is detected in the spa accessories� The audio page will allow you to control the active audio source�...
This menu is available only if the in�clear is detected in the spa accessories� The k1000 keypad can be used with the in�clear sanitation system� The in.clear menu allows you to configure your maintenance settings and boost levels� The main in.clear menu shows the current status of the sanitation system, whether it's on, and if it's generating bromine or not�...
Page 17
Keypad functions in.clear on/off Use the On/Off submenu to turn on or off the in�clear sanitation system� Bromicharge level ™ The Bromicharge page allows you to see the current level of sodium bromide in the water� Ideally, you should aim to be near the center of the green area of the gauge�...
Error messages The list below shows the different error messages that can appear on the home screen� Refer to the troubleshooting and error codes section of the TechBook for your spa pack system� Please note that if you are in a swim spa configuration, the message may be followed by "Master" or "Slave" to designate from which pack the error is coming from�...
Feature matrix The following table presents the features and/or options available for the in�k1000 keypad, and the earliest software version at which this feature/option is available� All versions greater than the earliest version continue to support the feature� Keypad functions...
Specifications Part number 0607-005024 Model IN�K1000-BK-GE1 Environmental Operating temperature: -4°F (-20°C) to 149°F (65°C) Storage temperature: -22°F (-30°C) to 185°F (85°C) Water ingress protection: IPX5 Mechanical Weight: 1�05 lbs (0�48 kg) Dimensions (W x H x D): 7,49" x 5,17" x 1,93"...
