Electrical Parts List - Samsung CL15A8L7X/GSU Service Manual

Chassis : ks2a(n).
Hide thumbs

Advertisement

7. Electrical Parts List

7-1 CL15A8L7X/STR (CL15A8L7X/STR and CL15A8L7X/GSU Dissimilar parts)
Loc. No.
Code No.
Description ; Specification
ASSY PCB MAIN(OPT)
* AA94-01431EASSY PCB MAIN(OPT);CL15A8L7X/STR,KS2A,PERU,-
ASSY CRT
* AA94-02410AASSY CRT;A36QDT351X,+380mG,15INCH,BEAR,CT-15A8,-
AA03-00146ACRT COLOR;-,A36QDT351X,+380mG,15inch,90,57%,FLAT
7-2 CL15A8L7X
Loc. No.
Code No.
Description ; Specification
ASSY PCB MAIN(OPT)
BUYER : G/SUPPLY, RCL
* AA94-01431TASSY PCB MAIN(OPT);CL15A8L7X/GSU,KS2A,CH
* AA94-01431SASSY PCB MAIN(OPT);CL15A8L7X/RCL,KS2A,KOREA,-
C102
2401-002463 C-AL;470uF,20%,16V,GP,TP,8x11.5,5
C103
2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
C104
2401-001363 C-AL;470uF,20%,16V,GP,TP,10x12.5,5
C105
2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm
C106
2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5
C115
2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C116
2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C201
2401-000553 C-AL;1uF,10%,50V,GP,TP,5x11,5
C202
2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C203
2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C206
2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C211
2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3
C212
2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm,5
C213
2301-000247 C-FILM,PEF;33nF,5%,50V,TP,8.1x4.5x13mm,5
C214
2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C215
2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C216
2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C217
2401-001026 C-AL;3.3UF,20%,50V,GP,TP,5X11,5
C218
2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C219
2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C220
2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C221
2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C222
2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C223
2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C224
2201-002031 C-CERAMIC,DISC;0.005nF,0.5pF,50V,NP0,TP,
C225
2201-002031 C-CERAMIC,DISC;0.005nF,0.5pF,50V,NP0,TP,
C226
2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C228
2301-000356 C-FILM,PEF;47nF,5%,50V,TP,7.5x4.0x6.5,5m
C229
2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C231
2401-002235 C-AL;10uF,20%,16V,GP,TP,5x11mm,5mm
C232
2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
C233
2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
C234
2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
Samsung Electronics
Remark
Loc. No.
Code No.
* AA94-02412BASSY ACCESSORY;CL15A8L7X/STR,KS2A,PERU
AA63-00239C COVER-AV;21A8,HIPS,-,HB,G4309,SV907P+W971,-
Remark
Loc. No.
Code No.
C235
2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
C236
2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
C237
2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5
C239
2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5
C242
2301-000310 C-FILM,PEF;68nF,5%,50V,TP,8.0X8.5X4.0X5,
C243
2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C244
2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C245
2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C247
2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
C301
2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5
C302
2401-000326 C-AL;100uF,20%,35V,GP,TP,8x11.5,5
C303
2201-002031 C-CERAMIC,DISC;0.005nF,0.5pF,50V,NP0,TP,
C304
2305-000285 C-FILM,MPEF;220NF,5%,100V,TP,10.5X5.5X15
C305
2305-000149 C-FILM,MPEF;100nF,5%,100V,TP,12x12.5x6.5
C306
2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm,
C307
2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5
C308
2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C401
2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5.
C402
2401-001397 C-AL;470uF,20%,25V,GP,TP,10x16,5
C403
2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5.
C404
2401-001397 C-AL;470uF,20%,25V,GP,TP,10x16,5
C407
2301-001338 C-FILM,MPE-PPF;0.68nF,5%,1.6kV,TP,28x7x1
C408
2305-000382 C-FILM,MPEF;4.7nF,5%,400V,TP,-,5mm
C412
2305-000178 C-FILM,MPEF;10nF,5%,100V,TP,-,5mm
C414
2401-002597 C-AL;220uF,20%,35V,GP,TP,10x12.5,5
C420
2301-001065 C-FILM,MPPF;47nF,5%,630V,TP,19x15.5x7,7.
C421
2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5.
C422
2401-001527 C-AL;47uF,20%,250V,HR,TP,13x25mm,5m
C425
2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
C427
2401-002267 C-AL;2.2uF,20%,250V,GP,TP,8x11.5,5
C504
2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5
C505
2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
C506
2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5
C507
2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
C508
2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5
C509
2201-000599 C-CERAMIC,DISC;0.56nF,10%,500V,Y5P,TP,5.
C511
2401-000493 C-AL;10uF,20%,50V,LZ,TP,5x11mm,5mm
C512
2401-000914 C-AL;22uF,20%,16V,GP,TP,5x11,5
C513
2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
C514
2401-000430 C-AL;10uF,20%,250V,GP,TP,10x16mm,5m
C515
2401-001232 C-AL;4.7uF,20%,250V,GP,TP,10x12.5,5
Electrical Parts List
Description ; Specification
ASSY ACCESSORY
Description ; Specification
Remark
Remark
7-1
