OWNER'S MANUAL
READ AND SAVE THESE INSTRUCTIONS
•
Read all instructions carefully before setting up and operating this unit.
•
This manual is designed to provide you with the information needed to set up,
operate, and maintain your radiant heater.
•
Failure to follow these instructions may damage and / or impair its operation.
Advertisement
Table of Contents
Related Manuals for RADtec X15R
Summary of Contents for RADtec X15R
- Page 1 OWNER’S MANUAL READ AND SAVE THESE INSTRUCTIONS • Read all instructions carefully before setting up and operating this unit. • This manual is designed to provide you with the information needed to set up, operate, and maintain your radiant heater. •...
-
Page 2: How Far-Infrared Heating Works
1. INTRODUCTION Thank you for your trust and support in choosing the RADtec Radiant Heater. Please read the instructions carefully before operating this product. You have purchased one of the most advanced heating systems for indoor and outdoor areas. The infrared radiant heater is characterized by a focused distribution of heat, which transports heat evenly to where it is needed. -
Page 3: Product Overview
Subtle, Slimline, No-Glow design The stylish, slimline black face of the RADtec radiant heater does not emit light or glow when in use, blending elegantly into your décor. Ceiling and wall mounting options ensure that your valuable floor, lounge and table space is not wasted. -
Page 4: Performance Features
4. PERFORMANCE FEATURES Coverage Area Table Model No. Indoors Outdoor Enclosed Outdoor Exposed X15R 50ft ~ 4.6m 40ft ~ 3.7m 30ft ~ 2.8m X24R 80ft ~ 7.4m 65ft ~ 6m 50ft ~ 4.6m X33R 110ft ~ 10.2m 90ft ~ 8.4m 70ft ~ 6.5m... -
Page 5: Installation Requirements
2. Installation Conditions: a. Before starting the installation, you must ensure that the operating voltage corresponds to that stated on the RADtec specifications label located on the side-panel of the heater. Supply Voltage fluctuation range should be within ±10%. If condition not met, it must be resolved before installation b. -
Page 6: Installation Instructions
7. INSTALLATION INSTRUCTIONS Model No. Dimension A (in) Dimension B (in) X15R X24R 57.5 31.5 X33R 71.5 43.3... - Page 7 Step 1: Installation of adjusting bracket and sliding bracket. Step 2: Installation of sliding bracket and heater, as arrow points. Step 3: 4 holes in wall and 4 expansion screws.
- Page 8 Step 4: Fix adjusting bracket into wall with expansion screws. Step 5: Installation of two adjusting brackets. Make sure to lock brackets tightly by using the butterfly hand screw.
-
Page 9: Installation Diagram
8. INSTALLATION DIAGRAM 9. REMOTE CONTROL INSTRUCTIONS... -
Page 10: Inspection Items After Installation
10. INSPECTION ITEMS AFTER INSTALLATION Items to be checked Improper installation Is the unit stable? The equipment may fall off or shake Is heat insulation adequate? May damage objects close to unit Is power voltage the same as voltage shown on product nameplate? Equipment failure Is the wired connection correct? Equipment failure... -
Page 11: Product Specifications
Except as provided below, RADtec is not liable for any loss, cost, expense, inconvenience or damage that may result from use or inability to use the heater. Under no circumstances shall RADtec be liable for any loss, cost, expense, inconvenience or damage exceeding the purchase price of the heater. - Page 12 USA. (Within the USA including US 48 States, Alaska, and Hawaii.) 2. This warranty covers only normal use of the heater. RADtec shall not be liable under this warranty if any damage or defect results from (i) misuse, abuse, neglect, improper shipping or installation; (ii) disasters such as fire, flood, lightning or improper electric current;...
- Page 13 RADtec to install. This warranty is null and void if the defect or malfunction was due to damage resulting from operation not within manufacturer specifications.
- Page 14 Warranty Form Cut and fill out warranty card and mail to RADtec.
