- Page 1 Adam Equipment AE-301 INDICATOR P.N. 700660194 Revision B- November 2011 Software rev 2.4 © Adam Equipment Company November 2011...
- Page 2 © Adam Equipment Company November 2011...
-
Page 3: Table Of Contents
BPS = SELECTING BAUD RATE .............. 10 RS-232 INTERFACE ..................11 TECHNICAL PARAMETERS................. 12 ZERO TRACKING ..................12 UNIT SETTING ..................12 CALIBRATION ................... 13 TROUBLE-SHOOTING GUIDE ..............14 SERVICE INFORMATION................15 WARRANTY INFORMATION ................. 16 © Adam Equipment Company November 2011... - Page 4 © Adam Equipment Company November 2011...
-
Page 5: Introduction
Power supply Re-chargeable battery located or mains power Display Large LCD with backlight Calibration Automatic calibration Housing ABS Plastic Dimensions 260 x 155 x 105 mm (w x d x h) Net Weight 1.35 kg © Adam Equipment Company November 2011... -
Page 6: Keyboard And Display
KEYBOARD AND DISPLAY The AE-301 indicator has the following symbols: The scale is at zero A weight has been tared, the display is showing the net weight The battery symbol showing the state of charge. While the battery is being re-charged this symbol will show four bars The weight is stable. -
Page 7: Power Supply
The load cell can be connected in either a 4 or 6-wired configuration. The standard connection is 4 wired. Pin 1 Excitation + Pin 2 Excitation – Pin 3 Signal + Pin 4 Signal – © Adam Equipment Company November 2011... -
Page 8: Operations
• The indicator can be set for different units by pressing the [Unit] key. The options are kilogram, gram, pound and ounce. They can be enabled as needed (see section 6.2). Kilogram is always on. © Adam Equipment Company November 2011... -
Page 9: Weighing
Low Limit. The beep will sound quickly if the weight is above the High Limit. If the sample weight is in between the Limits, the beep does not sound. © Adam Equipment Company November 2011... -
Page 10: Alarm
[Mode] key is pressed. To use any of the parameters see the corresponding section of the manual. • Switch off and switch on again to return to weighing when settings are complete. © Adam Equipment Company November 2011... -
Page 11: Blt = Backlight Control
• When “FIL” is displayed press the [Unit] key to change setting. “FIL= 0FF“ Filtering function is disabled. “FIL= O ” Filtering function is enabled. • Press the [Mode] key to store the setting and move on. © Adam Equipment Company November 2011... -
Page 12: Sdt = Rs-232 Control
[Unit] key to change to the other settings. The options are 1200, 2400, 4800 and 9600. • Press the [Mode] key to store the desired setting. • To return to weighing, switch the indicator off and then on again. © Adam Equipment Company November 2011... -
Page 13: Rs-232 Interface
Zero the indicator to display the net weight. This is the same as pressing [Tare] or [Zero]. Lxx.xxx Sets the lower limit. Same as pressing the [High/Low]. Hxx.xxx Sets the upper limit. Same as pressing the [High/Low]. Disable check weighing. Enable check weighing. © Adam Equipment Company November 2011... -
Page 14: Technical Parameters
• When g is displayed, press the [Unit] key to change to the other setting. “g= 0FF“ Gram unit is disabled. “g= O ” Gram unit is enabled. • Press the [Mode] key to store the desired setting and move to the next unit setting. © Adam Equipment Company November 2011... -
Page 15: Calibration
ADC counts of the selected calibration mass, then press [Mode] again. • The display shows PASS and then returns to normal weighing • Remove the weight and continue to use. © Adam Equipment Company November 2011... -
Page 16: Trouble-Shooting Guide
Load cell damaged Off Center Loading error Overload stops not set correctly Load cell damaged Battery will not charge Incorrect power adaptor being used Charging circuit failure Battery failure Main voltage not present or too low © Adam Equipment Company November 2011... -
Page 17: Service Information
Include any recent history of the unit. For example: -Has it been working since it’s delivered -Has it been in contact with water -Damaged from a fire -Electrical Storms in the area -Dropped on the floor, etc. © Adam Equipment Company November 2011... -
Page 18: Warranty Information
WARRANTY INFORMATION Adam Equipment offers Limited Warranty (Parts and Labour) for the components failed due to defects in materials or workmanship. Warranty starts from the date of delivery. During the warranty period, should any repairs be necessary, the purchaser must inform its supplier or Adam Equipment Company. - Page 19 Shielded interconnect cables must be employed with this equipment to insure compliance with the pertinent RF emission limits governing this device. Changes or modifications not expressly approved by Adam Equipment could void the user's authority to operate the equipment. WEEE COMPLIANCE...
- Page 20 For a complete listing of all Adam products visit our website at www.adamequipment.com © Copyright by Adam Equipment Co. Ltd. All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior permission of Adam Equipment.
