Page 3
Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with Seiko Epson Corporation’s operating and maintenance...
Shut down your equipment immediately if it produces smoke, a strange odor, or unusual noise. Continued use may lead to fire. Immediately unplug the equipment and contact your dealer or a SEIKO EPSON service center for advice. Never attempt to repair this product yourself. Improper repair work can be dangerous.
❏ USB cable (USB interface model only) ❏ Instruction sheet ❏ User’s Manuals (for printer and AC adapter) * The AC adapter is embedded in the printer. * The AC cable may not be included with the printer. TM-C3400 User’s Manual 3...
Installing the power switch cover onto the power switch prevents inadvertent changing of the power switch. WARNING: If an accident occurs with the power switch cover attached, unplug the AC cable immediately. Continued used may cause fire. 4 TM-C3400 User’s Manual...
Page 7
Installing the ink cartridge (See page 6.) Installing the printer driver and connecting the printer to the computer (See page 7.) Setting the DIP switches (See page 9.) Installing the paper (See page 9.) Attaching/adjusting the paper ejection tray (See page 18.) TM-C3400 User’s Manual 5...
Connecting the AC Cable WARNING: Always use the Epson Model M159A (PS-180) as the AC adapter. Using the other AC adapter can result in electric shock and fire. Should a fault ever occur in the AC adapter, immediately turn off the power to the printer and remove the AC cable from the wall socket.
Page 9
Installing the Driver and Connecting to the Computer CAUTION: Be sure to confirm the operating environment (page 20) before installing. You are required to login as a user with administrative rights. Turn off the printer before connecting it to the computer. TM-C3400 User’s Manual 7...
Double-click on the icon for Easy Setup (EPSetup.exe). Network On the screen displayed, click [ Complete the installation by following the instructions displayed. Network settings are also processed during the installation. Cable hook: prevents the cable from falling off. 8 TM-C3400 User’s Manual...
Make sure paper is ejected straight from the paper ejection guides, as shown in the illustration. If paper is not ejected straight due to such causes as an obstruction, the print result may be distorted. TM-C3400 User’s Manual 9...
Page 12
(page 15) ➃ ➃ Adjusting the guides (page 16) Adjusting the guides (page 13) ➄ ➄ Turning on the printer and Loading the paper and loading the paper turning on the printer (page 14) (page 17) 10 TM-C3400 User’s Manual...
Remove the paper left on the paper ejection table. When you change the paper type, open the roll paper cover and the fanfold paper cover to remove the paper. Close the roll paper cover and the fanfold paper cover. TM-C3400 User’s Manual 11...
Page 14
Pull the release lever to open the roll paper cover. If the paper feed guide is attached into the grooves inside of the roll paper cover, slide it in the direction of the arrow to remove it. Close the roll paper cover. 12 TM-C3400 User’s Manual...
Page 15
Push the roll paper guide on the left in the direction of the arrow, and load the roll paper with the printable side up completely inside the printer. Lock the roll paper guide. Unlock the paper ejection guide, using the tip of a tool, such as a pen. TM-C3400 User’s Manual 13...
Page 16
Load the roll paper with the printable side up completely inside the printer. While aligning the roll paper with the paper ejection guide, close the roll paper cover. Turn on the printer, and then the paper is fed automatically. 14 TM-C3400 User’s Manual...
Page 17
Open the fanfold paper cover and take out the paper feed guide. Pull the release lever to open the roll paper cover. Insert the paper feed guide into the grooves inside of the roll paper cover to attach it. Close the roll paper cover. TM-C3400 User’s Manual 15...
Page 18
Slide the paper ejection guide as wide as possible, and lock it. When you install fanfold paper for the first time, or when the paper width needs to be changed, continue to steps 3 and 4. Open the fanfold paper cover and unlock the fanfold paper guide. 16 TM-C3400 User’s Manual...
Page 19
(approximately 100 mm), and then the paper is fed automatically. Place the paper straight at least 40 mm from the printer. 40mm Close the fanfold paper cover. TM-C3400 User’s Manual 17...
Attach the paper ejection tray to the hooks under the paper ejection table. Pull the lever at the bottom-right of the paper ejection tray to unlock it. Slide the bottom tray to align it with the paper length, and lock it. 18 TM-C3400 User’s Manual...
Computers with a processor of 1 GHz or better are recommended. Intel/Pentium/Celeron series, AMD Athlon/Duron family, or processors that are compatible with these are recommended. Windows 2000 256 MB or larger is recommended. Windows XP/2003 Server/Vista 512 MB or larger is recommended. 250 MB 20 TM-C3400 User’s Manual...
6 million passes (3 million passes of carriage back and mechanism forth) Print head 6,000 million shots/nozzle Autocutter Normal paper: 1,500,000 cuts mechanism Fine paper: 750,000 cuts Normal label roll paper: 750,000 cuts Fine label roll paper: 500,000 cuts TM-C3400 User’s Manual 21...
Page 24
(At 40°C {104°F}: up to 1 month) Overall dimensions (H × W × D) 255 × 270 × 255 {10.04 × 10.63 × 10.04”} (The protrusion excluded) Mass Approximately 10.0 kg (Ethernet interface model) dpi: dots per 25.4 mm (dots per inch) 22 TM-C3400 User’s Manual...
Page 63
Microsoft Windows 2003 R2 SP2 Microsoft Windows Vista SP1 仅支持 32 位机型。 电脑 本打印机支持在上述操作系统运行的下述电脑。 ·兼容 PC/AT 建议使用处理器为 1 GHz 或以上的电脑。 建议使用 Intel/Pentium/Celeron 系列、AMD Athlon/Duron 系 列或兼容的处理器。 Windows 2000 建议使用 256 MB 或以上。 Windows XP/2003 Server/Vista 建议使用 512 MB 或以上。 250 MB TM-C3400 使用说明书 61...
Page 64
(在 40°C {104°F} 时 : 最多 1 个月) 总尺寸 (H x W x D) 255 x 270 x 255 {10.04 x 10.63 x 10.04"} (不包括突起部分) 重量 约 10.0 kg (Ethernet 接口机型) dpi: 点 /25.4 mm ( 点 / 英寸 ) 62 TM-C3400 使用说明书...
Page 65
擔任何責任,亦不為使用本手冊中所含之資料而造成之損壞負擔任何賠償責任。 本產品之購買人或第三者因意外、誤用或濫用本產品,或對本產品進行未經授權之修改、修理、或以任何形式 更改本產品,或 (美國除外)沒有嚴格遵守 Seiko Epson Corporation 之操作及維修指示,而對購買人或第三 者所造成之損害、損失、費用、或支出,Seiko Epson Corporation 及其附屬機構皆不須負責。 Seiko Epson Corporation 不須為使用 Epson 原廠產品或由 Seiko Epson Corporation 認可之 Epson 產品以 外之選購品或耗材所造成之損害或問題負責。 EPSON 為 Seiko Epson Corporation 在日本及其它國家或地區之註冊商標。 Microsoft、Windows 以及 Windows Vista 是微軟公司的注冊商標。 The Ethernet interface model of this product includes software developed by the University of California, Berkeley, and its contributors.
Page 83
Microsoft Windows 2003 R2 SP2 Microsoft Windows Vista SP1 僅支援 32 位機型。 電腦 本印表機支援在上述作業系統運行的下述電腦。 ∙相容 PC/AT 建議使用處理器為 1 GHz 或以上的電腦。 建議使用 Intel/Pentium/Celeron 系列、AMD Athlon/Duron 系列或 相容的處理器。 Windows 2000 建議使用 256 MB 或以上。 Windows XP/2003 Server/Vista 建議使用 512 MB 或以上。 250 MB TM-C3400 使用說明書 81...
Page 84
(在 40°C {104°F} 時:最多 1 個月) 總尺寸 (H x W x D) 255 x 270 x 255 {10.04 x 10.63 x 10.04"} (不包括突起部分) 重量 約 10.0 kg (Ethernet 介面機型) dpi: 點 /25.4 mm ( 點 / 英寸 ) 82 TM-C3400 使用說明書...
WEEE (Waste Electrical and Electronic Equipment) Directive This information only applies to customers in the European Union, according to Directive 2002/96/EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL OF 27 January 2003 on waste electrical and electronic equipment (WEEE) and legislation transposing and implementing it into the various national legal systems.
Page 87
Česky Lietuviškai Štítek s přeškrtnutým odpadkovým košem na kolečkách, Užbraukta ratuota šiukšliadėžės etiketė, kurią rasite ant který lze nalézt na výrobku, označuje, že tento product se jūsų produkto, reiškia, kad šis produktas neturėtų būti nemá likvidovat s běžným domovním odpadem. V zájmu išmestas kartu su įprastinėmis buitinėmis šiukšlėmis.
