SkyWay-MAX Subscriber Station Installation Guide
DOCS-1024 v1.0

1. Before You Begin

a. Precautions
Solectek shall not be responsible for any operation of this product which is in violation of local law, creates interference
harmful to other local devices, or results in a malfunction of this product caused by outside interference.
This device must be professionally installed and used in strict accordance with the manufacturer's instructions. However,
there is no guarantee that interference to radio communications will not occur in a particular commercial installation. In case
the device does cause harmful interference with an authorized radio service, the user/ operator shall promptly stop operating
the device until harmful interference has been limited. Solectek Corporation is not responsible for any radio or television
interference caused by unauthorized modification of this device or the substitution or attachment of connecting cables and
equipment other than specified by Solectek Corporation. The correction of interference caused by such unauthorized
modification, substitution, or attachment will be the responsibility of the user.
Solectek shall not be liable for damages associated with the installation and use of this product, including but not limited to
personal or property damage, business losses or infringement of local or national laws.
b. Package contents
Included with the SkyWay-MAX Subscriber Station Unit is the following:
Subscriber Station Unit Chassis
100-240 VAC Power over Ethernet module
Power Cord (bulked packed separately)
Installation Kit, including:
Mounting foot
o
Mounting knuckle
o
bolts, 2
o
flat washers, 4
o
split washers, 4
o
inside tooth washers, 2
o
nuts, 2
o
screw-band clamps, 2
o
Verify that all included items are present before attempting to install the unit.

2. Mounting Procedure

a. Mounting Location - Considerations
The integrated panel antenna on the Subscriber Station (SS) is directional, so the unit must be aimed
directly towards the Base Station (BSU) signal. Identify a location on a wall or pole (preferably
outdoors) that faces the BSU. The SS is housed within a weatherized, outdoor-grade plastic enclosure;
however, it should be mounted in a location where it will not be subjected to gutter overflow or other
excessive moisture. Likewise, the SS should not be mounted near electric conduit or other source of
electromagnetic interference (EMI), such as a ballast for a fluorescent light fixture.
For best performance, however, orient the unit so that the signal path to the BSU is as free from
obstructions as possible.
