Simplicity 4564 Illustrated Parts List page 9

Tube Group
REF NO PART NO.
1 1933896SM
2 1960096SM
4 1704283SM
5 1960404SM
6 2810542SM
7 1705063SM
8 1707712SM
9 1960252SM
10 1930641SM
Footnotes
The above parts group applies to the following Mfg. Nos.:
1694693 - Catcher
Briggs and Stratton Yard Power Products Group
Copyright © 2007 by Briggs and Stratton Corporation
Milwaukee, WI, USA. All rights reserved
QTY. DESCRIPTION
2 NUT, Hex Nylock, #10-32
6 WASHER
1 ELBOW, Upper
2 SCREW, Truss Head, #10-32 x 1/2
2 RIVET
1 CLIP, Spring
1 TUBE & SPRING ASSEMBLY (Incl. Ref. Nos. 2, 6, & 7)
1 CARRIAGE BOLT, 1/4-20 x 5/8
1 NUT, Hex Flange Lock, 1/4-20
9
TP 400-4564-00-AT-SMA
