Airhogs F/A-18 Hornet Instructions Manual

Tail Wing
Propeller
Main Wing
Fuselage Wheel
F/A-18 Hornet™
Check to make sure contents are complete:
• 1 Air Hogs ® F/A-18 Hornet™ • 1 Controller/Charger
• 1 Nose Wheel • 1 Fuselage Wheel Set
• 2 Extra Propellers • 1 Instruction Sheet
The Air Hogs ® F/A-18 Hornet™ is a revolutionary radio controlled jet that is a true backyard flyer. You can hand toss or
take off from the ground using the landing gear. The F/A-18 Hornet™ uses digital proportional control which provides
hobby like flight performance. Comes ready to fly – no assembly required.
1. Use a Phillips screwdriver to loosen the
battery door.
2. Slide the battery door towards the bottom of the
unit and remove. Install six AA 1.5-V alkaline
batteries (not included). Be careful to align the
positive (+) and negative (-) polarities with
the corresponding markings inside the battery
compartment as shown.
3. Reinstall the battery compartment door and
retighten the hold down screw.
IMPORTANT TIP: TURN YOUR CONTROLLER
ON TO ENSURE THAT THE BATTERIES ARE
INSTALLED PROPERLY. THE RED LED LIGHT
ON THE FRONT OF THE CONTROLLER
SHOULD TURN RED.
After each flight, store the jet in the package to
prevent damage.
ADDING WHEELS TO THE FUSELAGE
1
1. Add nose wheel to slot in
bottom of jet as shown.
NOTE: Wheels may pop off during flight but are easy to re-attach.
Vertical
Fuselage
Nose Wheel
CONTROLLER/CHARGER BATTERY INSTALLATION
2
2. Add fuselage wheels to slot in
bottom of jet as shown.
INSTRUCTIONS
Propeller
Main Wing
ON/OFF/CHARGE
Switch
Throttle
Charge Door
(to access
Charge Nozzle)
Controller/Charger
1
Battery
Compartment
Door
2
Six AA
1.5-V
Alkaline
Batteries
3
Battery
Compartment
Controller/Charger
TM
Antenna
REPAIRS
Charge
LED
Power
LED
Left/Right
Toggle
Steering
Trim Knob
Your
F/A-18 Hornet™
jet has
preinstalled
rechargeable
batteries in the
jet's fuselage.
Because the
Controller's
AA batteries
are used
for 2 functions –
charging and
controlling, they
will need to be
replaced after
every 20 – 25
flights.
If the wings
on your jet get
damaged they
can be easily
repaired with
clear tape as
shown.
Repair
