Summary of Contents for Lush Projects LushOne Echo

  • Page 1 LushOne Echo Synth Module Build Instructions...
  • Page 2: Getting Started

    Getting started • If you can build the LushOne base module then then  building the Echo should be easy • Remember: – Accuracy and neatness is more important than speed • Get it working first time – These instructions will guide you but I assume you are  familiar with basic techniques and equipment • All components except the power‐in are mounted on  the circuit board – no slow, fiddly point to point wiring! 2 LushOne Echo synth module – build instructions...
  • Page 3 Build order Build in any order you like, but I suggest: • Patch sockets • ICs • Resistors, capacitors • Transistor, diodes • Power leads • Internal/External feedback switch • Variable resistors 3 LushOne Echo synth module – build instructions...
  • Page 4 Front The following components are mounted from the front: • Patch sockets • Variable resistors 4 LushOne Echo synth module – build instructions...
  • Page 5 Back The following components are mounted from the back: • Everything not on the front! 5 LushOne Echo synth module – build instructions...
  • Page 6 Patch sockets • 9 small silver patch sockets fit from  front of board • Fit in the large, labelled circles – Not the four mounting holes in the  extreme corners • Solder round rim on back • Suggest you fit first so you can  make them sit nicely flush with the  board 6 LushOne Echo synth module – build instructions...
  • Page 7 Designation Type Comment 14 Pin U201,U202 LM324 16 Pin U301 LM13700 3 Pin transistor‐style case U401 78L05 16 Pin U402 PT2399 • All ICs are mounted from the back • ICs are provided unsocketed – You can add sockets if you like! • Positions and orientations are marked on the silk‐screen – Pin 1 also has a square pad • The voltage regulator has the same case as the transistors – check the  labels! – Orientation is shown on silk‐screen 7 LushOne Echo synth module – build instructions...
  • Page 8 • The round silk‐screen symbol shown in the photo shows  R307, R320 the resistor locations 1.5k R421 R207, R310, R323, R328, R334,  • Resistor colours are on next page 2.2k R411, R418 2.7k R401 4.7k R303, R316, R417, R422 5.6k R209 8.2k R305, R318 R206, R208, R313, R326, R403,  R404, R407, R416 R402, R405, R406, R408 R201, R203, R204 R312, R325 R309, R322 R202, R332, R335, R419 R415 R327, R329, R330, R331, R333,  100k R336, R410, R412, R414 180k R409 R301, R302, R308, R311, R314,  330k R315, R321, R324 R420 8 LushOne Echo synth module – build instructions...
  • Page 9 470R Yellow, Purple, Brown, Gold Brown, Black, Red, Gold 1.5k Brown, Green, Red, Gold Red, Red, Red, Gold 2.2k 2.7k Red, Purple, Red, Gold Yellow, Purple, Red, Gold 4.7k 5.6k Green, Blue, Red, Gold 8.2k Grey, Red, Red, Gold Brown, Black, Orange, Gold Brown, Green, Orange, Gold Red, Red, Orange, Gold Red, Purple, Orange, Gold Orange, Orange, Orange, Gold Yellow, Purple, Orange, Gold Blue, Grey, Orange, Gold 100k Brown, Black, Yellow, Gold Brown, Grey, Yellow, Gold 180k 330k Orange, Orange, Yellow, Gold Brown, Black, Green, Gold 9 LushOne Echo synth module – build instructions...
  • Page 10 Ceramic • For electrolytic capacitors the “+” lead (longer lead) is  labelled and indicated by the square pad. C402, C417 Ceramic Some capacitors may come with either wide or narrow leg  • 4.7n C403, C418 Ceramic spacing. Connect as shown below. C401 Ceramic Connect narrow legs to these pads C204, C205, C306,  C307, C406, C408,  100n Ceramic C409, C412, C415,  C416, C419, C420 C201, C202, C203,  Ceramic C303, C309, C312,  (Multi‐ C314, C315, C404,  Layer) C413 C301, C304, C305,  Connect wide legs to these pads C310, C311, C313,  Electrolytic C407 C405, C411, C421,  Electrolytic C424 10 LushOne Echo synth module – build instructions...
  • Page 11 Capacitor markings Value Marking 100p 560p 4.7n 100n 105 or 1u 11 LushOne Echo synth module – build instructions...
  • Page 12 Transistors, diodes All Transistors and diodes are mounted  • from the back. Transistors are marked showing the  • package orientation. Check you have the  transistors and not the voltage regulator! D201, There are both NPN and PNP transistors – • Q401, 2N3904 D202, Q402 check you have the right one D301, 1N4148 Q403 2N2906 D302, Diodes are all vertically mounted and  • D401 shown with the square symbol. – The diode’s stripe should be towards the  printed square / square pad – Small line coming out of square on silk  screen shows direction of the lead. 12 LushOne Echo synth module – build instructions...
  • Page 13 Power leads • The LushOne Echo can be  connected  to the LushOne base  module for power • Connect three leads to the  LushOne Echo “Power In”  connectors • Suggest: – Red = +9V – Black = 0V – Blue = ‐9V • Connect other end of power leads  to the spare terminals next to the  Power In on the LushOne base • If you have more than two  modules in your system see next  slide 13 LushOne Echo synth module – build instructions...
  • Page 14 Power with more than two LushOne modules • To connect more than  one LushOne module to a  LushOne LushOne base it is  Base desirable to use a “star”  power connection point • A simple terminal block is  an easy choice Distribution • Connect as shown in the  star point diagram ‐9V – Switched output of  LushOne base goes to star  point – Each additional module  eg LushOne eg LushOne connects to the star point  Contour Echo for its power 14 LushOne Echo synth module – build instructions...
  • Page 15 Internal/External switch • Connect the Internet/External  feedback switch to the front of  the board where indicated • The switch can go in either way  round 15 LushOne Echo synth module – build instructions...
  • Page 16: Variable Resistors

    Variable resistors • Eight variable resistors are  mounted where shown on front  of board • You may need to bend the pins  slightly to make them sit  RV301, RV302, RV303, properly RV304, RV305, RV306, RV401, RV402 16 LushOne Echo synth module – build instructions...
  • Page 17 Checking time • Congratulations – building should now  be complete! – Take a break • Time to check: – No parts left‐over – All parts (particularly ICs) in the right way – No bad solder joints or unsoldered joints – Power connectors on correctly (very  important!) – No solder bridges or other problems • Good luck 17 LushOne Echo synth module – build instructions...
  • Page 18 Testing Follow the quick reference guide or the tutorials  to test the functions of the LushOne Echo …now go play 18 LushOne Echo synth module – build instructions...
