Owner's Manual
INSTALLATION GUIDE
TECH SUPPORT
Western Canada 1 800 279-0636
United States: 1 866 698-5872
Eastern Canada. Bilingual Support: 1 800 268-0683
E-Mail Tech Support: support@ultrastarters.com
Check Our Web Site: www.ultrastarters.com
Advanced Remote Vehicle
Starter & Alarm
WWW.ULTRASTARTERS.COM
2500
2500
2500M
Advertisement
Related Manuals for Ultra Start 2500
Summary of Contents for Ultra Start 2500
- Page 1 INSTALLATION GUIDE 2500 2500 2500M Advanced Remote Vehicle Starter & Alarm WWW.ULTRASTARTERS.COM TECH SUPPORT Western Canada 1 800 279-0636 United States: 1 866 698-5872 Eastern Canada. Bilingual Support: 1 800 268-0683 E-Mail Tech Support: support@ultrastarters.com Check Our Web Site: www.ultrastarters.com...
- Page 2 Installation Guide TABLE OF CONTENTS 2500 Wiring Diagram Page 3 Pre-Installation Page 4 Components Recommended Pre-Installation Procedures Recommended Install procedures Wire Connectors Page 5 6 Pin Connector 14 Pin Connector 3 Pin Red Connector 4 Pin Blue Connector Jumper Selections...
-
Page 3: Wiring Diagram
Installation Guide WIRING DIAGRAM (+) 30amp Output Starter Yellow (+) 30amp Output Heater Green (+) 30amp Input Main Power (+) 30amp Input Main Power (+) 30amp Output Selectable P .5 White (+) 30amp Output Ignition 1 Blue (-)500ma Output RE-ARM YELLOW (-)500ma Output STARTER DISABLE... - Page 4 Installation Guide INSTALLATION TIPS Components - Control module - Remote transmitter(s) - Antenna with built in Program Button and LED’s - 6 pin main harness with dual 30amp power inputs - 14 pin harness - 4 pin square harness. - 4 pin keyless entry harness - 4 pin Aux.
- Page 5 Installation Guide WIRING CONNECTORS WIRING CONNECTORS 6 Pin Power Connector Yellow Starter 30amp output 12volts during crank only. Green Heater 30amp output 12volts in accessory. Off during start. 12 power 30amp input Constant 12volt power at ignition harness. 12 power 30amp input Constant 12volt power at ignition harness.
- Page 6 Installation Guide QUICK START INSTALL Step 1 - Connect All Of the Following Wires 6 Pin Power Connector Yellow Starter Output Connect To The Vehicles Starter Wire. Green Heater Output Connect To The Vehicles Accessory Wire. 12 power Input Connect to Constant 12 Volt Power Source- High Current. 12 power Input Connect to Constant 12 Volt Power Source- High Current.
- Page 7 Installation Guide PROGRAMMING Programming Overview Program mode allows you to adjust the settings and options of your system. Your system has been intelligently designed by installers with years of experience. The system’s default settings do not require any program changes in most cases. However, this system does incorporate a highly advanced programming system that includes 4 menus with numerous options and settings that can be easily adjusted for custom installations and applications.
- Page 8 Installation Guide PROGRAMMING PROGRAM MODE - USER SETTINGS Enter User Program Mode - See Page 7 for details on entering program mode Setting 1- Ignition Auto Lock 1 Ignition Lock & Unlock Enabled 1 Light Flash Doors Lock / Unlock when the key is turned On/ Off 2 Ignition Lock Only 2 Light Flashes Doors Lock when ignition key is turned ON only...
- Page 9 Installation Guide PROGRAMMING PROGRAM MODE - ALARM SETTINGS Enter Alarm Program Mode - See Page 7 for details on entering program mode Setting 1 - Car Finder / 5th Channel 1 Car Finder OFF 1 Light Flash Car Finder Mode Disabled *2 Car Finder ON 2 Light Flashes Car Finder Mode Enabled...
- Page 10 Installation Guide PROGRAM MODE - STARTER SETTINGS Enter Starter Program Mode - See Page 7 for details on entering program mode Setting 1- Special Door Lock/ Unlock Operations Chrysler / VW Re-Arm 1 Flash Unlock pulse before start and a lock pulse after start GM Auto Re-Lock 2 Flashes Lock pulse after remote starter shuts off...
- Page 11 Installation Guide Setting 8- Safety Start Mode Safety ON 1 Flash Must press the start button twice to remote start vehicle Safety OFF 2 Flashes Press the start button once to remote start vehicle. Press the Program Switch 8 times to select setting 8 (This will be confirmed by 8 LED flashes) Press and hold the Program Switch until you receive the appropriate # of park light flashes and siren chirps.
- Page 12 Installation Guide OPERATIONS Reservation Mode - Manual Trans. Manual Transmission Remote Starters must have both the door trigger and park brake wires connected. Most installs will require a clutch bypass. This is a temporary bypass. The clutch should only be bypassed during the activation of the remote starter.
- Page 13 Installation Guide OTHER FEATURES System Service Mode ACTIVATING SERVICE MODE 1. While the ignition is “ON” press and hold the Program Button for five seconds. The park lights will flash and the siren will chirp five times to confirm that the system is in Service Mode.
- Page 14 Installation Guide OPERATIONS Lock Doors & Arm The Alar m 1. Press & release the LOCK button on the remote transmitter. 2. The park lights will flash and the siren will chirp once. 3. The doors will lock. 4. The LED will start flashing within five seconds. Unlock Doors &...
- Page 15 Installation Guide OPERATIONS Remote Start 1. Press & release the button. 2. The Park lights will flash and the siren will chirp once. 3. When the vehicle has started, the system will flash the park lights four times and then remain “On” while the vehicle is running. 4.
- Page 16 Installation Guide RELAY DIAGRAMS Negative Door Locks Vehicle Lock To Control Lock/Unlock Relay or Switch Actuators lock Green Blue Positive Type Door Locks Vehicle Lock Lock/Unlock Fused +12V lock Switch Green Blue To Control Relay or Actuator 5 Wire / Reverse Polarity Type Door Locks Fused +12V Green Blue...
