PRODUCT FEATURES

Highlights

High performance and full featured 2 port switch with

VLAN, QoS packet prioritization, Rate Limiting, IGMP

Snooping and management functions

Easily interfaces to most 16-bit embedded CPU's

Unique Virtual PHY feature simplifies software

development by mimicking the multiple switch ports

as a single port MAC/PHY

Integrated IEEE 1588 Hardware Time Stamp Unit

Target Applications

Cable, satellite, and IP set-top boxes

Digital televisions

Digital video recorders

VoIP/Video phone systems

Home gateways

Test/Measurement equipment

Industrial automation systems

Key Benefits

Ethernet Switch Fabric

— 32K buffer RAM

— 1K entry forwarding table

— Port based IEEE 802.1Q VLAN support (16 groups)

– Programmable IEEE 802.1Q tag insertion/removal

— IEEE 802.1d spanning tree protocol support

— QoS/CoS Packet prioritization

– 4 dynamic QoS queues per port

– Input priority determined by VLAN tag, DA lookup,

TOS, DIFFSERV or port default value

– Programmable class of service map based on input

priority

– Remapping of 802.1Q priority field on per port basis

– Programmable rate limiting at the ingress/egress

ports with random early discard, per port / priority

— IGMP v1/v2/v3 snooping for Multicast packet filtering

— IPV6 Multicast Listener Discovery snoop

— Programmable filter by MAC address

Switch Management

— Port mirroring/monitoring/sniffing: ingress and/or egress

traffic on any ports or port pairs

— Fully compliant statistics (MIB) gathering counters

— Control registers configurable on-the-fly

SMSC LAN9311/LAN9311i

LAN9311/LAN9311i

Two Port 10/100 Managed

Ethernet Switch with 16-Bit

Non-PCI CPU Interface

Ports

— 2 internal 10/100 PHYs with HP Auto-MDIX support

— Fully compliant with IEEE 802.3 standards

— 10BASE-T and 100BASE-TX support

— Full and half duplex support

— Full duplex flow control

— Backpressure (forced collision) half duplex flow control

— Automatic flow control based on programmable levels

— Automatic 32-bit CRC generation and checking

— Automatic payload padding

— 2K Jumbo packet support

— Programmable interframe gap, flow control pause value

— Full transmit/receive statistics

— Auto-negotiation

— Automatic MDI/MDI-X

— Loop-back mode

High-performance host bus interface

— Provides in-band network communication path

— Access to management registers

— Simple, SRAM-like interface

— 16-bit data bus

— Big, little, and mixed endian support

— Large TX and RX FIFO's for high latency applications

— Programmable water marks and threshold levels

— Host interrupt support

IEEE 1588 Hardware Time Stamp Unit

— Global 64-bit tunable clock

— Master or slave mode per port

— Time stamp on TX or RX of Sync and Delay_req

packets per port, Timestamp on GPIO

— 64-bit timer comparator event generation (GPIO or IRQ)

Comprehensive Power Management Features

— Wake on LAN

— Wake on link status change (energy detect)

— Magic packet wakeup

— Wakeup indicator event signal

Other Features

— General Purpose Timer

— Serial EEPROM interface (I

master) for non-managed configuration

— Programmable GPIOs/LEDs

Single 3.3V power supply

Available in Commercial & Industrial Temp. Ranges

DATASHEET

Datasheet

C master or Microwire

Revision 1.4 (08-19-08)
