SMSC USB2242 Datasheet

Ultra fast usb 2.0 memory stick flash media controller

Advertisement

Quick Links

PRODUCT FEATURES

General Description
The SMSC USB2242/USB2242i is a USB 2.0 compliant,
high speed Bulk Only Mass Storage Class Peripheral
Controller intended for reading and writing to
Flash Media Cards.
The SMSC USB2242/USB2242i is a fully integrated, single
chip solution capable of ultra high performance operation.
Average sustained transfer rates exceeding 35MB/s are
possible if the media and host can support those rates.
Provisions to read/write secure media formats is also
provided.
General Features
36-pin QFN (6x6mm) lead-free RoHS compliant package
Hardware-controlled data flow architecture for all self-
mapped media
Pipelined hardware support for access to non-self-
mapped media
Product name with "i" denotes the version that supports
the industrial temperature range of -40ºC to 85ºC
Support included for secure media format on a licensed,
customized basis
TM
— Sony MagicGate
Hardware Features
Single Chip Flash Media Reader/Writer
— Memory Stick Specification 1.43
— Memory Stick Pro Format Specification 1.02
— Memory Stick Pro-HG Duo Format Specification 1.01
Memory Stick, MS Duo, HS-MS, MS Pro-HG, MS Pro
Extended configuration options
— Socket switch polarities, etc.
Media Activity LED
GPIO configuration and polarity
— Up to 8 GPIOs for special function use: LED indicators,
power control to memory devices, etc. The number of
actual GPIO's depends on the implementation
configuration used.
— One GPIO with up to 200 mA drive
On Board 24MHz Crystal Driver Circuit
Internal Card Power FET
— 200mA
— "Fold-back" short circuit current protected
8051 8-bit microprocessor
— 60MHz - single cycle execution
— 64KB ROM; 14KB RAM
Internal Regulator for 1.8V core operation
Optimized pinout improves signal routing, easing
implementation and allowing for improved signal integrity
SMSC USB2242/USB2242i
USB2242/USB2242
Ultra Fast USB 2.0 Memory
Stick Flash Media Controller
Mask Programmable Features
VID/PID/Language ID
28-character Manufacturer ID and Product string
12-hex digit (max) Serial Number string
Memory Stick
Customizable Vendor specific data LED blink interval or
duration
Software Features
Optimized for low latency interrupt handling
Reduced memory footprint
Please see the USB2242/USB2242i Software Release
Notes for additional Software Features.
Applications
Flash Media Card Reader/Writer
Printers
Desktop and Mobile PCs
Consumer A/V
Media Players/Viewers
Vista ReadyBoost
Compatible with Microsoft Vista, Windows XP, Windows
ME, Windows 2K SP4, Apple OSx, and Linux Mass
Storage Class Drivers
DATASHEET
I
TM
Revision 1.0 (05-27-08)
Datasheet

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the USB2242 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SMSC USB2242

  • Page 1: Product Features

    PRODUCT FEATURES General Description The SMSC USB2242/USB2242i is a USB 2.0 compliant, high speed Bulk Only Mass Storage Class Peripheral Controller intended for reading and writing to Flash Media Cards. The SMSC USB2242/USB2242i is a fully integrated, single chip solution capable of ultra high performance operation.
  • Page 2: Order Number

    Any and all such uses without prior written approval of an Officer of SMSC and further testing and/or modification will be fully at the risk of the customer.
  • Page 3: Table Of Contents

    Chapter 10 GPIO Usage ............23 SMSC USB2242/USB2242i DATASHEET Revision 1.0 (05-27-08)
  • Page 4: List Of Figures

    Figure 8.2 Formula to Find Value of C1 and C2 ......... . . 21 Figure 9.1 USB2242/USB2242i 36-QFN, 6x6mm Body, 0.5mm Pitch ......22 Revision 1.0 (05-27-08)
  • Page 5 Table 10.1 USB2242/USB2242i GPIO Usage (ROM Rev 0x00)....... . 23...
  • Page 6: Chapter 1 Acronyms

    SMSC all necessary licenses under Solid State Disk Patents; that the manufacture and testing by or for SMSC of the units of any of the devices made the subject of this document which may be sold to the customer, and any sale by SMSC of such units to the customer, are valid exercises of the customer's rights and licenses under such Solid State Disk Patents;...
  • Page 7: Chapter 2 Block Diagram

    Ultra Fast USB 2.0 Memory Stick Flash Media Controller Datasheet Chapter 2 Block Diagram Host INTFC 10KB ADDR 64KB Clock Generation and Control Figure 2.1 USB2242/USB2242i Block Diagram SMSC USB2242/USB2242i AUTO_ PROC FMDU INTFC EP0 TX EP0 RX INTFC EP1 RX EP1 TX...
  • Page 8: Chapter 3 Pin Table

    Chapter 3 Pin Table 36-Pin Package Table 3.1 USB2242/2242i 36-Pin QFN Package MS_D0 MS_D4 MS_BS USB+ XTAL1 (CLKIN) GPIO1 (LED1) GPIO2 / RXD / SDA GPIO10 (CRD_PWR) TEST (3) VDD33 Revision 1.0 (05-27-08) Ultra Fast USB 2.0 Memory Stick Flash Media Controller...
  • Page 9: Chapter 4 Pin Configuration

    MS _SCLK GPIO7 / TXD / SCK / MS_SKT_SEL XTAL2 XTAL1 (CLKIN) VDD18PLL RBIAS VDDA33 Figure 4.1 USB2242/USB2242i 36 Pin QFN Diagram SMSC USB2242/USB2242i SMSC USB2242/2242i (Top View QFN-36) Thermal Slug (must be connected to VSS) Indicates pins on the bottom of the device.
  • Page 10: Chapter 5 Pin Descriptions

    The term negate, or negation, indicates that a signal is inactive. Pin Descriptions Table 5.2 USB2242/2242i 36-Pin QFN Pin Descriptions NAME SYMBOL MS System Data...
  • Page 11 Ultra Fast USB 2.0 Memory Stick Flash Media Controller Datasheet Table 5.2 USB2242/2242i 36-Pin QFN Pin Descriptions (continued) NAME SYMBOL USB Transceiver RBIAS Bias 24MHz Crystal or XTAL1 (CLKIN) external clock input 24MHz Crystal XTAL2 3.3V Analog VDDA33 Power 1.8V PLL Power...
  • Page 12: Digital / Power

    Table 5.2 USB2242/2242i 36-Pin QFN Pin Descriptions (continued) NAME SYMBOL General Purpose GPIO7 / TXD / SCK / MS_SKT_SEL General Purpose GPIO10 (CRD_PWR) General Purpose GPIO14 General Purpose GPIO15 RESET Input nRESET TEST Input TEST No Connects +1.8V Core power VDD18 3.3V Power &...
  • Page 13: Buffer Type Descriptions

    Ultra Fast USB 2.0 Memory Stick Flash Media Controller Datasheet Buffer Type Descriptions Table 5.3 USB2242/USB2242i Buffer Type Descriptions BUFFER Input. Input with internal weak pull-up resistor. Input with Schmitt trigger. I/O12 Input/Output buffer with 12mA sink and 12mA source.
  • Page 14: Chapter 6 Pin Reset State Table

    Figure 6.2 Legend for Pin Reset States Table Revision 1.0 (05-27-08) Ultra Fast USB 2.0 Memory Stick Flash Media Controller Hardware Initialization RESET Figure 6.1 Pin Reset States DATASHEET Datasheet Firmware Operational RESET Time SMSC USB2242/USB2242i...
  • Page 15: 36-Pin Reset States

    Ultra Fast USB 2.0 Memory Stick Flash Media Controller Datasheet 36-Pin Reset States Table 6.1 USB2242/USB2242i Pin Reset States PIN NAME MS_D7 MS_D6 MS_D4 MS_D5 MS_SCLK MS_D3 MS_D2 MS_BS MS_D1 MS_D0 GPIO14 GPIO15 GPIO12 (MS_INS) GPIO2 / RXD / SDA...
  • Page 16: Chapter 7 Dc Parameters

    3.63V indefinitely, without damage to the device as long as V and V DD33 DDA33 are less than 3.63V and T less than 70 SMSC USB2242/USB2242i...
  • Page 17: Recommended Operating Conditions

    Voltage on XTAL2 Note 7.3 A 3.3V regulator with an output tolerance of 1% must be used if the output of the internal power FET’s must support a 5% tolerance. SMSC USB2242/USB2242i Figure 7.1 Supply Rise Time Model UNITS °C °C...
  • Page 18: Dc Electrical Characteristics

    Datasheet UNITS COMMENTS TTL Levels μA μA TTL Levels μA = 0 to V DD33 μA μA DD33 = 12mA @ = 3.3V DD33 = -12mA @ = 3.3V DD33 μA = 0 to V DD33 (Note 7.4) SMSC USB2242/USB2242i...
  • Page 19 Output current range is controlled by program software, software disables FET during short circuit condition. Note 7.8 The assignment of each Integrated Card Power FET to a designated Card Connector is controlled by both firmware and the specific board implementation. Firmware will default to SMSC USB2242/USB2242i SYMBOL DD33 - 0.4 DSON...
  • Page 20: Capacitance

    PARAMETER SYMBOL Clock Input Capacitance Input Capacitance Output Capacitance Revision 1.0 (05-27-08) Ultra Fast USB 2.0 Memory Stick Flash Media Controller Table 10.1, “USB2242/USB2242i GPIO Usage (ROM Rev 0x00),” on = 1.8V Table 7.1 Pin Capacitance LIMITS XTAL DATASHEET Datasheet...
  • Page 21: Chapter 8 Ac Specifications

    External Clock: 50% Duty cycle ± 10%, 24 MHz ± 100ppm, Jitter < 100ps rms. Crystal Note: C equals total board/trace capacitance. Figure 8.2 Formula to Find Value of C SMSC USB2242/USB2242i 1Meg Figure 8.1 Typical Crystal Circuit ) x (C DATASHEET...
  • Page 22: Chapter 9 Package Outline

    Chapter 9 Package Outline Figure 9.1 USB2242/USB2242i 36-QFN, 6x6mm Body, 0.5mm Pitch...
  • Page 23: Chapter 10 Gpio Usage

    Ultra Fast USB 2.0 Memory Stick Flash Media Controller Datasheet Chapter 10 GPIO Usage Table 10.1 USB2242/USB2242i GPIO Usage (ROM Rev 0x00) NAME ACTIVE LEVEL GPIO1 GPIO2 GPIO4 USER GPIO7 GPIO10 GPIO12 GPIO14 USER GPIO15 USER SMSC USB2242/USB2242i SYMBOL LED1...
