PRODUCT FEATURES

General Description
T h e S M S C 2 - P o r t H u b i s a l o w p o w e r, O E M
configurable, STT (Single transaction translator) hub
controller IC with 2 downstream ports for embedded
USB solutions. The 2-port hub is fully compliant with the
USB 2.0 Specification and will attach to an upstream
port as a Full-Speed Hub or as a Full-/Hi-Speed Hub.
The 2-Port Hub supports Low-Speed, Full- Speed, and
Hi-Speed (if operating as a Hi-Speed Hub) downstream
devices on all of the enabled downstream ports.
General Features
Hub Controller IC with 2 downstream ports
Enhanced OEM configuration options available
through either a single serial I
SMBus Slave Port
36-pin (6x6mm) QFN lead-free, RoHS compliant
package
Hardware Features
Low power operation
Full Power Management with individual or ganged
power control of each downstream port
On-chip Power On Reset (POR)
Internal 1.8V Voltage Regulator
Fully integrated USB termination and Pull-up/Pull-
down resistors
On Board 24MHz Crystal Driver, Resonator or
External 24MHz clock input
Enhanced EMI rejection and ESD protection
performance
OEM Selectable Features
Customizable Vendor ID, Product ID, and Device ID
Select whether the hub is part of a compound device
(When any downstream port is permanently
hardwired to a USB peripheral device, the hub is part
of a compound device)
Flexible port mapping and disable sequence. Ports
can be disabled/reordered in any order to support
multiple product SKUs. Hub will automatically reorder
the remaining ports to match the Host controller's
numbering scheme.
Programmable USB differential-pair pin location.
Ease PCB layout by aligning USB signal lines directly
to connectors
Programmable USB signal drive strength. Recover
USB signal integrity due to compromised system
environment using 2-level driving strength resolution
SMSC USB2512A
2
C EEPROM, or
DATASHEET
USB2512A
USB 2.0 Hi-Speed 2-Port
Hub Controller
Select the presence of a permanently hardwired USB
peripheral device on a port by port basis
Configure the delay time for filtering the over-current
sense inputs
Configure the delay time for turning on downstream
port power
Indicate the maximum current that the 2-port hub
consumes from the USB upstream port
Indicate the maximum current required for the hub
controller
Pin Selectable Options for Default Configuration
— Select Downstream Ports as Non-Removable Ports
Applications
LCD monitors and TVs
Multi-function USB peripherals
PC mother boards
Set-top boxes, DVD players, DVR/PVR
Printers and scanners
PC media drive bay
Portable hub boxes
Mobile PC docking
Embedded systems
Datasheet
Revision 1.96 (07-11-08)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the USB2512A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SMSC USB2512A

  • Page 1: Product Features

    Ease PCB layout by aligning USB signal lines directly to connectors Programmable USB signal drive strength. Recover USB signal integrity due to compromised system environment using 2-level driving strength resolution SMSC USB2512A USB2512A USB 2.0 Hi-Speed 2-Port Hub Controller Select the presence of a permanently hardwired USB...
  • Page 2: Order Numbers

    Any and all such uses without prior written approval of an Officer of SMSC and further testing and/or modification will be fully at the risk of the customer. Copies of this document or other SMSC literature, as well as the Terms of Sale Agreement, may be obtained by visiting SMSC’s website at http://www.smsc.com.
  • Page 3: Table Of Contents

    Chapter 7 Package Outline ........... 37 SMSC USB2512A DATASHEET Revision 1.96 (07-11-08)
  • Page 4 Figure 1.1 USB2512A 36-Pin QFN (Embedded Footprint) ........
  • Page 5 Table 3.3 USB2512A Power, Ground, and No Connect ....... . .
  • Page 6: Chapter 1 Pin Configuration

    VDDA33 USBUP_DM USBUP_DP XTAL2 XTAL1/CLKIN VDD18PLL RBIAS VDD33PLL Figure 1.1 USB2512A 36-Pin QFN (Embedded Footprint) Revision 1.96 (07-11-08) SMSC USB2512A Embedded Footprint (Top View QFN-36) Thermal Slug (must be connected to VSS) Indicates pins on the bottom of the device.
  • Page 7: Chapter 2 Block Diagram

    O C S e nse S w itch /LE D D ow n strea m D rive rs Figure 2.1 USB2512A Block Diagram DATASHEET T o E E P R O M o r S M B u s M a ste r S C K 1 .8 V...
  • Page 8: Chapter 3 Pin Descriptions

    Host port or upstream Hub. I/O12 Detect Upstream VBUS Power Detects state of Upstream VBUS power. The SMSC Hub monitors VBUS_DET to determine when to assert the internal D+ pull-up resistor which signals a connect event. When designing a detachable hub, this pin must be connected to the VBUS power pin of the USB port that is upstream of the Hub.
  • Page 9 USB 2.0 Hi-Speed 2-Port Hub Controller Datasheet Table 3.1 USB2512A Pin Descriptions (continued) QFN-36 SYMBOL RBIAS SDA/ SMBDATA/ NON_REM1 SCL/ SMBCLK/ CFG_SEL0 HS_IND/ CFG_SEL1 XTAL1/ CLKIN SMSC USB2512A BUFFER TYPE USB Transceiver Bias Ω A 12.0k (+/- 1%) resistor is attached from ground to this pin to set the transceiver’s internal bias settings.
  • Page 10 LED is active low TEST pin XNOR continuity tests all signal pins on the hub. Please contact your SMSC representative for a detailed description of how this test mode is enabled and utilized. DATASHEET USB 2.0 Hi-Speed 2-Port Hub Controller...
  • Page 11: Table 3.2 Smbus Or Eeprom Interface Behavior

    USB 2.0 Hi-Speed 2-Port Hub Controller Datasheet Table 3.2 SMBus or EEPROM Interface Behavior CFG_SEL1 CFG_SEL0 Table 3.3 USB2512A Power, Ground, and No Connect PACKAGE SYMBOL 36-QFN EMB VDD18 VDD33PLL VDDPLL18 VDDA33 VDD33/VDD33CR SMSC USB2512A SMBUS OR EEPROM INTERFACE BEHAVIOR...
  • Page 12: Buffer Type Descriptions

    Buffer Type Descriptions Table 3.4 USB2512A Buffer Type Descriptions BUFFER Input. Input with internal weak pull-down resistor. Input with internal weak pull-up resistor. Input with Schmitt trigger. Output 12mA. OD12 Open drain with 12mA sink. I/O12 Input/Output buffer with 12mA sink and 12mA source.
  • Page 13: Chapter 4 Configuration Options

    4.1.1 Hub Configuration Options The SMSC Hub supports a large number of features (some are mutually exclusive), and must be configured in order to correctly function when attached to a USB host controller. There are three principal ways to configure the hub: SMBus, EEPROM, or by internal default settings (with or without pin strapping option over-rides).
  • Page 14 USB 2.0 Hi-Speed 2-Port Hub Controller Datasheet SMBUS AND INTERNAL EEPROM OR DEFAULT ROM VALUES 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 SMSC USB2512A...
  • Page 15 Register 05h: Device ID (MSB) NUMBER BIT NAME DID_MSB SMSC USB2512A DESCRIPTION Most Significant Byte of the Vendor ID. This is a 16-bit value that uniquely identifies the Vendor of the user device (assigned by USB-Interface Forum). This field is set by the OEM using either the SMBus or EEPROM interface options.
  • Page 16 Bus-Powered (limited to a 100mA maximum of upstream power prior to being configured by the host controller). When configured as a Bus-Powered device, the SMSC Hub consumes less than 100mA of current prior to being configured. After configuration, the Bus-...
  • Page 17 (and from Bus-Powered to Self- Powered if the local power source is restored). {Note: If the local power source is available, the Hub will always switch to Self-Powered operation.} When Dynamic Power switching is enabled, the Hub detects the availability of a local power source by monitoring the external LOCAL_PWR pin.
  • Page 18 Bit 4= Reserved, always = ‘0’ Bit 3= Reserved, always = ‘1’ Bit 2= 1; Port 2 non-removable Bit 1= 1; Port 1 non removable Bit 0= Reserved, always = ‘0’ DATASHEET USB 2.0 Hi-Speed 2-Port Hub Controller Datasheet SMSC USB2512A...
  • Page 19 4.2.1.12 Register 0Bh: Port Disable For Bus Powered Operation NUMBER BIT NAME PORT_DIS_BP SMSC USB2512A DESCRIPTION Port Disable Self-Powered: Disables 1 or more contiguous ports. ‘0’ = port is available, ‘1’ = port is disabled. when remapping mode is disabled...
  • Page 20 Note: The USB 2.0 Specification does not permit this value to exceed 100mA A value of 50 (decimal) indicates 100mA, which is the default value. DATASHEET USB 2.0 Hi-Speed 2-Port Hub Controller Datasheet SMSC USB2512A...
  • Page 21 Register F8h: Boost_2:0 NUMBER BIT NAME Reserved SMSC USB2512A DESCRIPTION Hub Controller Max Current Bus-Powered: Value in 2mA increments that the Hub consumes from an upstream port (VBUS) when operating as a bus- powered hub. This value will include the hub silicon along with the combined power consumption (from VBUS) of all associated circuitry on the board.
  • Page 22 Bit 5= Reserved Bit 4= Reserved Bit 3= Reserved Bit 2= ‘1’; Port 2 DP/DM is Swapped. Bit 1= ‘1’: Port 1 DP/DM is Swapped. Bit 0= ‘1’:Upstream Port DP/DM is Swapped DATASHEET USB 2.0 Hi-Speed 2-Port Hub Controller Datasheet SMSC USB2512A...
  • Page 23: Table 4.2 Port Remap Register For Ports 1 & 2

    Register FBh: Port Remap 12 NUMBER BIT NAME PRTR12 SMSC USB2512A DESCRIPTION Port remap register for ports 1 & 2. When a hub is enumerated by a USB Host Controller, the hub is only permitted to report how many ports it has; the hub is not permitted to select a numerical range or assignment.
  • Page 24: I C Eeprom

    C Master Specification (Please refer to the C-Bus Specification for details on I C Specification are not supported. DATASHEET USB 2.0 Hi-Speed 2-Port Hub Controller Datasheet C bus protocols). The Hub’s I C EEPROM, and it conforms to the SMSC USB2512A...
  • Page 25: In-Circuit Eeprom Programming

    SMBus interface, external EEPROM support is no longer available (and the user-defined descriptor data must be downloaded via the SMBus). Due to system issues, the SMSC Hub waits indefinitely for the SMBus code load to complete and only “appears” as a newly connected device on USB after the code load is complete.
  • Page 26: Invalid Protocol Response Behavior

    Data byte 2 Block Read Figure 4.2 Block Read Section 4.3.3 for the response to undefined registers. TIMEOUT, MAX DATASHEET USB 2.0 Hi-Speed 2-Port Hub Controller Datasheet Data byte N Slave Address Data byte N ). Devices that TIMEOUT, MIN SMSC USB2512A...
  • Page 27: Stretching The Sclk Signal

    Please refer to Table 4.1 Default Strapping Options: The USB2512A can be configured via a combination of internal default values and pin strap options. Please see Table 3.1 configuration option. The strapping option pins only cover a limited sub-set of the configuration options. The internal default values will be used for the bits &...
  • Page 28: External Hardware Reset_N

    USB Reset inactive recovery Upstream levels Driven by Hub if strap is an output. Don’t Care 16.7 16.7 DATASHEET USB 2.0 Hi-Speed 2-Port Hub Controller Datasheet Start completion Idle request response UNITS μsec nsec 1400 nsec μsec msec msec SMSC USB2512A...
  • Page 29: Figure 4.4 Reset_N Timing For Eeprom Mode

    When in Bus-Powered mode, the Hub and its associated circuitry must not consume more than 100mA from the upstream USB power source during t4+t5+t6+t7. All Power Supplies must have reached the operating levels mandated in Parameters, prior to (or coincident with) the assertion of RESET_N. SMSC USB2512A Attach USB Reset recovery...
  • Page 30: Usb Bus Reset

    Revision 1.96 (07-11-08) Attach SMBus Code Hub PHY USB Reset Load Stabilization Upstream DATASHEET USB 2.0 Hi-Speed 2-Port Hub Controller Datasheet Start completion Idle recovery request response UNITS μsec μsec msec msec msec Undefined msec msec Chapter 5, DC SMSC USB2512A...
  • Page 31 6. Complies with Section 11.10 of the USB 2.0 Specification for behavior after completion of the reset sequence. The Host then configures the Hub and the Hub’s downstream port devices in accordance with the USB Specification. SMSC USB2512A DATASHEET Revision 1.96 (07-11-08)
  • Page 32: Chapter 5 Dc Parameters

    Voltage VDD33 Revision 1.96 (07-11-08) Figure 5.1 Supply Rise Time Model DATASHEET USB 2.0 Hi-Speed 2-Port Hub Controller Datasheet UNITS COMMENTS °C °C Soldering < 10 seconds 3.3V 100% Time SMSC USB2512A...
  • Page 33: Operating Conditions

    High Input Level Low Input Leakage High Input Leakage Input Buffer with Pull- Down (IPD) Low Input Level High Input Level Low Input Leakage High Input Leakage SMSC USB2512A UNITS °C 1.62 1.98 μs -0.3 -0.3 DDA33 Table 5.1 DC Electrical Characteristics...
  • Page 34 = 0 to V DD33 = 12mA @ V = 3.3V DD33 = -12mA @ V = 3.3V DD33 = 0 to V DD33 (Note 1) All supplies combined All supplies combined μA All supplies combined μA All supplies combined SMSC USB2512A...
  • Page 35: Table 5.2 Pin Capacitance

    = 25°C; fc = 1MHz; V PARAMETER SYMBOL Clock Input XTAL Capacitance Input Capacitance Output Capacitance SMSC USB2512A = 1.8V DD18 DDPLL Table 5.2 Pin Capacitance LIMITS UNIT All pins except USB pins (and pins under test tied to AC ground)
  • Page 36: Chapter 6 Ac Specifications

    Figure 6.2 Formula to find value of C 6.1.1 SMBus Interface: The SMSC Hub conforms to all voltage, power, and timing characteristics and specifications as set forth in the SMBus 1.0 Specification for Slave-Only devices (except as noted in 6.1.2 C EEPROM: Clock frequency is fixed at 60KHz ±...
  • Page 37: Chapter 7 Package Outline

    Chapter 7 Package Outline Figure 7.1 36-Pin QFN, 6x6mm Body, 0.5mm Pitch...
