Summary of Contents for Anycom EDR-AP
- Page 1 1 1 1 1...
-
Page 2: Table Of Contents
■ ■ ■ ■ Table of Contents Table of Contents Table of Contents Table of Contents 1. EDR-AP KEY FEATURES 2. PART CHECKLIST 3. PRODUCT DESCRIPTION 4. SPECIFICATION 5. CONTROLS AND FUNCTIONS [BUTTON/LED/REAR PANEL] 6. EDR-AP INSTALLATION 7. CAUTION 8. ETHERNET NETWORK CONNECTION... -
Page 3: Edr-Ap Key Features
AP Key Features EDR-AP supports Bluetooth PAN / DUN / OPP Gateway. EDR-AP provides a built-in web server for convenient configuration. EDR-AP support private leased lines, ADSL/VDSL modems using PPPoE and cable modems (DHCP). ■ ■ ■ ■ Part Checklist Part Checklist... - Page 4 ■ ■ ■ ■ Product Description Product Description Product Description Product Description Please check and make sure that you have all the following package contents. 4 4 4 4...
-
Page 5: Specification
■ ■ ■ ■ Specification Specification Specification Specification Name Name Name Name Description Description Description Description Output Power 15 ~ 20 dBm Rx Sensitivity 85 dBm Channel 79 CH Antenna 2.4GHz Band 1/2λSleeve Dipole Antenna Frequency 2402 ~ 2480 MHz Modulation FSK, QPSK Adaptor... -
Page 6: Controls And Functions [Button/Led/Rear Panel]
▌ ▌ ▌ ▌ Button Button Button Button Name Name Name Name Description Description Description Description If you press any two buttons on the unit, the LED (Green) blinks and EDR-AP goes to Button discoverable and pairable mode. 6 6 6 6... - Page 7 Power is OFF or Bluetooth is abnormal state mode TCP/IP communication is able mode Green BLINK TCP/IP communication is disable mode No connection with the Ethernet * When EDR-AP restarts, every LED blinks several times 7 7 7 7...
- Page 8 Description Description Description Description Press this button for more than three seconds to restore the original factory default setting of EDR-AP RESET (Reboot: press between 1~3 seconds) Connect the Power Adaptor 5V1A Connect to private leased line, ADSL/VDSL modem, cable model using LAN cable (UTP...
-
Page 9: Edr-Ap Installation
■ ■ ■ ■ EDR EDR- - - - AP Installation AP Installation AP Installation AP Installation Please check the port location of the rear panel and then follow the steps below to install the BS-P100 properly. ▌ ▌ ▌ ▌ Ethernet Network Connection Ethernet Network Connection Ethernet Network Connection Ethernet Network Connection... - Page 10 ① Pull out the cable from the Ethernet (LAN) port of modem and connect it to the WAN port at the EDR-AP’s rear panel. ② Connect the power adaptor to the “POWER” port at the EDR-AP rear panel. ③ Connect antenna provided to antenna connecting jack at the side of body. When you connect antenna, twist it on...
- Page 11 Use only the power adaptor supplied. Using other power adaptors may cause the voice quality to deteriorate and malfunction. Install EDR-AP far from wireless LAN/microwave about 1m. If installed close may cause jamming. Use only the antenna provided. The data of this device could be lost When the static electricity occurs in antenna portion...
- Page 12 IP address s IP address s IP address In case of you don’t know the IP address, you can check the current EDR-AP IP address by configuring IP address of user’s PC. ① Click [Start] from the bottom menu bar, then choose [Settings].
- Page 13 You can configure the Radius authentication method and information SNMP You can configure the information for the interoperate with SNMP server System Mgmt You can configure the ID, Password of the EDR-AP Factory Reset System reset by factory value System Restart...
- Page 15 Now select and set the appropriate IP configuration parameters that match your network environment from below. (a) Static IP i. Select [Static IP]. ii. Enter the IP, gateway, network mask and DNS address for EDR-AP. (b) DHCP(Dynamic IP) or Cable modem i. Select [DHCP].
- Page 16 Level 1 : Security Code(Pin Code) Is not requested. Level 3 Level 3 : Security Code(Pin Code) Is requested. Device Configuration Type the Pin Code of EDR-AP. 000000 Select the electric wave of EDR-AP. Class 1 is the strongest Radio Power Class Class 1 electric wave.
- Page 17 ▌ ▌ ▌ ▌ RADIUS RADIUS RADIUS RADIUS ① Select [Configuration], and then choose [RADIUS] to enter the network configuration page. Default Default Default Default Title Title Description Description Title Title Description Description value value value value Define the number of re-transmission times in case of data Retransmission failures when interoperate with Radius server.
- Page 18 ▌ ▌ ▌ ▌ SNMP SNMP SNMP SNMP ① Select [Configuration], and then choose [SNMP] to enter the network configuration page. Default Default Default Default Title Title Description Description Title Title Description Description V V V V alue alue alue alue SNMP activation Activate the SNMP function.
- Page 19 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
- Page 20 ▌ ▌ ▌ ▌ ATTENTION(FCC): ATTENTION(FCC): ATTENTION(FCC): ATTENTION(FCC): This appliance and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. A minimum separation distance of 20 cm must be maintained between the antenna and the person for this appliance to satisfy the RF exposure requirements.
