  • Page 1 Betriebsanleitung Operating instructions Notice d'utilisation Lese-/Schreibkopf für RF-Identifikationssysteme Read/write head for RF identification systems Tête de lecture/écriture pour identification par radiofréquence (RFID) DTA100...
  • Page 2: Table Of Contents

    DTA100 IDENTIFIKATIONSSYSTEM Diese Betriebsanleitung ... gilt für alle Geräte des Typs DTA100..richtet sich an fachkundige Personen im Sinne von EMV- und der Niederspan- nungs-Richtlinie..ist Bestandteil des Gerätes. Sie enthält Angaben zum korrekten Umgang mit dem Produkt. Lesen Sie sie vor dem Einsatz, damit Sie mit Einsatzbedingungen, In- stallation und Betrieb vertraut werden.
  • Page 3: Sicherheitsweise

    DTA100 IDENTIFIKATIONSSYSTEM 1. Sicherheitshinweise Allgemeines Befolgen Sie die Angaben der Betriebsanleitung. Nichtbeachten der Hin- weise, Verwendung außerhalb der nachstehend genannten bestim- mungsgemäßen Verwendung, falsche Installation oder Handhabung können Beein- trächtigungen der Sicherheit von Menschen und Anlagen zur Folge haben. Der Einbau und Anschluss muss den gültigen nationalen und internationalen Nor- men entsprechen.
  • Page 4: Bestimmungsgemäße Verwendung

    DTA100 IDENTIFIKATIONSSYSTEM 2. Bestimmungsgemäße Verwendung • Der Lese-/Schreibkopf DTA100 liest berührungslos Daten von systemkonformen RFID-Transpondern (ID-TAGs), • wandelt sie in digital codierte Werte • und stellt diese der AS-i Steuerungsebene zur Verfügung (AS-i Master, Controller oder Host). Einsatzbereiche sind z.B.: •...
  • Page 5: Anzeigeelemente

    Die Befestigung erfolgt wahlweise mit 2 Stk. M 4 Schrauben und Muttern oder mittels Klemmhalterung. Informationen zum erhältlichen Montagezubehör finden Sie im Internet unter: Datenblatt-Suche DTA100 Zubehör www.ifm-electronic.com Beispiel Beispiel Art.-Nr. E20898 Art.-Nr. E20901 Montagebeispiele Bei der Montage von mehreren Lese-/Schreibköpfen die Mindestabstände zwischen den Systemen beachten siehe 12.
  • Page 6: Elektrischer Anschluss

    Eine Auswahl an Kabeldosen finden Sie im Internet unter: Datenblatt-Suche DTA100 Zubehör www.ifm-electronic.com ASI+ Adernfarben bei ifm-Kabeldosen: 1 = BN (braun) 3 = BU (blau) Anschlussbelegung Abstand AS-i Leitung zum Lese-/Schreibkopfgehäuse beachten. A = 100 mm Freiraum Lese-/Schreibkopf ↔ Leitung...
  • Page 7: Der Lese-/Schreibkopf Im Asi-Netzwerk Grundeinstellung

    Das Handbuch mit der ausführlichen Beschreibung der AS-i Dienste nach Profil 7.4 finden Sie im Internet unter: Datenblatt-Suche DTA100 weitere Informationen www.ifm-electronic.com Belegung der Datenbits In einem Übertragungszyklus werden folgende Daten in Datentripel übertragen: Additional Information Bits: O = Overflow-Bit (wird bei den Werten 7FFF und 8000 Hex. gesetzt, sonst 0)
  • Page 8: Codewert-Darstellung Durch Datenbit D16

    Das Handbuch mit der ausführlichen Beschreibung der AS-i Dienste nach Profil 7.4 finden Sie im Internet unter: Datenblatt-Suche DTA100 weitere Informationen www.ifm-electronic.com 9. Funkanlagenzulassung Kennzeichnung nach R & TTE (Radio Equipment and Telecommunications Terminal Equipment) CE-Identifikationsnummer: CE 0682 Intended use: Verwendung in allen EU Staaten 10.
  • Page 9: Technische Daten

    Anschluss M12-Steckverbindung Bemerkungen *) bezogen auf ID-TAG E80301 (Mitte Schraube) Abstände zu anderen ID-TAGs siehe jeweiliges Datenblatt (E803xx) ifm electronic gmbh • Teichstraße 4 • D-45127 Essen Technische nderungen behalten wir uns ohne Ankündigung vor ! DE - DTA100 17.03.2006...
  • Page 10 DTA100 READ WRITE HEAD FOR RF IDENTICFICATION SYSTEMS The operating instructions ... apply to all DTA100 type units..are for authorised persons according to the EMC and low voltage directives..are part of the unit. They contain information about the correct handling of the product.
  • Page 11: Safety Instructions

    (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications made to this equipment not expressly appro- ved by ifm electronic gmbh may void the FCC authorization to operate this equipment.
  • Page 12: Function And Features

    DTA100 READ WRITE HEAD FOR RF IDENTICFICATION SYSTEMS 2. Function and features • The DTA100 read/write head reads without contact data of RFID transponders (ID tags) that conform to the system, • converts them into digitally coded values • and provides them to the AS-i control level (AS-i master, controller or host).
  • Page 13: Indicators

    5. Installation Fixing is done using 2 M4 screws and nuts or an angle bracket. Information about the available mounting accessories is given on our website at: Data sheet direct DTA100 Accessories www.ifm-electronic.com example example article no. article no. E20898...
  • Page 14: Electrical Connection

    You can find a selection of sockets on our website at: Data sheet direct DTA100 Accessories www.ifm-electronic.com ASI+ core colours of ifm sockets: 1 = BN (brown) 3 = BU (blue) wiring Adhere to the distance between the AS-i cable and the housing of the read/write head.
  • Page 15: The Read/Write Head In The As-I Network Basic Setting

    You can find the manual with details about the AS-i services to the profile 7.4 on our website at: Data sheet direct DTA100 Additional Data www.ifm-electronic.com Assignment of the data bits In one transmission cycle the following data are transferred in data triples. extension bits...
  • Page 16: Additional Functions To The As-I Profile

    You can find the manual with details about the AS-i services to the profile 7.4 on our website at: Data sheet direct DTA100 Additional Data www.ifm-electronic.com 9. Approval of radio equipment Marking to R & TTE (Radio and Telecommunications Terminal Equipment) CE identification number: CE 0682 Intended use: use in all EU countries 10.
  • Page 17: Technical Data

    *) referred to the ID tag E80301 (middle of the screw) For the distances to other ID tags see the respective data sheet (E803xx) ifm electronic gmbh • Teichstraße 4 • D-45127 Essen We reserve the right to make technical alterations without prior notice .
  • Page 18 ) DTA100 TÊTE DE LECTURE ÉCRITURE POUR IDENTIFICATION PAR RADIOFRÉQUENCE RFID La notice d'utilisation ... s'applique à tous les appareils de type DTA100..s'adresse à des personnes compétentes selon les directives CEM et basse tension..fait partie de l'appareil. Elle fournit des indications sur l'utilisation correcte du produit.
  • Page 19 ) DTA100 TÊTE DE LECTURE ÉCRITURE POUR IDENTIFICATION PAR RADIOFRÉQUENCE RFID 1. Consignes de sécurité Généralité Respectez les indications de la notice d'utilisation. Le non-respect des consignes, l'emploi non conforme par rapport aux prescriptions, un montage ou une manipulation incorrects peuvent porter atteinte à la sécurité des personnes et des installations.
  • Page 20: Caractéristiques Et Fonctionnement

    ) DTA100 TÊTE DE LECTURE ÉCRITURE POUR IDENTIFICATION PAR RADIOFRÉQUENCE RFID 2. Caractéristiques et fonctionnement • La tête de lecture/écriture DTA100 lit sans contact les données des étiquettes électroniques RFID (TAG) qui sont compatibles avec le système, • les convertit en valeurs codées numériquement •...
  • Page 21: Eléments De Visualisation

    La fixation se fait par 2 vis M4 et écrous ou par une équerre. Vous trouverez des informations sur les accessoires de montage disponibles sur notre site web à : Fiche technique DTA100 Accessoires www.ifm-electronic.com exemple exemple référence référence E20898...
  • Page 22: Raccordement Électrique

    DTA100 Accessoires www.ifm-electronic.com couleurs des fils conducteurs des ASI+ connecteurs femelles ifm : 1 = BN (brun) 3 = BU (bleu) schéma de branchement Respectez la distance entre le câble AS-i et le boîtier de la tête de lecture/d'écritu- A = 100 mm...
  • Page 23: La Tête De Lecture/Écriture Dans Le Réseau As-I

    Vous trouvez le manuel donnant un descriptif détaillé de la communication AS-i selon le profil 7.4 sur notre site web à : Fiche technique DTA100 Information sur le Produit www.ifm-electronic.com Affectation des bits de données Dans un cycle de transmission les données suivantes sont transmises par triplets de données : bits d'extension bits de données utilisateurs...
  • Page 24: Fonctions Supplémentaires Selon Le Profil As-I

    à : Fiche technique DTA100 Information sur le Produit www.ifm-electronic.com 9. Homologation des équipements radio Marquage selon R & TTE (Radio and Telecommunications Terminal Equipment = équipements radioélectriques et équipements terminaux de télécommunications) Numéro d'identification CE : CE 0682 Utilisation prévue : utilisation dans tous les états de l'UE...
  • Page 25: Données Techniques

    *) par rapport au TAG E80301 (milieu de la vis) Pour les distances avec d'autres TAG voir la fiche technique correspondante (E803xx) ifm electronic gmbh • Teichstraße 4 • D-45127 Essen Nous nous réservons le droit de modifier les données techniques sans préavis . FR - DTA100...
