INTRODUCTION

Thank you for your purchase of redKnows SBX-3 series product. In order to take full advan-
tage of this product, please read this manual carefully before starting to use the product.
SBX-3 can be used for guarding many types of objects such as cars, boats, excavators,
containers, motorcycles, campervans and others. In this manual all objects are referred to
as "vehicles" or objects.
SBX-3 is a GSM based positioning alarm. The alarm can be triggered by an alarm sensor
connected to one of the inputs or if the object is moved outside a defi ned area, so called
geofencing. When triggered the siren will sound and an SMS message will be sent to pre-
stored telephone numbers.
In addition to the alarm function, SBX-3 can also be used for tracking the position of an
object and control equipment with SMS.
The SBX-3 can only communicate with the prestored telephone numbers on the SIM card in
SBX-3. They can receive alarm SMS and control the alarm.
In the package you will fi nd:
Main unit with integrated GSM
module and spare battery.
GPS receiver
GSM antenna
The units are installed according to the instructions in this manual and a SIM card is inser-
ted. Then the users telephone numbers has to be stored into the SIM-card in order to allow
access to the system.
After this introduction the manual continues with instructions for handling the SBX-3 with
the remote controller and a mobile phone, once it is installed an initialised.
The installation should be made by a person with proper knowledge of the electrical system
of the object. Instructions are found in the Installation Manual.
When the system is installed a SIM card is inserted and power is applied. Then the SIM
card should be prepared with the proper settings, this is described in the Setup Manual.
SBX-3
C
1
2
3
4
5
6
7
8
9
*
0
#
T
SOS
SO
SO
S
SO
SOS S S
S OS
SO
S S S S
SOS
SOS
OS
OS S
S
S
SBX-3
Mini Tracker
User and
Installation Manual
Siren
Remote Control
Magnet Switch
Microphone
Cable kit
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SBX-3 and is the answer not in the manual?

Questions and answers

Related Manuals for RedKnows SBX-3

Summary of Contents for RedKnows SBX-3

  • Page 1: Introduction

    When triggered the siren will sound and an SMS message will be sent to pre- stored telephone numbers. In addition to the alarm function, SBX-3 can also be used for tracking the position of an object and control equipment with SMS.

  • Page 2: Table Of Contents

    Installation ......................12 SETUP MANUAL ....................13 SIM card in users mobile phone ................13 SIM card in SBX-3 ....................14 Programming the SIM-card in SBX-3 ..............14 Learn Remote Controller ..................17 TECHNICAL SPECIFICATION ................18 System description ................... 18 Functions ......................

  • Page 3: User Manual

    When the alarm is armed the high decibel siren will beep once. If a sensor input is in activated state, the SBX-3 will not go into armed mode and the high decibel siren will beep 3 times as a warning.

  • Page 4: Mobile Phone

    When SBX-3 receives SMS message SET, it will arm the security system and the high de- cibel siren will beep once. If a sensor input is in activated state, the SBX-3 will not go into armed mode and the high decibel siren will beep 3 times as a warning.

  • Page 5: Alarms

    Alarms SMS-message: ACC Alarm SBX-3 will immediately trigger the alarm when redKnows Mode: Ignition key, ACC, is turned on. Alarm TRG, ACC_ON GMT: 090912, When the alarm is triggered, the mobile pho- Long 011 57.177E, Lat 57 44. 8876N, nes in group 1 will receive ACC_ON + status Speed 001knots, message.

  • Page 6: Geofence Alarm

    Recommended setting is 6 due to the fact that, even if the vehicle is in a fi xed position, the data from the GPS can change over time depending on reception conditions. When armed, the SBX-3 will store the current position. Then, every SMS-message: ten minutes, it will exit power saving mode, read the GPS position and compare with the stored position.

  • Page 7: Disconnected Gps Alarm

    If immobilization function is not required this function can be used to turn on and off other devices such as a heater or water pump. The relay is switched on when SBX-3 receives SMS message OUT_ON The relay is switched off when SBX-3 receives SMS message OUT_OFF or when SBX-3 is disarmed.

  • Page 8: Monitoring Function

    The interval can be set between 10 to 990 seconds, ss=01 is 10 seconds and ss=99 is 990 seconds. nn is the number of LOCATE SMS to be sent from SBX-3. The num- redKnows Mode: ber can be set between 01 to 99. The default is 5 SMS: message...

  • Page 9: Location Search By Phone Call

    Geofence region to LAT 8 och LON 8 Power saving mode SBX-3 has an automatic power saving function. When it enters the power saving mode, all LEDs are off and GPS is powered down. To exit the power saving mode, press the unlock key...

  • Page 10: Installation Manual

    • Siren • Remote Control • Magnet Switch, Normal Closed • Microphone • Cable kit Not included: SIM card for SBX-3, more information in the Setup Manual section Connections 1 White Input and output wires Antenna (for remote control) 2 Orange...

  • Page 11: Cable Installation Instructions

    External main battery Gnd. Connect as close to battery negative terminal as possible. NOTE! Do not connect cable 7 until the SIM card has been inserted into the SBX-3 Sensor1 trigger, Negative triggering. >1.5V or no connection is positive, < 1.5V is nega- tive.

  • Page 12: Installation

    Hide the components and cabling as much as pos- sible. Since SBX-3 is operated only with the wireless Remote Controller and mobile phone there is no need to have easy access to the units.

  • Page 13: Setup Manual

    11 should be connected to +, witch will prevent the power save mode, until position is found and the red GPS LED starts blinking. Yellow GSM LED blinks when the SBX-3 is in contact with the GSM-net. Green SYS LED blinks when the SBX-3 is in operation.

  • Page 14: Sim Card In Sbx-3

    Insert the SIM card into the SIM card holder observing the correct position indicated by the fi gure close to the card slot. Apply power to the SBX-3: Connect the black cables 7 and 12 to ground and red cable 10 to battery +.
  • Page 15 A number can not be used in both group 4 and group 5 Group 6 numbers can send SMS to control SBX-3 Shaded positions should not be changed or used. As a basic setting we suggest the following: In MAIN_A the telephone number of the SIM card, The primary users phone number in USER_A and the last 8 digits of the primary users phone number in SEARCH_A.
  • Page 16 Sending SMS to enter the numbers: In order to store numbers and settings in the SBX-3 SIM card, send an SMS in this format: TSST$MAIN_A:0733123456&USER_A:0706123456&SEARCH_A:06123456& Where 0733123456 should be changed to the telephone number of the SIM card 0706123456 should be changed to the primary users phone number...

  • Page 17: Learn Remote Controller

    The following procedure is only necessary if a new remote controller should be used with the system. In order for SBX-3 to recognize the commands from a remote control- ler it has to be learned. The procedure for learning the remote is: 1.

  • Page 18: Technical Specification

    GPS module and tri-band GSM module, the mini security tracker can perform security and tracking for all over the world. The water resistant design allows the SBX-3 to be applied to any mobile vehicles, boats, houses, cargo containers, and any objects for complete safety.

  • Page 19: Accessories, Optional

    SMS - Short Message Service - A text messaging service in the mobile telephone system Relay - An electrically controlled circuit breaker SIM card - A small plastic card with a computer chip used by mobile phones and SBX-3. The card contains information such as telehone number and mobile phone operator.
  • Page 20 FCC ID : USW-SBX-3 FCC INFORMATION The Federal Communication Commission Radio Frequency Interference Statement includes the following paragraph: The equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to part 24 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
