MS120-8 Series Installation Guide
Model Number
MS120-8
MS120-8LP
MS120-8FP
Package contents
In addition to the MS switch, the following are provided:
Wall Mount Kit includes
• Dry Wall Anchors, 2 of each
• Mounting Screw, 2 of each
MS120-8FP Series front panel
MS120-8/LP Series front panel
Description
Layer-2 8-port gigabit Ethernet switch with 2 SFP
interfaces
Layer-2 8-port gigabit Ethernet 67W PoE switch
with 2 SFP interfaces
Layer-2 8-port gigabit Ethernet 124W PoE switch
with 2 SFP interfaces
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Cisco MERAKI MS120-8 Series
Summary of Contents for Cisco MERAKI MS120-8 Series
-
Page 1: Package Contents
MS120-8 Series Installation Guide Model Number Description Layer-2 8-port gigabit Ethernet switch with 2 SFP MS120-8 interfaces Layer-2 8-port gigabit Ethernet 67W PoE switch MS120-8LP with 2 SFP interfaces Layer-2 8-port gigabit Ethernet 124W PoE switch MS120-8FP with 2 SFP interfaces... - Page 2 Ports and Status Indicators The MS uses LEDs to inform the user of the device's status. When the device powers on, all the Internet LEDs flash twice. Additional functions are described below, from left to right. Item Function LED Status Meaning Power Solid orange...
-
Page 3: Mounting Hardware
MS120-8/LP Series back panel Additional functions on the back panel are described below, from left to right. Power input Power cords may be ordered separately. Equipment is to be used only in a restricted access location and installed/operated only by trained service personnel. - Page 4 Connecting to the Meraki Cloud All Meraki MS devices must have a logical network connection and valid IP address. An IP address can be assigned dynamically through a local DHCP server or statically through a local management interface. For details on getting started, read the Quick Start.
