Page 2: Specification
Banshee Plus Plus includes: 1* Banshee Plus BOX MOD 1* User Manual Specification Size: 55mm*95mm*26mm Output Mode:TEMP-Ti/TEMP-Ni/Temp-SS/POWER Output Wattage:1W-150W Support resistance: above 0.1ohm Temperature Range: 100C-315C (200F-600F); Each +/- increase or decrease 5C/10F Hidden full length LED display, durable stainless steel,... - Page 3 Pieces & Parts A) Firing button B)Adjust up button C)Adjust down button D)USB port (underneath) for firmware only! E)Hidden display area...
- Page 4 Slide off the battery cover, and put 2pcs 18650 cell into the battery holder(recommends:high-rate and better branded 18650 cells,Max discharge current over 20A) Press the firing button 5 times within 2S to turn on the devise on/off, Power on screens display “CIGGO” → Resting Screen 2. Details Operation Steps Enter Setting Mode: Press both adjustment buttons simultaneously.
-
Page 5: Display Screens
Display Screens: A)Powering on screen B)Resting screen (Power Mode) C)Nichrome TC Mode D)Titanium TC Mode E)Stainless steel TC Mode... - Page 6 3. Vaping Hold the firing button and inhale from the atomizer mouthpiece, release the firing button and exhale The “ ” battery symbol will change to “ ”lightning symbol 4. Adjust power: Press adjustment buttons. Longer press=Faster adjustment (After you have made your selection/adjustments, the display will show your power output for 1s and then your resistance for 3s) How to Switch Fahrenheit and Celsius Under TEMP NI/TI/SS working mode, firstly set Celsius up to 315C, then press “+”...
-
Page 7: Short Circuit Protection
How to adjust Wattage Under TEMP NI/TI/SS working mode, press firing button and “+” together to increase the wattage, Press firing button and “-” button together to decrease the wattage. 5. Short circuit protection If the devise didn’t screw with atomizer or the atomizer resistance is exceed supporting range, screen display “Ω”... - Page 8 8. Over discharge remind protection If vaping voltage is lower than 6.8V, the battery symbol will flashing 5 times to remind you the devise needs to charging, and device turns off automatically.(Picture 1]) 9. Over Hot Protection If device inner temperature over 70C, Screen will display “HOT”...
- Page 9 How to edit your led screen: 1. 1) Make sure your box mod don't have battery cell inside. (if you already have battery cell inside , please take it out), keep the box mod empty or at least the battery slider is open. 2) Press both "+"...
- Page 10 4. To finish the settings, long press on fire button and "-" （image J）until the screen shows "END"(image K) , settings are done. image J image K Warm promopt: 1.If you failed with screen editing, please recheck if you've followed correct operating steps , as buttons not press at the same time , or cover back the battery slider too early, both will cause unsuccessful opeartion.
- Page 11 Possible side effect: Using this device can cause dehydration and lead to mouth and throat irritation, if it’s occurs, please change your power and/or airflow setting and/or the your e-liquid. The crossed-out dustbin symbol indicates that batteries, rechargeable batteries, button cells, battery packs, etc.
- Page 12 Our Limited warranties are void if a product is returned with removed, damaged or tampered labels or any alterations, including removal or alteration of any internal or external components. This Warranty extends to the original purchaser only and is non-transferable. Purchaser is required to show proof of purchase for any clams. Contact: service@ciggo.com for warranty inquiries.
